O W N E R ’ S M A N U A L
1600W POWERED LOUDSPEAKERS
SRM550 • SRM650 • SRM750
SRM550 • SRM650 • SRM750 Powered Loudspeakers
2
SRM550 • SRM650 • SRM750 Powered Loudspeakers
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manu-
facturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding-
type plug has two blades and a third grounding prong. The wide blade or
the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.
Only use attachments/accessories specified by the manufacturer.
12.
Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15.
This apparatus shall not be exposed to dripping or splashing, and no object
filled with liquids, such as vases or beer glasses, shall be placed on the
apparatus.
16.
Do not overload wall outlets and extension cords as this can result in a risk
of fire or electric shock.
17.
This apparatus has been designed with Class-I construction and must be
connected to a mains socket outlet with a protective earthing connection
(the third grounding prong).
18.
This apparatus has been equipped with a rocker-style AC mains power
switch. This switch is located on the rear panel and should remain readily
accessible to the user.
PORTABLE CART
WARNING
CAUTION
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the prescence of uninsulated “dangerous voltage
within the product’s enclosure, that may be of significant
magnitude to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important
operating and maintaining (servicing) instructions in the
literature accompanying the appliance.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
Apparatet må tilkoples jordet stikkontakt.
Apparaten skall anslutas till jordat uttag.
19.
The MAINS plug or an appliance coupler is used as the disconnect device,
so the disconnect device shall remain readily operable.
20. NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandthereceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthat
to which the receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
CAUTION: Changes or modifications to this device not expressly approved
by LOUD Technologies Inc. could void the user's authority to operate the
equipment under FCC rules.
21.
This apparatus does not exceed the Class A/Class B (whichever is
applicable)
limits for radio noise emissions from digital apparatus as
set
out in the radio interference regulations of the Canadian Department
of
Communications.
ATTENTION
Le présent appareil numérique n’émet pas de bruits radioélec-
triques dépassant las limites applicables aux appareils numériques de class
A/de class B (selon le cas) prescrites dans le réglement sur le brouillage
radioélectrique édicté par les ministere des communications du Canada.
22.
Exposure to extremely high noise levels may cause permanent hearing
loss. Individuals vary considerably in susceptibility to noise-induced hearing
loss, but nearly everyone will lose some hearing if exposed to sufficiently
intense noise for a period of time. The U.S. Government’s Occupational
Safety and Health Administration (OSHA) has specified the permissible
noise level exposures shown in the following chart.
According to OSHA, any exposure in excess of these permissible limits
could result in some hearing loss. To ensure against potentially dangerous
exposure to high sound pressure levels, it is recommended that all persons
exposed to equipment capable of producing high sound pressure levels
use hearing protectors while the equipment is in operation. Ear plugs or
protectors in the ear canals or over the ears must be worn when operating
the equipment in order to prevent permanent hearing loss if exposure is in
excess of the limits set forth here:
Duration, per
day in hours Sound Level dBA,
Slow Response Typical Example
8 90 Duo in small club
6 92
4 95 Subway Train
3 97
2 100 Veryloudclassicalmusic
1.5 102
1 105 John screaming at Troy about deadlines
0.5 110
0.25 or less 115 Loudest parts at a rock concert
WARNING — To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
CAUTION — To prevent electric shock hazard, do not connect
to mains power supply while grille is removed.
Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household
waste, according to the WEEE directive (2012/19/EU) and your national law. This product should be handed over to
an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling of this type
of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances
that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product will
contribute to the effective usage of natural resources. For more information about where you can drop off your waste
