Sida 1/65

Magellan Navigation SAS. - ZAC de la Fleuriaye - BP 60433

44477 Carquefou Cedex - France

Magellan®

Maestro™

User Manual

Maestro 3050

Maestro 3100

Maestro 3140

Downloaded from www.Manualslib.com manuals search engine

The Magellan Maestro is a vehicle-navigation aid designed to assist you in arriving at your selected destinations. When using

the Magellan Maestro, these safety rules must be followed to prevent accidents that can result in injury or death to yourself

or others:

• Some countries prohibit mounting any item to your windscreen. Please check the applicable regulations in your country

as regards windscreen mounting. Go to www.magellanGPS.com for alternate mounting solutions. An adhesive disk is

supplied with the Magellan Maestro for use as an alternative mounting solution to the dashboard.

• When driving, the need to view the display is minimal. Voice prompts will guide you to your destination. The driver

should enter data or programme the Magellan Maestro only when the vehicle is stationary. Only a vehicle passenger

should enter data or programme the Magellan Maestro while the vehicle is moving.

• It is your responsibility to comply with all traffic laws.

• Every attempt is made to ensure that the database is accurate. However, roadways, points of interest (POIs) and

business and service locations may change over time. The database does not include, analyse, process, consider or

reflect any of the following: legal restrictions (such as vehicular type, weight, height, width, load and speed restrictions);

road slope or grade; bridge height, width, weight or other limits; population density; neighbourhood quality or safety;

availability or proximity of police, emergency rescue, medical or other assistance; construction work zones or hazards;

road or lane closures; road, traffic or traffic facilities’ safety or condition; weather conditions; pavement characteristics

or conditions; special events; traffic congestion. It is your responsibility to disregard any unsafe, hazardous or illegal

route suggestions.

• Keep the Magellan Maestro safe from extreme temperature conditions. For example, do not leave it exposed to direct

sunlight for an extended period of time.

• Take care when mounting the Magellan Maestro in your vehicle, whether using the windscreen mount or other mount or

accessories, that it does not obstruct the driver’s view of the road, interfere with the operation of the vehicle’s safety

devices such as air bags, or present a hazard to occupants of the vehicle should the Magellan Maestro be dislodged

while driving. You assume the risks associated with damage to your vehicle or vehicle occupants as the result of your

choices in mounting the Magellan Maestro.

• Laws in some countries prohibit wearing stereo headphones while operating a motor vehicle. Please check the applicable

laws for the country in which you are driving.

• Proceed with caution when listening to music for prolonged periods of time through headphones, as this may lead to

hearing loss.

• The battery in the Magellan Maestro is rechargeable and should not be removed. If it ever needs to be replaced, please

contact Magellan Technical Support.

About Charging the Magellan Maestro

• Only use the AC adapter (Phihong: PSC2200R-050) approved for your Magellan Maestro. Use of another type of AC

adapter can result in malfunction and/or a possible fire hazard due to battery overheating.

• Only use the car charger approved for/supplied with your Magellan Maestro. Use of another type of car charger will result

in a malfunction and/or may be hazardous.

• The Magellan Maestro is intended to be supplied with a LISTED Power Unit marked with "LPS", "Limited Power Source"

and output rated + 5 V DC/2.0 A".

• Use the USB cable approved for/supplied with your Magellan Maestro.

• For safety reasons, the battery in your Magellan Maestro will stop charging when the ambient temperature is below 0°C

(32°F) or above 45°C (113°F).

IMPORTANT SAFETY WARNINGS

Downloaded from www.Manualslib.com manuals search engine

IMPORTANT SAFETY WARNINGS

About the AC Adapter

• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.

• Allow adequate ventilation around the adapter when using it to operate the device or charging the battery. Do not cover

the AC adapter with paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a

carrying case.

• Connect the adapter to a suitable power source. The voltage and earthing requirements are found on the product case

and/or packaging.

• Do not use the adapter if the cord becomes damaged.

• Do not attempt to service the Magellan Maestro. There are no serviceable parts inside. Replace the Magellan Maestro if

it is damaged or exposed to excess moisture.

About the Battery

• Do not attempt to replace the battery. Please contact Magellan Technical Support for issues related to the battery.

• Use the charger approved for your Magellan Maestro.

Downloaded from www.Manualslib.com manuals search engine
