Sida 1/80
GB Battery adapter Instruction Manual
F Adaptateur de batterie Manuel d’instructions
D Akku-Adapter Gebrauchsanleitung
I Adattatore per batterie Istruzioni per l’uso
NL Accuadapter Gebruiksaanwijzing
E Adaptadora de batería Manual de instrucciones
P Adaptador de bateria Manual de instruções
BZ Adaptador de bateria Manual de instruções
DK Akku-adapter Brugervejledning
GR Προσαρμογέας μπαταριών Εγχειρίδιο οδηγιών
TR Batarya adaptörü Kullanım Kılavuzu
S Batteriadapter Bruksanvisning
N Batteriadapter Bruksanvisning
FIN Akkuadapteri Käyttöohje
LV Akumulatoru pārveidotājs Lietošanas rokasgrāmata
LT Akumuliatorių adapteris Naudojimo instrukcija
EE KasutusjuhendAkumuundur
PL Adapter akumulatora Instrukcja obsługi
HU Akkumulátor adapter Használati útmutató
SK Adaptér batérií Návod na obsluhu
CZ Akumulátorový konvertor Návod k použití
SI Adapter za baterije Navodila za uporabo
AL Përshtatësi i baterisë Manual Udhëzimi
BG Адаптер за акумулаторни батерии Упътване за работа
HR Upute za korištenjeAdapter za akumulator
MK Конвертер на батерии Упатство за работа
RO Transformator cu baterii Manual de instrucţiuni
RS Адаптер за батеријe Упутство за употребу
RUS Переходник зарядного устройства
Инструкция по эксплуатации
UA Адаптер для акумуляторів Інструкція з експлуатації
CS 电池连接转换器 使用说明书
CT
KR 배터리 아답타 사용 설명서
ID Adapter baterai Buku Petunjuk
VI Cục sạn pin Hướng dẫn sử dụng
TH
PR
AR
BAP182
2
1
2 3
4 5
6
7
8
10
7
89
11
12
13
14
15
1
2
3
4
5
6
3
1 Cover
2 Battery
3 Lock lever
4 Product
5 Product mounting adapter
6 Cord
7 Hook
8 Belt
9 Screw
10 Shoulder strap
11 Battery capacity display button
12 Remaining battery capacity
indication lamp for Battery 1
13 Remaining battery capacity
indication lamp for Battery 2
14 Battery 1
15 Battery 2
English (Original instructions)
Explanation of general view
Applications
This battery adapter enables the main unit and batteries to be separated, making it suitable for work performed over
long times, etc.
This battery adapter uses two 18 V batteries, and can be used with 36 V battery-powered products.
Compatible battery: BL1815N, BL1820, BL1820B, BL1830, BL1840, BL1840B, BL1850, BL1850B
NOTE:
• BL1815 cannot be used with the battery adapter.
CAUTION:
• Be sure to carefully read the product main unit instruction manual before use.
• This battery adapter is designed exclusively for use with 18 V batteries. Do not use 14.4 V batteries.
• Install two 18 V batteries for use. This battery adapter cannot be used with only one 18 V battery.
• Do not pick up or carry the battery adapter by holding only the cord.
• Do not insert the product mounting adapter into the charger. Charging is not possible in this case.
• During operation, keep the cord away from obstacles such as branches. The cord caught by obstacles may cause
serious injury.
• During operation, keep the cord away from obstacles. When using with a circular saw, the caught cord may pull the
tool, leading to a kick-back and serious injury.
• Always be sure that the battery cartridges are removed before attempting to perform inspection or maintenance such
as replacing a saw blade.
• Never use the battery adapter together with a single-18 V battery-operated tool.
Installing the batteries (Fig. 1 & 2)
CAUTION:
• Be careful not to pinch your fingers with the cover when inserting the batteries.
• Be careful not to drop the batteries when removing them.
• Be careful when removing the batteries with the batteries facing downward, as they may fall out and drop.
1. Slide the lock lever of the adapter used to house the 18 V batteries, and open the cover.
2. Insert the batteries firmly all the way, until the red color of the button is no longer visible.
3. Be sure to secure the cover with the lock lever.
4. Set the hook onto your belt, etc. (Fig. 3)
5. Attach the product mounting adapter to the product.
6. You can also remove the hook and pass the belt through it as shown in the illustration.
Attaching the optional shoulder strap
The optional shoulder strap can be attached as shown in the illustration. (Fig. 4)
Operation
Attach the battery adapter to your body for work as shown in the illustration. (Fig. 5)
