Instruction Sheet Subject: K00470 K00472 K00473 Bin Adapter
BIN ADAPTER
K00470 30” ICE MACHINE ON 48” BIN
K00472 22” ICE MACHINE ON A 30” BIN
K00473 22” ICE MACHINE ON A 48” BIN
1 of 1
Document Number: 000015255 Rev 01 1/18
MA NITOWOC ICE
2110 SOUT H 26TH STREET, MANITOWOC, WI 54220
844724CARE
WW W.MANITO WOCICE.COM
nWarning
Authorized Service Representatives are obligated to follow
industry standard safety procedures, including, but not
limited to, local/national regulations for disconnection
/ lock out / tag out procedures for all utilities including
electric, gas, water and steam.
These instructions are used for installing the following:
• 22” ice machines on 30” B, K or D model bins
• 22” ice machines on 48” B, K or D model bins
• 30” ice machines on 48” B, K or D model bins
1. Remove protective coating from support rail and bin
adapter prior to assembly.
2. Refer to drawing and place support in position. Angled
flange of support must face the front of the bin. Apply
foam tape on top of the support.
3. Place bin adapter on bin - No fasteners are required.
4. Apply foam tape from the kit around bin top opening.
A. Foam tape applied to the front of the bin opening
must be located under the ice machine bottom rail.
B. Apply foam tape around the sides and rear of the
bin top opening.
5. Place bin in final position and adjust legs to level bin in
all directions.
6. Refer to Ice Machine Installation Manual for ice machine
installation. Clean and sanitize the ice machine and bin
when installation is complete.
Angled ends must face toward
front of bin/ice machine Foam tape must be located
underneath the front ice
machine bottom rail.
Install Foam Tape around
bin top opening
