INSTRUCTION MANUAL

Cordless Jig Saw

JV102D

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: JV102D

Length of stroke 23 mm

Strokes per minute 800 - 3,000 min-1

Blade type B type

Max. cutting capacities 90 mmWood

Mild steel 10 mm

Aluminum 20 mm

Overall length 237 mm

Rated voltage D.C. 10.8 V - 12 V max

Standard battery cartridge BL1015 / BL1016 / BL1020B / BL1021B / BL1040B / BL1041B

Net weight 1.8 - 1.9 kg

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsandbatterycartridgemaydifferfromcountrytocountry.

• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.

Symbols

Thefollowingshowthesymbolsusedfortheequip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

Ni-MH

Li-ion

Only for EU countries

Donotdisposeofelectricequipmentor

battery pack together with household waste

material!

In observance of the European Directives,

on Waste Electric and Electronic

EquipmentandBatteriesandAccumulators

and Waste Batteries and Accumulators

and their implementation in accordance

withnationallaws,electricequipmentand

batteriesandbatterypack(s)thathave

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

Thetoolisintendedforthesawingofwood,plasticand

metal materials. As a result of the extensive accessory

and saw blade program, the tool can be used for many

purposes and is very well suited for curved or circular

cuts.

Noise

ThetypicalA-weightednoiseleveldeterminedaccord-

ing to EN60745:

Soundpressurelevel(L

pA):85dB(A)

Soundpowerlevel(L

WA):96dB(A)

Uncertainty(K):3dB(A)

WARNING: Wear ear protection.

Vibration

Thevibrationtotalvalue(tri-axialvectorsum)deter-

mined according to EN60745:

Work mode: cutting boards

Vibrationemission(a

h,B):11.5m/s2

Uncertainty(K):1.5m/s

Work mode: cutting sheet metal

Vibrationemission(a

h,M):9.5m/s2

Uncertainty(K):1.5m/s

NOTE:Thedeclaredvibrationemissionvaluehas

been measured in accordance with the standard test

method and may be used for comparing one tool with

another.

NOTE:Thedeclaredvibrationemissionvalue

may also be used in a preliminary assessment of

exposure.

WARNING:Thevibrationemissionduringactual

use of the power tool can differ from the declared

emission value depending on the ways in which the

tool is used.

WARNING: Be sure to identify safety measures

to protect the operator that are based on an estima-

tionofexposureintheactualconditionsofuse(taking

account of all parts of the operating cycle such as

the times when the tool is switched off and when it is

runningidleinadditiontothetriggertime).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

3 ENGLISH

SAFETY WARNINGS

General power tool safety warnings

WARNING:

Read all safety warnings, instruc-

tions, illustrations and specications provided with this

power tool. Failure to follow all instructions listed below

mayresultinelectricshock,reand/orseriousinjury.

Save all warnings and instruc-

tions for future reference.

Theterm"powertool"inthewarningsreferstoyour

mains-operated(corded)powertoolorbattery-operated

(cordless)powertool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiedplugsandmatchingoutletswill

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators.Thereisanincreasedriskofelec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions. Water entering a power tool will increase

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a cord

suitable for outdoor use reduces the risk of electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

Power tools can produce electromagnetic elds

(EMF) that are not harmful to the user. However,

users of pacemakers and other similar medical

devices should contact the maker of their device and/

or doctor for advice before operating this power tool.

Personal Safety

Stay alert, watch what you are doing and use

common sense when operating a power tool. Do

not use a power tool while you are tired or under

the inuence of drugs, alcohol or medication. A

moment of inattention while operating power tools

mayresultinseriouspersonalinjury.

2. Use personal protective equipment. Always

wear eye protection.Protectiveequipmentsuch

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

willreducepersonalinjuries.

3. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

yourngerontheswitchorenergisingpowertools

that have the switch on invites accidents.

4. Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may

resultinpersonalinjury.

5. Do not overreach. Keep proper footing and

balance at all times.Thisenablesbettercontrol

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair and clothing away

from moving parts.Looseclothes,jewelleryor

long hair can be caught in moving parts.

7. If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used. Use of

dust collection can reduce dust-related hazards.

Do not let familiarity gained from frequent use

of tools allow you to become complacent and

ignore tool safety principles. A careless action can

causesevereinjurywithinafractionofasecond.

Power tool use and care

1. Do not force the power tool. Use the correct

power tool for your application.Thecorrect

powertoolwilldothejobbetterandsaferatthe

rate for which it was designed.

2. Do not use the power tool if the switch does

not turn it on and off. Any power tool that cannot

be controlled with the switch is dangerous and

must be repaired.

3. Disconnect the plug from the power source

and/or remove the battery pack, if detachable,

from the power tool before making any adjust-

ments, changing accessories, or storing power

tools. Such preventive safety measures reduce

the risk of starting the power tool accidentally.

4. Store idle power tools out of the reach of chil-

dren and do not allow persons unfamiliar with

the power tool or these instructions to operate

the power tool. Power tools are dangerous in the

hands of untrained users.

Maintain power tools and accessories. Check for

misalignment or binding of moving parts, break-

age of parts and any other condition that may

affect the power tool’s operation. If damaged, have

the power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

6. Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

7. Use the power tool, accessories and tool bits

etc. in accordance with these instructions, tak-

ing into account the working conditions and

the work to be performed. Use of the power tool

for operations different from those intended could

result in a hazardous situation.
