INSTRUCTION MANUAL
Cordless Chain Saw
DUC305
DUC355
DUC405
ENGLISH: Original instructions
Read before use.
2 ENGLISH
SPECIFICATIONS
Model: DUC305 DUC355 DUC405
Overall length (without guide bar) 443 mm
Rated voltage D.C. 36 V
Net weight 4.6 - 5.5 kg
Standard guide bar length 300 mm 350 mm 400 mm
Recommended guide bar length 300 - 400 mm
Applicable saw chain type
(refer to the table below)
90PX
91PX
Sprocket Number of teeth 6
Pitch 3/8″
Chain speed 0 - 20 m/s
(0 - 1,200 m/min)
Chain oil tank volume 200 cm
3
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge
BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 / BL1840B / BL1850 / BL1850B / BL1860B
• Some of the battery cartridges listed above may not be available depending on your region of residence.
WARNING: Only use the battery cartridges listed above. Use of any other battery cartridges may cause
injuryand/orre.
Saw chain and guide bar
Saw chain type 90PX
Number of drive links 46 52 56
Guide bar Guide bar length 300 mm 350 mm 400 mm
Cutting length 275 mm 330 mm 370 mm
Pitch 3/8″
Gauge 1.1 mm
Type Sprocket nose bar
Saw chain type 91PX
Number of drive links 46 52 56
Guide bar Guide bar length 300 mm 350 mm 400 mm
Cutting length 275 mm 330 mm 370 mm
Pitch 3/8″
Gauge 1.3 mm
Type Sprocket nose bar
WARNING:Useappropriatecombinationoftheguidebarandsawchain.Otherwisepersonalinjurymay
result.
Symbols
The following show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
Wear safety glasses.
Wear ear protection.
3 ENGLISH
Wear a helmet, goggles and ear protection.
Use appropriate protection for foot-leg and
hand-arm.
Do not expose to moisture.
Maximum permissible cut length
Direction of chain travel
Sawchainoiladjustment
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or battery
pack together with household waste material!
In observance of the European Directives,
on Waste Electric and Electronic Equipment
and Batteries and Accumulators and Waste
Batteries and Accumulators and their imple-
mentation in accordance with national laws,
electric equipment and batteries and battery
pack(s) that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility.
Intended use
This chain saw is intended for sawing wood.
Noise
The typical A-weighted noise level determined accord-
ing to EN60745-2-13:
Model DUC305
Sound pressure level (LpA) : 87.7 dB(A)
Sound power level (LWA) : 100.4 dB (A)
Uncertainty (K) : 2 dB(A)
Model DUC355
Sound pressure level (LpA) : 87.7 dB(A)
Sound power level (LWA) : 100.4 dB (A)
Uncertainty (K) : 2 dB(A)
Model DUC405
Sound pressure level (LpA) : 87.7 dB(A)
Sound power level (LWA) : 100.4 dB (A)
Uncertainty (K) : 2 dB(A)
WARNING: Wear ear protection.
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN60745-2-13:
Model DUC305
Work mode: cutting wood
Vibration emission (ah,W) : 5.3 m/s2
Uncertainty (K) : 1.5 m/s2
Model DUC355
Work mode: cutting wood
Vibration emission (ah,W) : 5.3 m/s2
Uncertainty (K) : 1.5 m/s2
Model DUC405
Work mode: cutting wood
Vibration emission (ah,W) : 5.3 m/s2
Uncertainty (K) : 1.5 m/s2
NOTE:
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
NOTE:
The declared vibration emission value may
also be used in a preliminary assessment of exposure.
WARNING:
The vibration emission during actual
use of the power tool can differ from the declared emission
value depending on the ways in which the tool is used.
WARNING:
Be sure to identify safety measures to pro-
tect the operator that are based on an estimation of exposure
in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off
and when it is running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
The EC declaration of conformity is included as Annex A
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodiedplugsandmatchingoutletswill
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
