ACC–CK100 Caster Kit Installation Instructions
Description
The contents of this kit allow the addition of casters to various
subwoofers. Only use with subwoofers specifically designed
to use the ACC–CK00 kit.
Note: In order to use this kit with any subwoofer, users should first
verify that there are mounting holes located on the rear of the cabinet.
ACC–CK100 Caster Kit (Part No. 2035618-01 / 02) contents:
Item Quantity Description
A 6 Screw, M6 hex head
B 6 Washer, lock
C 6 Washer, flat
D 4 Caster Swivel
Required Tools (not included):
#3 Phillips screwdriver
0mm socket wrench
Safety First!
Before installing and using this product, please read these instructions
carefully and keep them on hand for future reference. Additionally,
refer to the subwoofer product manual for detailed product-specific
information. Failure to follow the precautions in both documents
may result in injury or damage to the subwoofer and/or contents
of the caster kit.
WARNING: This product has been designed for installation only
by qualified personnel having the technical know-how and experience
or specific instructions to ensure correct execution of all of the operations
involved to prevent any risk to personal safety. It is strongly recommended
that this product be installed only by professionals or specialized firms.
When installing this product, always respect the safety standard. Do not
install the product in any way that is not described in these instructions.
Caster Installation
. Using the #3 Phillips screwdriver, remove the 6 screws
from the rear corners of the subwoofer.
2. Place the threaded part of the screw (A) through the locking
washer (B).
3. Place the screw through the flat washer (C).
4. Place the screw through one of the openings of the caster
(D) and finger-tighten.
5. Repeat steps 2-4 for the remaining three openings of the same
caster.
6. Using the 0mm socket wrench, fully tighten the four screws
into the threaded inserts of the subwoofer.
7. Repeat steps 2-6 for the remaining three casters.
VERY IMPORTANT: Do not over-tighten the screws, as this could
damage the threaded inserts of the subwoofer.
Note: Subwoofer shown is for reference only and may not reflect
the user’s actual subwoofer.
B
D
A
C
LOUD Audio, LLC. • 6220 Wood-Red Road NE
Woodinville • WA • 98072 • 800/258-6883
Outside the U.S. call 425/487-4333 • FAX 425/487-4337
Disclaimer:
LOUD Audio, LLC. continually engages in research related to product improvement.
New material, production methods, and design refinements are introduced into existing
products without notice as a routine expression of that philosophy. For this reason, any
current LOUD Audio, LLC. product may dier in some respect from its published description,
but will always equal or exceed the original design specifications unless otherwise stated.
Part No. SW0867 Rev D 04/19
© 209 LOUD Audio, LLC. All Rights Reserved.
