Sida 1/37

FREE

Lifetime

Map

Updates

Record

Video

Magellan

RoadMate

6220-LM

6230-LMX

6235-LM

User Manual

RoadMate User Manual Page ii

IMPORTANT SAFETY WARNINGS

The Magellan RoadMate receiver is a vehicle-navigation aid designed to assist you in arriving at

your selected destinations. When using the Magellan RoadMate receiver, these safety rules must be

followed to prevent accidents that can result in injury or death to yourself or others:

Please check the applicable regulations in your state regarding windshield mounting. Certain

states prohibit the mounting of any items on your windshield. Go to www.magellanGPS.com for

alternative mounting solutions.

When driving, the need to view the display is minimal. Voice prompts will guide you to your

destination. The driver should enter data or program the Magellan RoadMate receiver only when

the vehicle is stationary. Only a vehicle passenger should enter data or program the Magellan

RoadMate receiver while the vehicle is moving. Do not become distracted by the receiver while

driving, and always be fully aware of all driving conditions.

It is your responsibility to comply with all traffic laws and to use the Magellan RoadMate and

mounting options in such a manner that the user is in compliance with applicable laws.

Roads, points of interest (POIs), business and service locations may change over time. As a result

the database may contain inaccuracy. Also, the database does not include, analyze, process,

consider, or reflect any of the following: legal restrictions (such as vehicle type, weight, height,

width, load and speed restrictions); road slope or gradient;

bridge height, width, weight or other limits; population

density; neighborhood quality or safety; availability or

proximity of police, emergency rescue, medical or other

assistance; construction work zones or hazards; road

or lane closures; road, traffic or traffic facilities’ safety or

condition; weather conditions; pavement characteristics

or conditions; special events; traffic congestion. It is your

responsibility to disregard any unsafe, hazardous or illegal

route suggestions.

Keep the Magellan RoadMate receiver safe from extreme temperature conditions. For example, do

not leave it exposed to direct sunlight for an extended period of time.

Take care when mounting the Magellan RoadMate receiver in your vehicle, whether using the

windshield mount or other mounts, that it does not obstruct the driver’s view of the road, interfere

with the operation of the vehicle’s safety devices such as air bags, or present a hazard to occupants

of the vehicle should the receiver be dislodged while driving. It is your responsibility to assess the

risks associated with damage to your vehicle or vehicle occupants as the result of your choices in

mounting the Magellan RoadMate receiver.

Temperature

The maximum operating temperature is 140°F (60°C).

Battery

The battery in the Magellan RoadMate receiver is rechargeable and should not be removed. In the

event that it should need to be replaced, please contact Magellan Technical Support.

Charging the Magellan RoadMate

An optional AC adapter is available as an accessory for your Magellan RoadMate. Use of

Magellan RoadMate 6220T-LM

Tested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

RoadMate User Manual Page iii

another type of AC adapter can result in malfunction and/or possible fire hazard due to battery

overheating.

Use only the car charger approved for/supplied with your Magellan RoadMate receiver. Use of

another type of car charger will result in fire or electric shock.

For safety reasons, the battery in your Magellan RoadMate receiver will stop charging when the

ambient temperature is less than 32°F (0°C) or more than 113°F (45°C).

It will take approximately 4 hours of charging the Magellan RoadMate receiver through the vehicle

power adapter or optional AC adapter to obtain a full battery charge. It is recommended that you

charge the battery initially for at least 2 hours.

Use only the charger approved for your Magellan RoadMate receiver.

Estimated usage of the Magellan RoadMate on battery power is approximately .1 hour

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for class B digital devices,

in accordance with part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

FCC Caution:

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. End users must follow the specific operating instructions for satisfying RF exposure

compliance.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

In order to maintain compliance with FCC regulations, shielded cables must be used with this

equipment. Operation with non-approved equipment or unshielded cables is likely to result in

interference to radio and TV reception. The user is cautioned that changes and modifications
