Sida 1/20

INSTRUCTION MANUAL

Table Saw

MLT100N

ENGLISH: Original instructions

DOUBLE INSULATION

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: MLT100N

Arbor hole

(Country specic)

30 mm / 25.4 mm

Blade diameter 260 mm

Max. cutting capacities bevel 0° 93 mm

bevel 45° 64 mm

No load speed 4,300 min-1

Table size (L x W)

with sub tables (R) and (back)

835 mm x 1,305 mm (tables extended)

685 mm x 955 mm (tables stored)

Dimensions (L x W x H)

with sub tables (R) and (back)

726 mm x 984 mm x 473mm (tables stored)

Net weight 34.8 - 35.1 kg

Safety class /II

• Due to our continuing program of research and development, the specications herein are subject to change

without notice.

• Specications may differ from country to country.

• The weight may differ depending on the attachment(s). The lightest and heaviest combination, according to

EPTA-Procedure 01/2014, are shown in the table.

Symbols

The followings show the symbols used for the equip-

ment. Be sure that you understand their meaning before

use.

Read instruction manual.

DOUBLE INSULATION

Wear safety glasses.

Do not place hand or ngers close to the

blade.

X~Xmm(мм)

Make proper clearance between the saw

blade and riving knife.

Only for EU countries

Do not dispose of electric equipment

together with household waste material! In

observance of the European Directive, on

Waste Electric and Electronic Equipment

and its implementation in accordance with

national law, electric equipment that have

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

The tool is intended for cutting in wood.

Straight cutting, bevel cutting, and miter cutting are

available with this tool. This tool is not designed for non-

through cutting.

Power supply

The tool should be connected only to a power supply of

the same voltage as indicated on the nameplate, and

can only be operated on single-phase AC supply. They

are double-insulated and can, therefore, also be used

from sockets without earth wire.

Noise

The typical A-weighted noise level determined accord-

ing to EN62841-3-1:

Sound pressure level (L

pA) : 89 dB(A)

Sound power level (L

WA) : 100 dB (A)

Uncertainty (K) : 3 dB(A)

NOTE: The declared noise emission value(s) has

been measured in accordance with a standard test

method and may be used for comparing one tool with

another.

NOTE: The declared noise emission value(s)

may also be used in a preliminary assessment of

exposure.

WARNING: Wear ear protection.

WARNING: The noise emission during actual

use of the power tool can differ from the declared

value(s) depending on the ways in which the

tool is used especially what kind of workpiece is

processed.

WARNING: Be sure to identify safety mea-

sures to protect the operator that are based on an

estimation of exposure in the actual conditions of

use (taking account of all parts of the operating

cycle such as the times when the tool is switched

off and when it is running idle in addition to the

trigger time).

3 ENGLISH

EC Declaration of Conformity

For European countries only

The EC declaration of conformity is included as Annex A

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING: Read all safety warnings, instruc-

tions, illustrations and specications provided

with this power tool. Failure to follow all instructions

listed below may result in electric shock, re and/or

serious injury.

Save all warnings and instruc-

tions for future reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust. Power tools create sparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodied plugs and matching outlets will

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of elec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions. Water entering a power tool will increase

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

5. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of

electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply. Use of an RCD reduces

the risk of electric shock.

7. Use of power supply via an RCD with a rated

residual current of 30 mA or less is always

recommended.

Power tools can produce electromagnetic elds

(EMF) that are not harmful to the user. However,

users of pacemakers and other similar medical

devices should contact the maker of their device and/

or doctor for advice before operating this power tool.

9. Do not touch the power plug with wet hands.

10.

If the cord is damaged, have it replaced by the manu-

facturer or his agent in order to avoid a safety hazard.

Personal Safety

1. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the inuence of drugs, alcohol or med-

ication. A moment of inattention while operating

power tools may result in serious personal injury.

2. Use personal protective equipment. Always

wear eye protection. Protective equipment such

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

will reduce personal injuries.

3. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

your nger on the switch or energising power tools

that have the switch on invites accidents.

Remove any adjusting key or wrench before turning

the power tool on. A wrench or a key left attached to a

rotating part of the power tool may result in personal injury.

5. Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair and clothing away

from moving parts. Loose clothes, jewellery or

long hair can be caught in moving parts.

7. If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used. Use of

dust collection can reduce dust-related hazards.

Do not let familiarity gained from frequent use

of tools allow you to become complacent and

ignore tool safety principles. A careless action can

cause severe injury within a fraction of a second.

Always wear protective goggles to protect your eyes

from injury when using power tools.The goggles

must comply with ANSI Z87.1 in the USA, EN 166 in

Europe, or AS/NZS 1336 in Australia/New Zealand. In

Australia/New Zealand, it is legally required to wear

a face shield to protect your face, too.
