Makita DK18041 Bruksanvisning

Makita Borrmaskin DK18041

Läs nedan 📖 manual på svenska för Makita DK18041 (10 sidor) i kategorin Borrmaskin. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/10
GB Cordless Driver Drill Instruction manual
F Perceuse-Visseuse sans Fil Manuel d’instructions
D Akku-Bohrschrauber Betriebsanleitung
I Trapano avvitatore a batteria Istruzioni per l’uso
NL Accuschroef-boormachine Gebruiksaanwijzing
E Atornillador Taladro Manual de instrucciones
Inalámbrico
P Furadeira/ Parafusadeira a Manual de instruções
Bateria
DK Akku bore-skruemaskine Brugsanvisning
GR Δραπανοκατσάβιδο μπαταρίας Οδηγίες χρήσης
DF347D
DF457D
2
1 2
3 4
5 6
7
1
23
4
5
AB6
7
8
9
10
3
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing programme of research and development, the specifications herein are subject to change without
notice.
• Specifications and battery cartridge may differ from country to country.
• Weight, with battery cartridge, according to EPTA-Procedure 01/2003
Intended use ENE034-1
The tool is intended for drilling and screw driving in wood,
metal and plastic.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
CORDLESS DRILL SAFETY
WARNINGS GEB051-2
1. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
2. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring. Cutting
accessory contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
3. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
4. Hold the tool firmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the drill bit or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
8. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation and
skin contact. Follow material supplier safety data.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to safety
rules for the subject product. MISUSE or failure to
follow the safety rules stated in this instruction
manual may cause serious personal injury.
IMPORTANT SAFETY
INSTRUCTIONS ENC009-1
FOR BATTERY CARTRIDGE
1. Before using battery cartridge, read all
instructions and cautionary markings on (1)
battery charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively shorter,
stop operating immediately. It may result in a risk
of overheating, possible burns and even an
explosion.
4. If electrolyte gets into your eyes, rinse them out
with clear water and seek medical attention right
away. It may result in loss of your eyesight.
1. Red indicator
2. Button
3. Battery cartridge
4. Switch trigger
5. Reversing switch lever
6. Speed change lever
7. Adjusting ring
8. Graduation
9. Arrow
10. Sleeve
Model DF347D DF457D
Capacities
Steel 10 mm 13 mm
Wood 25 mm 36 mm
Wood screw 5.1 x 63 mm 6 mm x 75 mm
Machine screw 6 mm
No load speed (min-1)High (2) 0 - 1,400
Low (1) 0 - 400
Overall length North/South America 198 mm 228 mm
Other countries 221 mm
Net weight 1.4 kg 1.7 kg
Rated voltage D.C. 14.4 V D.C. 18 V

Produktspecifikationer

Varumärke: Makita
Kategori: Borrmaskin
Modell: DK18041
