Instruction Manual
Original Instruction Manual
Important:
Read this instruction manual carefully before putting the chain saw into operation and strictly observe the
safety regulations!
Keep this instruction manual!
EA3500S
EA3501S
EA3502S
EA3503S
2
Thank you for purchasing a MAKITA product!
Congratulations on choosing a MAKITA chain saw! We are
conÞ dent that you will be satisÞ ed with this modern piece of
equipment. The EA3500S-EA3503S are very handy and robust
chain saws with a new Design.
The automatic chain lubrication with variable-ß ow oil pump
and maintenance-free electronic ignition ensure trouble-free
operation, while the hand-saving anti-vibration system and
ergonomic grips and controls make work easier, safer, and
less tiring for the user.
The Featherlight-Start system lets you start the saw effortlessly
with a spring-loaded starting assist.
For some countries the saw is also equipped with a catalytic
converter. This reduces the amount of pollutants in the exhaust,
and meets European Guideline 2002/88/EG.
MAKITA chain saws EA3500S-EA3503S are equipped with the
latest safety features and meet all national and international
standards. These features include: hand guards on both handles,
grip throttle lever lock, chain catch, safety saw chain, and chain
brake. The chain brake can be actuated manually, and is also
inertia-actuated automatically in case of kickback.
The following industrial property rights apply:
DE 101 32 973, DE 20 2008 006 013, DE 20 2009 013 953,
DE 203 19 902, DE 203 01 182, DE 197 22 629, DE 10 2007
039 028, DE 10 2007 038 199.
In order to ensure the proper functioning and performance
of your new chain saw, and to safeguard your own per-
sonal safety, it is imperative that you read this instruction
manual thoroughly before operation. Be especially careful
to observe all safety precautions! Failure to observe these
precautions can lead to severe injury or death!
Table of contents Page
Delivery inventory .............................................................. 3
Symbols ............................................................................... 3
SAFETY PRECAUTIONS
General precautions .......................................................4
Protective equipment ...................................................... 4
Fuels / Refuelling ............................................................ 5
Putting into operation ......................................................5
Kickback .........................................................................6
Working behavior/Method of working ...........................6-7
Transport and storage .....................................................8
Maintenance ................................................................... 8
First aid ........................................................................... 8
Technical data .....................................................................9
Packing ................................................................................ 9
Denomination of components ......................................... 10
PUTTING INTO OPERATION
Only for models with fastening nuts on the sprocket
guard
Mounting the guide bar and saw chain .................... 11-12
Tightening the saw chain .............................................. 12
Checking the chain tension ............................................ 13
Retightening the saw chain ........................................... 13
Only for the QuickSet guide bar
Mounting the guide bar and saw chain ....................14-15
Tightening the saw chain .............................................. 15
Checking the chain tension ........................................... 15
Retightening the saw chain ........................................... 15
Only for models with quick tensioner on sprocket guard
Mounting the guide bar and saw chain ....................16-17
Tightening the saw chain .............................................. 17
Checking the chain tension ........................................... 18
Retightening the saw chain ........................................... 18
Chain brake ..................................................................18
Fuels ........................................................................19-20
Refuelling ......................................................................20
Checking the chain lubrication ......................................21
Adjusting the chain lubrication ...................................... 21
Starting the engine ........................................................ 22
Cold start ......................................................................22
Warm start .................................................................... 22
Stopping the engine ......................................................22
Checking the chain brake ............................................. 23
Adjusting the carburetor .................................................. 24
MAINTENANCE
Sharpening the saw chain .......................................25-26
Cleaning the inside of the sprocket guard .................... 27
Cleaning the guide bar .................................................. 27
Replacing the saw chain ...............................................28
Cleaning the air Þ lter ..................................................... 29
Replacing the spark plug ..............................................30
Checking the ignition spark ........................................... 30
Checking the mufß er screws ......................................... 30
Replacing the starter cable/Replacing the return spring
cassette/Replacing the Featherlight -Start spring .........31
Mounting the fan housing .............................................31
Cleaning the air Þ lter compartment/fan compartment ... 32
Cleaning the cylinder Þ ns .............................................. 32
Replacing the suction head ..........................................32
Instructions for periodic maintenance ........................... 33
Service, spare parts and guarantee ................................ 34
Trouble shooting ..............................................................35
Extract from spare parts list ....................................... 36-37
Accessories .............................................................36-37
EU conformity declaration ............................................... 38
3
4
5 6
32
1
Delivery inventory
1. Chain saw
2. Guide bar
3. Saw chain
4. Chain protection cover
5. Universal wrench
6. Screwdriver for carburetor adjustment
7. Instruction manual (not shown)
In case one of the parts listed should not be included in the
delivery inventory, please consult your sales agent.
Symbols
You will notice the following symbols on the saw and in the Instruction Manual:
Caution, kickback!
Chain brake
Fuel and oil mixture
Carburetor adjustment
Chain oil Þ ll/oil pump
Saw chain oil
adjustment screw
First aid
Recycling
CE - Marking
Read instruction manual and
follow the warning- and safety
precautions!
Particular care
and caution!
Forbidden!
Wear protective helmet,
eye and ear protection!
Wear protective
gloves!
No smoking!
No open Þ re!
Stop engine!
Start engine
Combination switch,
Choke ON/STOP
Safety position
Produktspecifikationer
| Varumärke: | Makita |
| Kategori: | Sågmaskin |
| Modell: | EA3502S |
