Sida 1/28

For additional benefits

EU 10-Port AC

Charging Cabinet

Instructions

Model 180924

or visit: register.manhattanproducts.com/r/180924

Important: Read before use. • Importante: Leer antes de usar.

Scan to

product warranty

For specifications, please visit manhattanproducts.com register.. Register your product at

manhattanproducts.com/r/180924 or scan the QR code on the cover.

Using the Lock

The Default Combination and Turning the Wheels

The default combination is 0-0-0-0; see below. The wheels are only able to be turned to the left.

To Unlock

• Combination Method: Turn the wheels to the correct

code.

• Key Method: Turn the key in the lock as shown.

Once the cabinet is unlocked, pull up from the bottom of the handle and turn it 90° to the right; then open the door.

To Lock

Close the door, turn the handle 90° to the left and push it back into its closed state. Once the cabinet is secure:

• Combination Method: Scramble

the combination wheels.

• Key Method: Turn the key back 90°

and remove it from the lock.

Instructions

English

To Set a New Combination

Remember to record and safely store the new combination after you set it. This is a

mechanical lock, which cannot be reset directly if the code is forgotten.

1 Make sure the Combination button on the back of the handle is in the Normal position.

2 Push the Combination button to the Set position.

3 Turn the combination wheels to your desired code. NOTE: make sure

to record and securely store the new combination.

4 Once the new code is set, push the Combination button back to the Normal position.

NOTE: Make sure you record and securely store the new combination.

To Find the Forgotten Combination

1 Remove the combination wheel box from the handle by unfastening the screws that secure it in place.

2 Turn the combination wheels to the left to find the cutouts on the adjacent smaller wheels. The number next to the

cutout is the correct number in the combination.

3 Once the correct combination is noted and stored securely, re-fasten the

combination wheel box to the handle using the screws.

1 2 3 4

Instructions

English
