INSTRUCTION MANUAL

Circular Saw

HS0600

ENGLISH: Original instructions

DOUBLE INSULATION

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: HS0600

Blade diameter 255 mm 260 mm 270 mm

Max. Cutting depth at 0° 94 mm 97 mm 101 mm

at 45° bevel 65 mm 68 mm 71 mm

at 50° bevel 59 mm 61 mm 63 mm

No load speed 4,300 min-1

Overall length 418 mm

Net weight 6.9 kg

Safety class /II

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsmaydifferfromcountrytocountry.

• WeightaccordingtoEPTA-Procedure01/2014

Symbols

The following show the symbols used for the equip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

DOUBLE INSULATION

Only for EU countries

Do not dispose of electric equipment

together with household waste material! In

observance of the European Directive, on

WasteElectricandElectronicEquipment

and its implementation in accordance with

national law, electric equipment that have

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

The tool is intended for performing lengthways and

crossways straight cuts and mitre cuts with angles in

woodwhileinrmcontactwiththeworkpiece.With

appropriate Makita genuine saw blades, other materials

can also be sawed.

Power supply

The tool should be connected only to a power supply of

the same voltage as indicated on the nameplate, and

can only be operated on single-phase AC supply. They

are double-insulated and can, therefore, also be used

from sockets without earth wire.

For public low-voltage distribution

systems of between 220 V and 250 V

Switching operations of electric apparatus cause voltage

uctuations.Theoperationofthisdeviceunderunfavor-

able mains conditions can have adverse effects to the

operationofotherequipment.Withamainsimpedance

equal or less than 0.28 Ohms it can be presumed that

there will be no negative effects. The mains socket used

for this device must be protected with a fuse or protec-

tive circuit breaker having slow tripping characteristics.

Noise

The typical A-weighted noise level determined accord-

ing to 62841-2-5:

Sound pressure level (L

pA) : 94 dB(A)

Sound power level (L

WA) : 105 dB (A)

Uncertainty (K) : 3 dB(A)

WARNING: Wear ear protection.

Vibration

The vibration total value (tri-axial vector sum) deter-

mined according to 62841-2-5:

Workmode:cuttingwood

Vibration emission (a

h,W) : 2.5 m/s2 or less

Uncertainty (K) : 1.5 m/s

NOTE:

The declared vibration emission value has been

measured in accordance with the standard test method

and may be used for comparing one tool with another.

NOTE:

The declared vibration emission value may

also be used in a preliminary assessment of exposure.

WARNING:

The vibration emission during actual

use of the power tool can differ from the declared emission

value depending on the ways in which the tool is used.

WARNING:

Be sure to identify safety measures to pro-

tect the operator that are based on an estimation of exposure

in the actual conditions of use (taking account of all parts of the

operating cycle such as the times when the tool is switched off

and when it is running idle in addition to the trigger time).

3 ENGLISH

EC Declaration of Conformity

For European countries only

The EC declaration of conformity is included as Annex A

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING: Read all safety warnings, instruc-

tions, illustrations and specications provided

with this power tool. Failure to follow all instructions

listedbelowmayresultinelectricshock,reand/or

seriousinjury.

Save all warnings and instruc-

tions for future reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust.Powertoolscreatesparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiedplugsandmatchingoutletswill

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of elec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions.Waterenteringapowertoolwillincrease

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

5. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of

electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

7. Use of power supply via an RCD with a rated

residual current of 30 mA or less is always

recommended.

Personal Safety

1. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the inuence of drugs, alcohol or med-

ication. A moment of inattention while operating

powertoolsmayresultinseriouspersonalinjury.

2. Use personal protective equipment. Always

wear eye protection.Protectiveequipmentsuch

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

willreducepersonalinjuries.

3. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

yourngerontheswitchorenergisingpowertools

that have the switch on invites accidents.

4. Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may

resultinpersonalinjury.

5. Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair and clothing away

from moving parts.Looseclothes,jewelleryor

long hair can be caught in moving parts.

7. If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used. Use of

dust collection can reduce dust-related hazards.

8. Do not let familiarity gained from frequent use

of tools allow you to become complacent and

ignore tool safety principles. A careless action

cancausesevereinjurywithinafractionofa

second.

Power tool use and care

1. Do not force the power tool. Use the correct

power tool for your application. The correct

powertoolwilldothejobbetterandsaferatthe

rate for which it was designed.

2. Do not use the power tool if the switch does

not turn it on and off. Any power tool that cannot

be controlled with the switch is dangerous and

must be repaired.

3. Disconnect the plug from the power source

and/or remove the battery pack, if detachable,

from the power tool before making any adjust-

ments, changing accessories, or storing power

tools. Such preventive safety measures reduce

the risk of starting the power tool accidentally.

4. Store idle power tools out of the reach of chil-

dren and do not allow persons unfamiliar with

the power tool or these instructions to operate

the power tool.Powertoolsaredangerousinthe

hands of untrained users.

5. Maintain power tools and accessories. Check

for misalignment or binding of moving parts,

breakage of parts and any other condition that

may affect the power tool’s operation. If dam-

aged, have the power tool repaired before use.

Many accidents are caused by poorly maintained

power tools.
