INSTRUCTION MANUAL
Battery Powered Grass Trimmer
UR101C
UR201C
ENGLISH: Original instructions
Read before use.
2 ENGLISH
SPECIFICATIONS
Model: UR101C UR201C
Handle type Bike handle Loop handle
No load speed
(at each rotation speed level)
Cutter blade
Plastic blade (305 mm)
3: 0 - 7,000 min-1
2: 0 - 5,500 min-1
1: 0 - 4,600 min-1
Nylon cutting head
Plastic blade (255 mm)
3: 0 - 5,500 min-1
2: 0 - 5,000 min-1
1: 0 - 4,600 min-1
Overall length
(without cutting tool)
1,760 mm 1,795 mm
Nylon cord diameter 2.4 mm
Applicable cutting tool and
cutting diameter
2-tooth blade
(P/N 198345-9)
255 mm
3-tooth blade
(P/N 195299-1)
255 mm
4-tooth blade
(P/N 196895-8)
255 mm
Nylon cutting head
(P/N 197993-1)
430 mm
Plastic blade
(P/N 198383-1)
(P/N 199868-0)
255 mm
305 mm
Rated voltage D.C. 36 V - 40 V max
Net weight 5.2 kg 4.7 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydierfromcountrytocountry.
• Weight according to EPTA-Procedure 01/2014
Applicable portable power pack
PDC01
Noise
Model UR101C
Cutting tool
Sound pressure level (L
pA) dB(A)
Sound power level (L
WA) dB(A)
Applicable
standard
LpA
dB(A)
Uncertainty (K)
dB(A)
LWA dB(A)
Uncertainty (K)
dB(A)
2-tooth blade 81.7 0.5 93.9 0.8
ISO22868
(ISO11806-1)
4-tooth blade 83.0 0.3 97.6 0.2
ISO22868
(ISO11806-1)
Nylon cutting head 80.0 0.9 91.8 1.0
ISO22868
(ISO11806-1)/
EN50636-2-91
Plastic blade 78.0 1.0 87.4 0.7
ISO22868
(ISO11806-1)/
EN50636-2-91
3 ENGLISH
Model UR201C
Cutting tool
Sound pressure level (L
pA) dB(A)
Sound power level (L
WA) dB(A)
Applicable
standard
LpA
dB(A)
Uncertainty (K)
dB(A)
LWA dB(A)
Uncertainty (K)
dB(A)
2-tooth blade 81.7 0.5 93.9 0.8
ISO22868
(ISO11806-1)
4-tooth blade 83.0 0.3 97.6 0.2
ISO22868
(ISO11806-1)
Nylon cutting head 80.0 0.9 91.8 1.0
ISO22868
(ISO11806-1)/
EN50636-2-91
Plastic blade 78.0 1.0 87.4 0.7
ISO22868
(ISO11806-1)/
EN50636-2-91
• Even if the sound pressure level listed above is 80 dB (A) or less, the level under working may exceed 80 dB
(A). Wear ear protection.
NOTE: The declared noise emission value(s) has been measured in accordance with a standard test method and
may be used for comparing one tool with another.
NOTE: The declared noise emission value(s) may also be used in a preliminary assessment of exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual use of the power tool can dier from the declared val-
ue(s) depending on the ways in which the tool is used especially what kind of workpiece is processed.
WARNING: Be sure to identify safety measures to protect the operator that are based on an estimation
of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the
times when the tool is switched o and when it is running idle in addition to the trigger time).
Vibration
Applicable standard : ISO22867(ISO11806-1)
Model UR101C
Cutting tool Left hand Right hand
ah,W (m/s2) Uncertainty K
(m/s 2)
ah,W (m/s2) Uncertainty K
(m/s2)
2-tooth blade 2.5 1.5 2.5 1.5
4-tooth blade 2.5 1.5 2.5 1.5
Nylon cutting head 2.5 1.5 2.5 1.5
Plastic blade 2.5 1.5 2.5 1.5
Model UR201C
Cutting tool Left hand Right hand
ah,W (m/s2) Uncertainty K
(m/s 2)
ah,W (m/s2) Uncertainty K
(m/s2)
2-tooth blade 2.5 1.5 2.5 1.5
4-tooth blade 2.5 1.5 2.5 1.5
Nylon cutting head 2.5 1.5 2.5 1.5
Plastic blade 2.5 1.5 2.5 1.5
NOTE: The declared vibration total value(s) has been measured in accordance with a standard test method and
may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also be used in a preliminary assessment of exposure.
