K00146 ICE BAGGER
Installation Instructions
To Assemble Bagger Mounting Bracket
1. Remove the ice chute.
2. For left-handed users, assemble the bagger mounting
bracket on the left side, as illustrated in Figure A. For
right-handed users, assemble the bagger mounting bracket
on the right side of the bagger cabinet using the machine
screws and lockwashers provided. Note: mount the
rubber bumper to the same side of the bagger as the
mounting bracket, along the lower edge.
To Use Ice Bagger
1. Hang bags on the rear bracket through the rectangle slot
in the bag hanger (see Figures B and C).
2. Place supplied twist ties in front tray.
3. Replace the ice chute.
4. Pull open one bag under the ice chute.
5. Fill the bag with ice, leaving enough room so the bag can
be twisted and closed.
6. Firmly pull bag of ice off of hanger, twist, and close with
twist tie.
Refilling Empty Bag Hanger
1. Remove the empty wire wicket from bag hanger and
discard.
2. Lay wicket of new bags down on a flat surface with the
ends of the wicket sticking straight up.
3. Slide the bag hanger down onto the wire wicket with the
ends of the wire wicket going through the holes in the bag
hanger.
4. Tuck the top ends of the bags under the tab on the front of
the bag hanger.
5. Keep the bags and hanger lying flat. With your left hand,
squeeze together the wire wicket, bags, and hanger.
While squeezing with your left hand, pull up and bend the
ends of the wire wicket over 90 towards the center, with
your right hand.
6. Tuck the ends of the bent wire wicket under the tab on the
back of the bag hanger.
7. Remove the cardboard from the front of the bags and
hang the bags in place.
Manitowoc Ice, Inc.
2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 8011103
Web Site - www.manitowocice.com Rev. 06/10/03
Ice Chute Ice Chute
Bagger Mounting
Bracket
Rubber
Bumper
FIGURE A
FIGURE B
FIGURE C
Rear Bracket
Front Tray
Bag Hanger
Rectangle Slot for Hanging - Do
Not Hang by Wire Wicket
Wire Wicket
