Model ZC4001 User Guide

Audio Client

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

The lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (servicing) instructions

in the literature accompanying the product.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG

TO WIDE SLOT, FULLY INSERT.

ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA

LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE

DE LA PRISE ET POUSSER JUSQU’AU FOND.

NOTE TO CATV SYSTEM INSTALLER:

This reminder is provided to call the CATV (Cable-TV) system installer’s attention to Section 820-40 of the

NEC which provides guidelines for proper grounding and, in particular, specifies that the cable ground

shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

NOTE:

This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference in a residential

installation. This equipment generates, uses and

can radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful interference to

radio communications. However, there is no

guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by tuning the

equipment off and on, the user is encouraged to try

to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment

and receiver.

- Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV

technician for help.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

IMPORTANT SAFETY

INSTRUCTIONS

READ BEFORE OPERATING EQUIPMENT

This product was designed and manufactured to

meet strict quality and safety standards. There are,

however, some installation and operation

precautions which you should be particularly

aware of.

1. Read Instructions – All the safety and

operating instructions should be read before

the product is operated.

2. Retain Instructions – The safety and operating

instructions should be retained for future

reference.

3. Heed Warnings – All warnings on the product

and in the operating instructions should be

adhered to.

4. Follow Instructions – All operating and use

instructions should be followed.

5. Cleaning – Unplug this product from the wall

outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use a damp

cloth for cleaning.

6. Attachments – Do not use attachments not

recommended by the product manufacturer

as they may cause hazards.

7. Water and Moisture – Do not use this product

near water-for example, near a bath tub, wash

bowl, kitchen sink, or laundry tub, in a wet

basement, or near a swimming pool, and the

like.

8. Accessories – Do not place this product on an

unstable cart, stand, tripod, bracket, or table.

The product may fall, causing serious injury to

a child or adult, and serious damage to the

product. Use only with a cart, stand, tripod,

bracket, or table recommended by the

manufacturer, or sold with the product. Any

mounting of the product should follow the

manufacturer’s instructions, and should use a

mounting accessory recommended by the

manufacturer.

9. A product and cart combination should be

moved with care. Quick stops, excessive

force, and uneven surfaces may cause the

product and cart combination to overturn.

10. Ventilation – Slots and openings in the cabinet

are provided for ventilation and to ensure

reliable operation of the product and to protect

it from overheating, and these openings must

not be blocked or covered. The openings

should never be blocked by placing the

product on a bed, sofa, rug, or other similar

surface. This product should not be placed in

a built-in installation such as a bookcase or

rack unless proper ventilation is provided or

the manufacturer’s instructions have been

adhered to.

11. Power Sources – This product should be

operated only from the type of power source

indicated on the marking label. If you are not

sure of the type of power supply to your home,

consult your product dealer or local power

company. For products intended to operate

from battery power, or other sources, refer to

the operating instructions.

12. Grounding or Polarization – This product may

be equipped with a polarized alternating-

current line plug (a plug having one blade

wider than the other). This plug will fit into the

power outlet only one way. This is a safety

feature. If you are unable to insert the plug

fully into the outlet, try reversing the plug. If the

plug should still fail to fit, contact your

electrician to replace your obsolete outlet. Do

not defeat the safety purpose of the polarized

plug.

AC POLARIZED PLUG

13. Power-Cord Protection – Power-supply cords

should be routed so that they are not likely to

be walked on or pinched by items placed upon

or against them, paying particular attention to

cords at plugs, convenience receptacles, and

the point where they exit from the product.

14. Protective Attachment Plug The product is–

equipped with an attachment plug having

overload protection. This is a safety feature.

See Instruction Manual for replacement or

resetting of protective device. If replacement

of the plug is required, be sure the service

technician has used a replacement plug

specified by the manufacturer that has the

same overload protection as the original plug.

15. Outdoor Antenna Grounding If an outside–

antenna or cable system is connected to the

product, be sure the antenna or cable system

is grounded so as to provide some protection

against voltage surges and built-up static

charges. Article 810 of the National Electrical

Code, ANSI/NFPA 70, provides information

with regard to proper grounding of the mast

and supporting structure, grounding of the

lead-in wire to an antenna discharge unit, size

of grounding conductors, location of antenna-

discharge unit, connection to grounding

electrodes, and requirements for the

grounding electrode. See Figure 1.

16. Lightning – For added protection for this

product during a lightning storm, or when it is

left unattended and unused for long periods of

time, unplug it from the wall outlet and

disconnect the antenna or cable system. This

will prevent damage to the product due to

lightning and power-line surges.

17. Power Lines An outside antenna system–

should not be located in the vicinity of

overhead power lines or other electric light or

power circuits, or where it can fall into such

power lines or circuits. When installing an

outside antenna system, extreme care should

be taken to keep from touching such power

lines or circuits as contact with them might be

fatal.

18. Overloading – Do not overload wall outlets,

extension cords, or integral convenience

receptacles as this can result in a risk of fire or

electric shock.

19. Object and Liquid Entry – Never push objects

of any kind into this product through openings

as they may touch dangerous voltage points

or short-out parts that could result in a fire or

electric shock. Never spill liquid of any kind on

the product.

20. Servicing – Do not attempt to service this

product yourself as opening or removing

covers may expose you to dangerous voltage

or other hazards. Refer all servicing to

qualified service personnel.

21. Damage Requiring Service Unplug this–

product from the wall outlet and refer servicing

to qualified service personnel under the

following conditions:

a. When the power-supply cord or plug is

damaged.

b. If liquid has been spilled, or objects have

fallen into the product.

c. If the product has been exposed to rain or

water.

d. If the product does not operate normally by

following the operating instructions. Adjust

only those controls that are covered by the

operating instructions as an improper

adjustment of other controls may result in

damage and will often require extensive work

by a qualified technician to restore the product

to its normal operation.

e. If the product has been dropped or damaged

in any way, and

f. When the product exhibits a distinct change in

performance – this indicates a need for

service.

22. Replacement Parts When replacement–

parts are required, be sure the service

technician has used replacement parts

specified by the manufacturer or have the

same characteristics as the original part.

Unauthorized substitutions may result in fire,

electric shock, or other hazards.

23. Safety Check Upon completion of any–

service or repairs to this product, ask the

service technician to perform safety checks to

determine that the product is in proper

operating condition.

24. Wall or Ceiling Mounting – The product should

be mounted to a wall or ceiling only as

recommended by the manufacturer.

25. Heat – The product should be situated away

from heat sources such as radiators, heat

registers, stoves, or other products (including

amplifiers) that produce heat.

FIGURE 1

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

This Class B digital apparatus complies with

Canadian ICES-003.

Cet appareil num rique de la Classe B est conformeé

à la norme NMB-003 du Canada.

NEC - NATIONAL ELECTRICAL CODE

ANTENNA

LEAD IN WIRE

GROUND

CLAMP

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

ELECTRIC

SERVICE

EQUIPMENT

GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)
