O W N E R ’ S M A N U A L

High-Performance Powered Loudspeaker Series

SRM210 | V-Class

SRM212 | V-Class

SRM215 | V-Class

SRM | V-Class High-Performance Powered Loudspeaker Series

2SRM | V-Class High-Performance Powered Loudspeaker Series

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8. Minimum distance (5 cm) around the apparatus for sucient ventilation.

The ventilation should not be impeded by covering the ventilation openings

with items, such as newspapers, table-cloths, curtains, etc.

9. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliﬁers) that produce heat.

10. No naked ﬂame sources, such as lighted candles, should be placed

on the apparatus.

11. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding-

type plug has two blades and a third grounding prong. The wide blade or

the third prong are provided for your safety. If the provided plug does not ﬁt

into your outlet, consult an electrician for replacement of the obsolete outlet.

12. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

13. Only use attachments/accessories speciﬁed by the manufacturer.

14. Use only with a cart, stand, tripod, bracket, or table

speciﬁed by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/

apparatus combination to avoid injury from tip-over.

15. Unplug this apparatus during lightning storms or when

unused for long periods of time.

16. Refer all servicing to qualiﬁed service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has been dropped.

17. This apparatus shall not be exposed to dripping or splashing, and no object ﬁlled

with liquids, such as vases or beer glasses, shall be placed on the apparatus.

18. Do not overload wall outlets and extension cords as this can result in a risk

of ﬁre or electric shock.

PORTABLE CART

WARNING

CAUTION

The lightning ﬂash with arrowhead symbol within an equilateral

triangle is intended to alert the user to the prescence of uninsulated

“dangerous voltage” within the product’s enclosure, that may be of

signiﬁcant magnitude to constitute a risk of electric shock to persons.

RISK OF ELECTRIC SHOCK! DO NOT OPEN!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED PERSONNEL.

The exclamation point within an equilateral triangle is intended

to alert the user of the prescence of important operating and

maintaining (servicing) instructions in the literature accompanying

the appliance.

WARNING — To reduce the risk of ﬁre or electric shock, do not

expose this apparatus to rain or moisture.

CAUTION — To prevent electric shock hazard, do not connect

to mains power supply while grille is removed.

Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.

Apparatet stikprop skal tilsluttes en stikkontakt

med jord, som giver forbindelse til stikproppens jord.

Apparatet må tilkoples jordet stikkontakt.

Apparaten skall anslutas till jordat uttag.

19. This apparatus has been designed with Class-I construction and

must be connected to a mains socket outlet with a protective earthing

connection (the third grounding prong).

20. This apparatus has been equipped with a rocker-style AC mains power

switch. This switch is located on the rear panel and should remain readily

accessible to the user.

21. The MAINS plug or an appliance coupler is used as the disconnect device,

so the disconnect device shall remain readily operable.

22. The use of apparatus is in moderate climates.

23. This device should be installed and operated with minimum distance 20cm

between the radiator & your body.

The product can be sold in all EU countries.

Bluetooth transmitter Power: 19dBm ≤

Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

24. NOTE: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation

of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his

own expense.

Equipment meeting Class A requirements may not oer adequate NOTE:

protection to broadcast services within a residential environment.

Changes or modiﬁcations to this device not expressly approved CAUTION:

by LOUD Audio, LLC could void the user’s authority to operate the equipment

under FCC rules.

25. This apparatus does not exceed the Class A/Class B (whichever

is applicable) limits for radio noise emissions from digital apparatus

as set out in the radio interference regulations of the Canadian Department

of Communications.

Canada ICES-003(A)/NMB-003(A)

ATTENTION

— Le présent appareil numérique n’émet pas de bruits

radioélectriques dépassant las limites applicables aux appareils

numériques de class A/de class B (selon le cas) prescrites dans

le réglement sur le brouillage radioélectrique édicté par les ministere

des communications du Canada.

26. Exposure to extremely high noise levels may cause permanent hearing loss.

Individuals vary considerably in susceptibility to noise-induced hearing loss,

but nearly everyone will lose some hearing if exposed to suciently intense

noise for a period of time. The U.S. Government’s Occupational Safety and

Health Administration (OSHA) has speciﬁed the permissible noise level

exposures shown in the following chart.

According to OSHA, any exposure in excess of these permissible limits

could result in some hearing loss. To ensure against potentially dangerous

exposure to high sound pressure levels, it is recommended that all persons

exposed to equipment capable of producing high sound pressure levels

use hearing protectors while the equipment is in operation. Ear plugs or

protectors in the ear canals or over the ears must be worn when operating

the equipment in order to prevent permanent hearing loss if exposure is in

excess of the limits set forth here:

Duration, per

day in hours

Sound Level dBA,

Slow Response Typical Example

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Very loud classical music

1.5 102

1 105 Matt screaming at Troy about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE directive (2012/19/EU)

and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling of this type of waste

could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation

in the correct disposal of this product will contribute to the eective usage of natural resources. For more information about where you can drop o your waste equipment for recycling, please

contact your local city oce, waste authority, or your household waste disposal service.

