INSTRUCTION MANUAL

Cordless Rotary Hammer

HR140D

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: HR140D

Drilling capacities 14 mmConcrete

Steel 10 mm

Wood 13 mm

No load speed 0 - 850 min-1

Blows per minute 0 - 4,900 min-1

Overall length 246 mm

Rated voltage D.C. 10.8 V - 12 V max

Standard battery cartridge BL1015 / BL1016 / BL1020B / BL1021B / BL1040B / BL1041B

Net weight 1.9 - 2.6 kg

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsandbatterycartridgemaydifferfromcountrytocountry.

• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.

Symbols

Thefollowingshowthesymbolsusedfortheequipment.

Be sure that you understand their meaning before use.

Read instruction manual.

Ni-MH

Li-ion

Only for EU countries

Donotdisposeofelectricequipmentorbattery

pack together with household waste material!

In observance of the European Directives,

on Waste Electric and Electronic

EquipmentandBatteriesandAccumulators

andWasteBatteriesandAccumulators

and their implementation in accordance

withnationallaws,electricequipmentand

batteriesandbatterypack(s)thathave

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

Thetoolisintendedforhammerdrillinganddrillingin

brick, concrete and stone.

It is also suitable for drilling without impact in wood,

metal, ceramic and plastic.

Noise

ThetypicalA-weightednoiseleveldeterminedaccord-

ing to EN60745:

Soundpressurelevel(L

pA):84dB(A)

Soundpowerlevel(L

WA):95dB(A)

Uncertainty(K):3dB(A)

WARNING: Wear ear protection.

Vibration

Thevibrationtotalvalue(tri-axialvectorsum)deter-

mined according to EN60745:

Work mode: hammer drilling into concrete

Vibrationemission(ah, HD):6.5m/s2

Uncertainty(K):1.5m/s2

Work mode: drilling into metal

Vibrationemission(a

h,D):3.0m/s2 or less

Uncertainty(K):1.5m/s

NOTE:

Thedeclaredvibrationemissionvaluehasbeen

measured in accordance with the standard test method

and may be used for comparing one tool with another.

NOTE:

Thedeclaredvibrationemissionvaluemay

also be used in a preliminary assessment of exposure.

WARNING:

Thevibrationemissionduringactual

use of the power tool can differ from the declared emission

value depending on the ways in which the tool is used.

WARNING:

Be sure to identify safety measures to pro-

tect the operator that are based on an estimation of exposure

intheactualconditionsofuse(takingaccountofallpartsofthe

operating cycle such as the times when the tool is switched off

andwhenitisrunningidleinadditiontothetriggertime).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING:

Read all safety warnings, instruc-

tions, illustrations and specications provided with this

power tool. Failure to follow all instructions listed below

mayresultinelectricshock,reand/orseriousinjury.

Save all warnings and instruc-

tions for future reference.

Theterm"powertool"inthewarningsreferstoyour

mains-operated(corded)powertoolorbattery-operated

(cordless)powertool.

3 ENGLISH

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiedplugsandmatchingoutletswill

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators.Thereisanincreasedriskofelec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions. Water entering a power tool will increase

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

5. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of

electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

7. Power tools can produce electromagnetic

elds (EMF) that are not harmful to the user.

However, users of pacemakers and other similar

medical devices should contact the maker of their

device and/or doctor for advice before operating

this power tool.

Personal Safety

1. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the inuence of drugs, alcohol or med-

ication.Amomentofinattentionwhileoperating

powertoolsmayresultinseriouspersonalinjury.

2. Use personal protective equipment. Always

wear eye protection.Protectiveequipmentsuch

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

willreducepersonalinjuries.

3. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

yourngerontheswitchorenergisingpowertools

that have the switch on invites accidents.

4. Remove any adjusting key or wrench before

turning the power tool on.Awrenchorakeyleft

attached to a rotating part of the power tool may

resultinpersonalinjury.

5. Do not overreach. Keep proper footing and

balance at all times.Thisenablesbettercontrol

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair and clothing away

from moving parts.Looseclothes,jewelleryor

long hair can be caught in moving parts.

7. If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used. Use of

dust collection can reduce dust-related hazards.

Do not let familiarity gained from frequent use

of tools allow you to become complacent and

ignore tool safety principles.Acarelessactioncan

causesevereinjurywithinafractionofasecond.

9. Always wear protective goggles to protect

your eyes from injury when using power tools.

The goggles must comply with ANSI Z87.1 in

the USA, EN 166 in Europe, or AS/NZS 1336

in Australia/New Zealand. In Australia/New

Zealand, it is legally required to wear a face

shield to protect your face, too.

It is an employer's responsibility to enforce

the use of appropriate safety protective equip-

ments by the tool operators and by other per-

sons in the immediate working area.

Power tool use and care

1. Do not force the power tool. Use the correct

power tool for your application.Thecorrect

powertoolwilldothejobbetterandsaferatthe

rate for which it was designed.

Do not use the power tool if the switch does not turn

it on and off.Anypowertoolthatcannotbecontrolled

with the switch is dangerous and must be repaired.

3. Disconnect the plug from the power source

and/or remove the battery pack, if detachable,

from the power tool before making any adjust-

ments, changing accessories, or storing power

tools. Such preventive safety measures reduce

the risk of starting the power tool accidentally.

Store idle power tools out of the reach of children and

do not allow persons unfamiliar with the power tool

or these instructions to operate the power tool. Power

tools are dangerous in the hands of untrained users.

Maintain power tools and accessories. Check for

misalignment or binding of moving parts, break-

age of parts and any other condition that may

affect the power tool’s operation. If damaged, have

the power tool repaired before use. Many accidents

are caused by poorly maintained power tools.
