Makita M6500 Bruksanvisning
Makita
Skruvborrar
M6500
Läs nedan 📖 manual på svenska för Makita M6500 (11 sidor) i kategorin Skruvborrar. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/11
GB High Speed Drill Instruction Manual
F Perceuse à Haute Vitesse Manuel d’Instructions
DHochgeschwindigkeits-
Bohrmaschine Betriebsanleitung
I Trapano ad alta velocità Istruzioni d’Uso
NL Hoge-snelheid boormachine Gebruiksaanwijzing
E Taladro de Alta Velocidad Manual de Instrucciones
P Furadeira de Alta Velocidade Manual de Instruções
DK Hurtigløbende boremaskine Brugsanvisning
GR Τρυπάνι υψηλής ταχύτητας Οδηγίες χρήσεως
TR Yüksek Hızlı ı Matkap Kullanma k lavuzu
M6500
M6501
2
1 2
3 4
5
5
6
7
A
B
3
4
1
2
013476 013477
013475 013712
015473
3
ENGLISH (Original instructions)
Explanation of general view
1 Switch trigger
2 Lock button
3 Reversing switch lever
4 Chuck key
5 Depth gauge
6 Washer
7 Clamp screw
SPECIFICATIONS
• Due to our continuing program of research and
development, the specifications herein are subject to
change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE032-1
Intended use
The tool is intended for drilling in wood, metal and plastic.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
GEA010-1
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future
reference.
GEB001-6
DRILL SAFETY WARNINGS
1. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
2. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
3. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
4. Hold the tool firmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the drill bit or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
8. Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation
and skin contact. Follow material supplier safety
data.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function on the
tool.
Switch action (Fig. 1)
CAUTION:
• Before plugging in the tool, always check to see the
switch trigger actuates properly and returns to the
“OFF” position when released.
• Switch can be locked in “ON” position for ease of
operator comfort during extended use. Apply caution
when locking tool in “ON” position and maintain firm
grasp on tool.
For Model M6500
To start the tool, simply pull the switch trigger. Release
the switch trigger to stop. For continuous operation, pull
the switch trigger, push in the lock button and then
release the switch trigger. To stop the tool from the
locked position, pull the switch trigger fully, then release
it.
Model M6500 M6501
Capacities
Steel 6.5 mm
Wood 9 mm
No load speed (min–1
) 4,500 0 – 4,500
Overall length 200 mm 203 mm
Net weight 0.92 kg 0.95 kg
Safety class /II
Produktspecifikationer
| Varumärke: | Makita |
| Kategori: | Skruvborrar |
| Modell: | M6500 |