Owner’s Manual

Features

Part No. SW296 Rev. A 05/20

Industry-leading 2000W Class-D ampliﬁers

• Our most advanced ampliﬁer plaform ever, delivering

incredible stability, headroom, and audio ﬁdelity

• Unrivaled reliability and rock-solid operation

can withstand the most demanding applications

• Universal power supply (00-240VAC) with Power

Factor Correction for stable operation even with

unstable AC power

Advanced Impulse™ DSP – Proprietary Acoustic Tuning

• Crystal clear sound across the entire dispersion zone

means the whole room is the sweet spot

• Precision crossover and transducer time-alignment

ensures balanced and accurate sound

Intelligent Bass Management™

• Our proprietary LF management technology maintains

tonal balance and output level when operating at very

high volumes while keeping the bass tight and punchy

Custom Sym-X™ Horn

• Allows for total eciency from the HF transducer

minimizing distortion and increasing output

• Creates a perfectly symmetrical, ﬂat response at

the crossover point for exceptionally smooth midrange

• The horn-loading frequency is set below the drivers’

LF capability allowing for maximum eciency

and optimal performance at the crossover point

High-Performance Custom Transducers

• Large, powerful magnets partner with robust motors,

voice coils and spiders to provide the highest possible

eciency and transient accuracy

• Additional cooling vents surrounding the specially

designed voice coil plus directional cabinet porting

ensures maximum heat dispersion and reliability

• Premium polymer high-frequency driver provides

the ﬂattest possible response for incredibly smooth

highs that sound natural and balanced

Transparent System Limiting and Protection

• Dedicated processing module monitors and protects

the ampliﬁer in real time

• Sound quality and tonal balance is maintained

even under heavy limiting

• Utilizing powerful multi-band compression, the ampliﬁer

can target speciﬁc frequency ranges to prevent

the system from being overloaded rather than turn

everything down at the expense of overall output

• Input limiting keeps your source signal in check

so if you’re sending audio that’s a bit too hot,

the speaker will cool it down

Like us Follow us Watch our dang videos

SRM Mix Control™ Built-in 4-Channel Digital Mixer with Bluetooth®

• Dual independent channels that support mic, line,

and instrument signals

• Dedicated /8" stereo aux channel

• Stream music from any Bluetooth® enabled device

• High-contrast full color display for easy single-knob

access to mixer and processing

• Adjust channel levels and EQ

• Application and venue speciﬁc voicing modes

• Alignment delay – up to 00 feet

• Save and recall up to 0 user presets

• Screensaver plus dimmer and contrast control

• System lock with 4-digit passcode

• Change front LED function: Green, white, o,

signal present, multi (cycle through colors)

Complete Wireless Control via the SRM Connect™ App

• The SRM Connect™ app gives you access

to all adjustments and settings including EQ,

levels, and presets

Wirelessly link two SRM | V-Class speakers together for music

streaming applications plus complete control over both speakers

• The latest Bluetooth technology allows up to 00 meters

of range between linked speakers

• Stereo or dual zone linking modes allows discrete

control over the inputs and outputs of the entire

system across two rooms or zones

• Creates an incredibly clean setup in minutes

Versatile conﬁguration options

• Dual-angled cabinet design allows for use

as a high-performance ﬂoor monitor

• Dual angle pole-mount provides optimal coverage

and minimal reﬂections in most venues. The 7-degree

downward tilt is perfect for when the speakers are on

elevated stages.

• M0 ﬂypoints for professional installation

Produktspecifikationer

Varumärke:	Mackie
Kategori:	högtalare
Modell:	V-Class SRM212
Typ av operation:	Buttons, Rotary
Färg på produkten:	Grafiet
Inbyggd display:	Ja
Timer:	Ja
Bredd:	600 mm
Djup:	600 mm
Höjd:	900 mm
Grill:	Ja
Barnlås:	Nee
Ljudnivå:	- dB
Energie-efficiëntieklasse:	A
Integrerad klocka:	Ja
Typ av klocka:	Elektronisch
Ångkokning:	Nee
Rotisserie:	Nee
Avfrostningsfunktion:	Nee
Antal brännare/kokzoner:	4 zone(s)
Typ av häll:	Gaskookplaat
Elektronisk tändning:	Ja
Total inomhuskapacitet (ugnar):	109 l
Ugnens strömkälla:	Natuurlijk gas
Antal ugnar:	2
Antal gasbrännare:	4 zone(s)
Kontrollposition:	Voorkant
Typ av rengöring:	Katalytisch
Energiförbrukning (konventionell):	- kWu
Energiförbrukning (tvungen konvektion):	- kWu
Ugnsstorlek:	Groot
Total ugnseffekt:	- W
Ugn med nettokapacitet:	77 l
Över- och undervärme:	Ja
Självrengörande:	Ja
Undervärmning:	Ja
Övervärme:	Ja
Skriv timer:	Digitaal
Pannstödsmaterial:	Geglazuurd
Säkerhetsventil:	Ja
Restvärmeindikator:	Nee
Ugn med bruttokapacitet:	77 l
Pizza funktion:	Nee
Snabb värme:	Ja
Ugnskraft:	- W
Långsam matlagning:	Ja
Wokbrännare:	Nee
Typ produkt:	Vrijstaand fornuis
3D varmluft:	Nee
Täckplatta:	Ja
Bakplåt:	Nee
Ugn 2 bruttokapacitet:	32 l
Brödbakningsfunktion:	Nee
