ENGLISH (Original instructions)

INSTRUCTION MANUAL

DOUBLE INSULATION

IMPORTANT: Read Before Using.

Compound Miter Saw

LS1040

LS1040S

012678

ENGLISH (Original instructions)

SPECIFICATIONS

Model LS1040 / LS1040S

Blade diameter 255 mm -260 mm

Blade body thickness 1.6 mm - 2.4 mm

Hole diameter

For all countries other than European countries 25.4 mm and 25 mm

For European countries 30 mm

Max. Cutting capacities (H x W) with blade 260 mm in diameter

Miter angle

Bevel angle 0° 45° (left and right)

93 mm x 95 mm 93 mm x 67 mm

0° 69 mm x 135 mm 69 mm x 95 mm

53 mm x 95 mm 49 mm x 67 mm

45° (left) 35 mm x 135 mm 35 mm x 94 mm

No load speed (min-1) 4,600

Dimensions (L x W x H) 530 mm x 476 mm x 532 mm

Net weight 12.4 kg

Safety class /II

• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

• Specifications may differ from country to country.

• Weight according to EPTA-Procedure 01/2003

END217-3

Symbols

The following show the symbols used for the equipment.

Be sure that you understand their meaning before use.

･ Read instruction manual.

･ DOUBLE INSULATION

･ To avoid injury from flying debris, keep

holding the saw head down, after

making cuts, until the blade has come to

a complete stop.

･ Do not place hand or fingers close to the

blade.

･ For your safety, remove the chips, small

pieces, etc. from the table top before

operation.

･ Always set SUB-FENCE to left position

when performing left bevel cuts. Failure

to do so may cause serious injury to

operator.

･ To loosen the bolt, turn it clockwise.

･ Only for EU countries

Do not dispose of electric equipment

together with household waste material!

In observance of European Directive

2002/96/EC on waste electric and

electronic equipment and its

implementation in accordance with

national law, electric equipment that

have reached the end of their life must

be collected separately and returned to

an environmentally compatible recycling

facility.

ENE004-1

Intended use

The tool is intended for accurate straight and miter

cutting in wood. With appropriate saw blades, aluminum

can also be sawed.

ENF002-2

Power supply

The tool should be connected only to a power supply of

the same voltage as indicated on the nameplate, and can

only be operated on single-phase AC supply. They are

double-insulated and can, therefore, also be used from

sockets without earth wire.

For Model LS1040

ENF100-1

For public low-voltage distribution systems of

between 220 V and 250 V.

Switching operations of electric apparatus cause voltage

fluctuations. The operation of this device under

unfavorable mains conditions can have adverse effects

to the operation of other equipment. With a mains

impedance equal or less than 0.29 Ohms it can be

presumed that there will be no negative effects. The

mains socket used for this device must be protected with

a fuse or protective circuit breaker having slow tripping

characteristics.

ENG905-1

Noise

The typical A-weighted noise level determined according

to EN61029:

Sound pressure level (L

pA) : 91 dB(A)

Sound power level (L

WA) : 101 dB(A)

Uncertainty (K) : 3 dB(A)

Wear ear protection

ENG900-1

Vibration

The vibration total value (tri-axial vector sum) determined

according to EN61029:

Vibration emission (ah) : 2.5 m/s2 or less

Uncertainty (K) : 1.5 m/s2

ENG901-1

• The declared vibration emission value has been

measured in accordance with the standard test

method and may be used for comparing one tool

with another.

• The declared vibration emission value may also be

used in a preliminary assessment of exposure.

WARNING:

• The vibration emission during actual use of the

power tool can differ from the declared emission

value depending on the ways in which the tool is

used.

• Be sure to identify safety measures to protect the

operator that are based on an estimation of

exposure in the actual conditions of use (taking

account of all parts of the operating cycle such as

the times when the tool is switched off and when it

is running idle in addition to the trigger time).

ENH003-13

For European countries only

EC Declaration of Conformity

We Makita Corporation as the responsible

manufacturer declare that the following Makita

machine(s):

Designation of Machine:

Compound Miter Saw

Model No./ Type: LS1040,LS1040S

are of series production and

Conforms to the following European Directives:

2006/42/EC

And are manufactured in accordance with the following

standards or standardised documents:

EN61029

The technical documentation is kept by our authorised

representative in Europe who is:

Makita International Europe Ltd.

Michigan Drive, Tongwell,

Milton Keynes, Bucks MK15 8JD, England

30. 1. 2009

000230

Tomoyasu Kato

Director

Makita Corporation

3-11-8, Sumiyoshi-cho,

Anjo, Aichi, 446-8502, JAPAN

ENA001-2

SAFETY INSTRUCTIONS

WARNING! When using electric tools, basic safety

precautions, including the following, should always

be followed to reduce the risk of fire, electric shock

and personal injury. Read all these instructions

before operating this product and save these

instructions.

For safe operations:

1. Keep work area clean.

Cluttered areas and benches invite injuries.

2. Consider work area environment.

Do not expose power tools to rain. Do not use

power tools in damp or wet locations. Keep work

area well lit. Do not use power tools where there is

risk to cause fire or explosion.

3. Guard against electric shock.

Avoid body contact with earthed or grounded

surfaces (e.g. pipes, radiators, ranges,

refrigerators).

4. Keep children away.

Do not let visitors touch the tool or extension cord.

All visitors should be kept away from work area.

5. Store idle tools.

When not in use, tools should be stored in a dry,

high or locked up place, out of reach of children.

6. Do not force the tool.

It will do the job better and safer at the rate for

which it was intended.

7. Use the right tool.

Do not force small tools or attachments to do the

job of a heavy duty tool. Do not use tools for

purposes not intended; for example, do not use

circular saws to cut tree limbs or logs.