equipment for recycling, please contact your local city office, waste authority, or your household waste disposal service.
Important Safety Instructions
Owner’s Manual
3
Owners Manual
Contents Features
Part No. SW0985 Rev. B 07/14
©2014 LOUD Technologies Inc. All Rights Reserved.
• 1600Wsystempowerpairedwithcustom
 transducersdelivergig-levelvolumeswith
 roomtospare
• 12"high-outputLFdriver/1.4"titaniumdome
  compressiondriver[SRM550]
• 15"high-outputLFdriver/1.4"titaniumdome
  compressiondriver[SRM650]
• 2x15"high-outputLFdriver/1.4"titanium
  domecompressiondriver[SRM750]
• “Built-Like-A-Tank”all-wood,internally
 bracedcabinetdeliversprofessional-grade
 road-worthiness
• Rugged18-gaugesteelgrilleandne-textured,
  sleekblackcabinetnish
• Frontportedformaximumlow-endextension
  andpunch
• High-DenitionAudioProcessingforprofessional
 soundwithunmatchedclarity
• Patentedacousticcorrectiondevelopedwith
  touringgeniusesatEAW®
• Precision2-waydigitalcrossover
• Drivertimealignmentandphasecorrection
• Quickone-buttonSpeakerModeselection
 forapplication-specicvoicing(PA,DJ,Monitor,
 Soloist,FillandSpeech)
• Effortlesslyeliminatenastyfeedbackwith
 one-buttonautomaticFeedbackDestroyer
• Integrated2-channelmixerfeaturingdual
 Wide-Zinputs
• Handlesanythingfrommicstoguitarsto 
  mixerswithasingletwistofthegainknob
• IncludesstereoRCAinputsforeasyconnection
  tomusicsource
• Perfectforthesinger/songwriter,
  pluginandleavethemixerathome
• SmartProtectDSPkicksintoprotect
 yourinvestmentwhenthingsgetpushed
 alittletoohard
• FlyableviastandardM10eyebolts
• Monitor-specic60˚angleandvoicing
 modeperfectforcuttingthroughonstage
 [SRM550/SRM650]
Like us
Follow us
Watch our dang videos
Important Safety Instructions 2 ..................................
Contents 3 .................................................................
Features 3 .................................................................
Introduction 4 ............................................................
How To Use This Manual 4 .........................................
Getting Started 4 .......................................................
Things To Remember 4 ................................................
Hookup Diagrams 5 ....................................................
SRM Loudspeaker: Rear Panel Features 9 ....................
1. Power Connection 9 .........................................
2. Power Switch 9 ...............................................
3. XLR and 1/4" Combo Inputs 9 ..........................
4. Gain Knobs 10 .................................................
5. RCA Inputs [Channel 2 Only] 10 .......................
6. Thru Output ................................................ 11
7. Ch 1/Mix Switch [Thru Output] ................... 11
8. Speaker Mode 11 ............................................
9. Feedback desTROYer 11 ...................................
10. Main Logo Switch / Limit LED 12 ....................
11. Extra Knobs, Buttons and LEDs .................. 12
12. Rock ‘n Roll 12 ..............................................
Smart Protect 13 .......................................................
Limiting .......................................................... 13
Overexcursion Protection ................................ 13
Thermal Protection 13 ..........................................
AC Power 13 .............................................................
Care and Maintenance 13 ...........................................
Placement 14 .............................................................
Room Acoustics 15 ...............................................
Rigging ............................................................... 16
Rigging Design Practices .................................. 16
Rigging Hardware and Accessories ................... 16
Rigging Notes ................................................. 16
Important Rigging Reminder ............................ 17
Appendix A: Service Information ............................ 18
Appendix B: Connections ....................................... 20
Appendix C: Technical Information .......................... 21
SRM550 Dimensions & Frequency Response 23 .....
SRM650 Dimensions & Frequency Response ..... 24
SRM750 Dimensions & Frequency Response ..... 25
SRM Loudspeaker Block Diagram 26 .....................
Limited Warranty .................................................. 27

Produktspecifikationer

Varumärke: Mackie
Kategori: högtalare
Modell: SRM750

Behöver du hjälp?

Om du behöver hjälp med Mackie SRM750 ställ en fråga nedan och andra användare kommer att svara dig




högtalare Mackie Manualer

högtalare Manualer

Nyaste högtalare Manualer
