GB Cordless Oil-impulse Driver INSTRUCTION MANUAL

Batteridriven hydraulisk slagskruvdragare

BRUKSANVISNING

N Batteridrevet oljeimpulsskrutrekker BRUKSANVISNING

FIN

Akkukäyttöinen öljyimpulssiväännin

KÄYTTÖOHJE

LV Bezvada eļļas triecienskrūvgriezis LIETOŠANAS INSTRUKCIJA

Belaidis hidraulinis smūginis suktuvas

NAUDOJIMO INSTRUKCIJA

EE Juhtmeta õli-impulsskruvikeeraja KASUTUSJUHEND

RUS

Аккумуляторный масляно-импульсный

шуруповерт

РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ

BTS130

1 012131

2 012128

3 006796

4 006797

5 6 006798 004521

1 2

7 011406

1 2 3

8 011407

9 006592

10 006843

11 006258

12 006799

2 3

13 006260

14 006261

15 006304

ENGLISH (Original instructions)

Explanation of general view

1-1. Battery cartridge

1-2. Button

1-3. Red indicator

2-1. Star marking

3-1. Switch trigger

4-1. Lamp

5-1. Reversing switch lever

7-1. Bit

7-2. Sleeve

8-1. Bit

8-2. Bit-piece

8-3. Sleeve

9-1. Screw

9-2. Hook

9-3. Groove

10-1. Air vents

10-2. Cooling down oil unit

11-1. Limit mark

12-1. Rear cover

12-2. Screws

13-1. Spring

13-2. Arm

13-3. Recessed part

14-1. Carbon brush cap

15-1. Hole

15-2. Carbon brush cap

SPECIFICATIONS

Model BTS130

Machine screw M4 - M8

Standard bolt M6 - M10

Capacities

High tensile bolt M6 - M8

No load speed (min-1) 0 - 2,400

Impacts per minute (min

-1) 0 - 1,600

Overall length 183 mm

Net weight 1.7 kg

Rated voltage D.C.14.4 V

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

• Specifications and battery cartridge may differ from country to country.

• Weight, with battery cartridge, according to EPTA-Procedure 01/2003

ENE033-1

Intended use

The tool is intended for screw driving in wood, metal and

plastic.

ENG905-1

Noise

The typical A-weighted noise level determined according

to EN60745:

Sound pressure level (L

pA) : 79 dB(A)

Uncertainty (K) : 3 dB(A)

The noise level under working may exceed 80 dB (A).

Wear ear protection

ENG900-1

Vibration

The vibration total value (tri-axial vector sum) determined

according to EN60745:

Work mode : impact tightening of fasteners of the

maximum capacity of the tool

Vibration emission (ah) : 17.5 m/s2

Uncertainty (K) : 2.0 m/s2

ENG901-1

• The declared vibration emission value has been

measured in accordance with the standard test

method and may be used for comparing one tool

with another.

• The declared vibration emission value may also be

used in a preliminary assessment of exposure.

WARNING:

• The vibration emission during actual use of the

power tool can differ from the declared emission

value depending on the ways in which the tool is

used.

• Be sure to identify safety measures to protect the

operator that are based on an estimation of

exposure in the actual conditions of use (taking

account of all parts of the operating cycle such as

the times when the tool is switched off and when it

is running idle in addition to the trigger time).

ENH101-15

For European countries only

EC Declaration of Conformity

We Makita Corporation as the responsible

manufacturer declare that the following Makita

machine(s):

Designation of Machine:

Cordless Oil-impulse Driver

Model No./ Type: BTS130

are of series production and

Conforms to the following European Directives:

2006/42/EC

And are manufactured in accordance with the following

standards or standardised documents:

EN60745
