INSTRUCTION MANUAL

Cordless Hedge Trimmer

UH013G

UH014G

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: UH013G UH014G

Blade length 600 mm 750 mm

Strokes per minute 2,000 / 3,600 / 5,000 min

-1

Overall length 1,085 mm 1,225 mm

Rated voltage D.C. 36 V - 40 V max

Net weight 3.9 - 4.5 kg 4.0 - 4.7 kg

Protection degree IPX4

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsmaydi󰀨erfromcountrytocountry.

• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

est combination, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Batterycartridge BL4020* / BL4025* / BL4040* / BL4050F

*:Recommendedbattery

Charger DC40RA / DC40RB / DC40RC

• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof

residence.

WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges

andchargersmaycauseinjuryand/orre.

Recommended cord connected power source

Portable power pack PDC01 / PDC1200

• Thecordconnectedpowersource(s)listedabovemaynotbeavailabledependingonyourregionofresidence.

• Beforeusingthecordconnectedpowersource,readinstructionandcautionarymarkingsonthem.

Symbols

Thefollowingsshowthesymbolswhichmaybeused

fortheequipment.Besurethatyouunderstandtheir

meaning before use.

Read instruction manual.

DANGER-Keephandsawayfromblade.

Wearsafetyglasses.

Ni-MH

Li-ion

OnlyforEUcountries

Due to the presence of hazardous com-

ponents in the equipment, waste electrical

and electronic equipment, accumulators

andbatteriesmayhaveanegativeimpact

on the environment and human health.

Do not dispose of electrical and electronic

appliances or batteries with household

waste!

In accordance with the European Directive

on waste electrical and electronic equip-

ment and on accumulators and batteries

and waste accumulators and batteries,

as well as their adaptation to national law,

waste electrical equipment, batteries and

accumulatorsshouldbestoredseparately

and delivered to a separate collection point

for municipal waste, operating in accor-

dance with the regulations on environmen-

tal protection.

Thisisindicatedbythesymbolofthe

crossed-out wheeled bin placed on the

equipment.

Intended use

The tool is intended for trimming hedges.

3 ENGLISH

Noise

Applicable standard : EN62841-4-2

Model Sound pressure level Sound power level

LpA(dB(A)) UncertaintyK

(dB(A))

LWA(dB(A)) UncertaintyK

(dB(A))

UH013G 80 913 3

UH014G 81 923 3

NOTE:Thedeclarednoiseemissionvalue(s)hasbeenmeasuredinaccordancewithastandardtestmethodand

maybeusedforcomparingonetoolwithanother.

NOTE:Thedeclarednoiseemissionvalue(s)mayalsobeusedinapreliminaryassessmentofexposure.

WARNING: Wear ear protection.

WARNING: The noise emission during actual use of the power tool can di󰀨er from the declared val-

ue(s) depending on the ways in which the tool is used especially what kind of workpiece is processed.

WARNING: Be sure to identify safety measures to protect the operator that are based on an estimation

of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the

times when the tool is switched o󰀨 and when it is running idle in addition to the trigger time).

Vibration

Thevibrationtotalvalue(tri-axialvectorsum)determinedaccordingtoEN62841-4-2:

Model Front handle Rear handle

ah (m/s2) Uncertainty K

(m/s2)

ah (m/s2) Uncertainty K

(m/s2)

UH013G 2.5 1.5

2.5 m/s2 or less

1.5

UH014G 3.2 1.5

2.5 m/s2 or less

1.5

NOTE:Thedeclaredvibrationtotalvalue(s)hasbeenmeasuredinaccordancewithastandardtestmethodand

maybeusedforcomparingonetoolwithanother.

NOTE:Thedeclaredvibrationtotalvalue(s)mayalsobeusedinapreliminaryassessmentofexposure.

WARNING: The vibration emission during actual use of the power tool can di󰀨er from the declared

value(s) depending on the ways in which the tool is used especially what kind of workpiece is processed.

WARNING: Be sure to identify safety measures to protect the operator that are based on an estimation

of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the

times when the tool is switched o󰀨 and when it is running idle in addition to the trigger time).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING: Read all safety warnings, instruc-

tions, illustrations and specications provided

with this power tool. Failure to follow all instructions

listedbelowmayresultinelectricshock,reand/or

seriousinjury.

Save all warnings and instruc-

tions for future reference.

Theterm"powertool"inthewarningsreferstoyour

mains-operated(corded)powertoolorbattery-operated

(cordless)powertool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust. Power tools create sparks

whichmayignitethedustorfumes.

Keep children and bystanders away while operating

a power tool.Distractionscancauseyoutolosecontrol.

Electrical safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiedplugsandmatchingoutletswill

reduce risk of electric shock.
