Owner’s
Manual
Photo Tripod
DX-M
Photo Tripod Components
Thank you for choosing Magnus.
Congratulations on the purchase of your new Magnus
tripod. This tripod features a rapid center column
that detaches to serve as an adjustable four-section
monopod, and telescoping legs with flip-locks for fast
and easy leg adjustments. The three-way pan & tilt
head gives you total control over camera positioning,
and the quick-release plate features a 1/4”-20 male
thread for universal camera mounting. There is also
a bubble level to ensure that your shot is properly
aligned.
Please read and follow these instructions, and keep
this manual in a safe place.
Platform Orientation
Locking Knob
Universal ¼-20
Mounting Screw
Tilt/Pan Bar /
Tilt Lock
Center Column
Locking Knob
Foam Padding
Center Brace
Locking Collar
Retractable
Spiked Feet
Quick-Release
Mounting Plate
Pan Locking
Knob
Leg
Flip-Lock
Image is for illustration purposes only.
Features vary by model.
Center column/
monopod
Opening the Tripod
1 Always extend the legs from the top flip-locks first.
Pull out on each flip-lock and extend the legs to the
desired height. Close each flip-lock. (See Figs. A-B.)
2 Rotate the locking
collar counterclockwise
to release the center
brace, and gently pull
the legs out. Push
down on the center
brace, and then rotate
the locking collar
clockwise to lock the
legs in place (Fig. C).
Mounting the Quick-Release Plate to the
Camera
1 To remove the quick-release plate from the tripod
head, use your thumb to turn out and hold the plate
locking lever and remove the quick-release plate
(Fig. D).
2 Line up the quick-release plate lengthwise with the
bottom of the camera. Match the quick-release
plate screw to the camera’s mounting thread, and
mount the plate to the camera by flipping out the
D-ring handle to rotate the screw clockwise until
snug (Fig. E).
3 Press down on the D-ring so that it is flat against
the bottom of the quick-release plate. Mount the
camera/quick-release plate assembly to the tripod
Figure A Figure B
Figure EFigure D
Figure C
