Sida 1/20
WARNING
CAUTION
CAUTION!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
This Compact Disc player is classified as CLASS 1 LASER product.
Invisible laser radiation when open and interlocks defeated. Avoid
exposure to beam.
A CONTROLS
1 VOLUME
2 FUNCTION ( CD/TAPE/RADIO )
3 CD REPEAT
4 CD PROGRAM
5 CD STOP ( )
6 PHONES
7 FM ANTENNA
HANDLE
9 BAND ( AM/FM ST )
DISC COMPARTMENT
11 DIAL SCALE
TUNING
13 CD SKIP + ( )
8
10
12
14 CD PLAY/PAUSE ( )
15 CD SKIP - ( )
16 BATTERY
17 POWER INDICATOR
18 CASSETTE COMPARTMENT
19 LCD DISPLAY
20 TAPE PAUSE ( )
21 TAPE STOP/EJECT ( )
22 TAPE F. FWD ( )
23 TAPE REWIND( )
24 TAPE PLAY ( )
TAPE REC ( )
26 AC IN
25
Read the Operating Instructions carefully and completely
before operating the unit. Be sure to keep the Operating
Instructions for future reference. All warnings and cautions
in the Operating Instructions and on the unit should be
strictly followed, as well as the safety suggestions below.
Installation
1 Water and moisture - Do not use this unit near water,
such as near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement, swimming pool, or the like.
2 Heat - Do not use this unit near sources of heat, including
heating vents, stoves, or other appliances that generate
heat.
3 Mounting surface - Place the unit on a flat, even surface.
4 Ventilation - The unit should be situated with adequate
space around it so that proper heat ventilation is assured.
Allow 10 cm(4 in.) clearance from the rear and the top of
the unit and 5 cm (2 in.) from each side.
- Do not place the unit on a bed, rug, or similar surface
that may block the ventilation openings.
- Do not install the unit in a bookcase, cabinet,
or airtight rack where ventilation may be impeded.
5 Objects and liquid entry - Take care that objects
or liquids do not get inside the unit through the
ventilation openings.
6 Condensation - Moisture may form on the CD Pickup
lens when:
- The unit is moved from a cold spot to a warm spot
- the heating system has just been turned on
- the unit is used in a very humid room
- the unit is cooled by an air conditioner
When this unit has condensation inside, it may not
function normally. Should this occur, leave the unit for
a few hours, then try to operate again.
Electric Power
1 Power sources - Use on batteries or AC house current,
as specified in the Operating Instructions and marked
on the unit.
2 AC power cord
When disconnecting the AC power cord, pull it out by-
the AC power plug. Do not pull the cord itself.
Never handle the AC power plug with wet hands, as-
this could result in fire or shock.
Power cords should be firmly secured to avoid being -
bent, pinched, or walked upon. Pay particular attention
to the cord from the unit to the power socket.
Avoid overloading AC power plugs and extension -
cords. beyond their capacity, as this could result in fire
or shock.
3 When not in use - Unplug the AC power cord from the
AC outlet or remove all the batteries if the unit will not
be used for several months or more. When the cord is
plugged in ,a small amount of current continues to flow
to the unit, even when the power is turned off.
B PRECAUTIONS
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
MPR-86 PORTABLE CD SYSTEM
OPERATING INSTRUCTION
1
2
3
5
6 7 8
9
10
11
12
14
15
16
17 18 19
2520 21 22 23 24
26
13
4
GB-1 GB-2
IMPORTANT
Make sure that f is set to TAPE before connecting
the AC cord or inserting batteries.
Using on batteries
Open the lid of the battery compartment on the rear and
unction
C POWER SUPPLY
The batteries need to be replaced when:
The tape speed slows down, volume decreases, or
sound is distorted during operation.
notes on batteries
Do not mix different types of batteries or old batteries
with new ones.
Never recharge the batteries, apply heat to them or
take them apart.
Remove dead batteries.
If liquid leaks from the batteries, wipe thoroughly to remove.
D MAINTENANCE
To clean the cabinet
Use a soft cloth lightly moistened with mild detergent
solution. Do not use strong solvents such as alcohol.
benzine or thinner.
To clean the heads and tape paths
After every 10 hours of use, clean the Recording heads
and Playback head , the pinch roller and capstan .Use
a cotton swab 5 slightly moistened with cleaning fluid
or denatured alcohol.
Cassette tapes
To prevent accidental erasure, bread off the plastic tabs
on the cassette tape after recording with a screwdriver
or other pointed tool.
To record on the tape again, cover the tab openings with
adhesive tape, etc.
1 Set to CD.
2 OPEN the disc compartment and
the printed side up. The total number
is displayed.
3 Press PLAY/PAUSE to start play.
The number of the track being played is displayed.
4 Turn VOLUME to adjust the sound.
- Stops play.STOP
PLAY/PAUSE - Pauses play. To resume play, press
again.
SKIP-/ - Searches for a particular
point during playback. Keep or pressed and then
release it.
- Skips to the beginning of a track. Press or
repeatedly
function
place a disc with
of tracks
SKIP+
E CD OPERATION
,
REPEAT
Press REPEAT once- Display the flashed "RPT" symbol:
A single track is played repeatedly. Select a track
with or .
Press REPEAT twice- Display the solid "RPT" symbol:
All tracks are played repeatedly.
PROGRAM
In stop state, press PROGRAM and use skip/search
to select the track. Will be program, press play to
start program play.
NOTE
Do not use irregular shape CDs(example: heart-shaped,
octagonal ones). It may result in malfunctions.
Do not place more than one disc in the disc
compartment.
Do not try to open the disc compartment during play.
Do not touch the lens. Doing so may cause malfunctions.
1 Set function to RADIO.
2 Select a band with BAND.
3 Tune to a station with TUNING.
4 Turn VOLUME to adjust the sound.
For better reception - Extend the AM antenna is inside
the unit.
Position the unit for the best reception.
FM ST
Sets the FM or AM sound, insert a tape, Press rec start
recording.
F TUNER OPERATION
Use Type 1 (normal) tapes only.
PLAYING BACK A TAPE
1 Set to TAPE.
2 Press STOP/EJECT to open the cassette
holder and insert a tape with the exposed side up and
the side to be played facing out.
3 Press PLAY to start play.
4 Turn VOLUME to adjust the sound.
- Stops play.STOP/EJECT
PAUSE - Pauses play. To resume play, press again.
- Fast forwards/rewinds. F FWD/ REW
function
G TAPE OPERATION
RECORDING
Note that recording is done on only one side of the tape.
1 Insert a tape with the side to be recorded facing out.
Wind up the tape to the point where recording starts.
2 Get ready to record from the source.
To record from a CD: set function to CD and start play.
To record from the tuner: set function to RADIO and
tune to a station.
3 Press REC to start recording.
PLAY is pressed simultaneously.
To stop recording, press STOP/EJECT.
To erase a recording, set function to TAPE and start
recording.
To turn off the unit, set function to TAPE.
To listen with the headphones, connect headphones with a stereo mini plug to the PHONES jack.
If an erroneous display or malfunction occurs, disconnect the AC cord and remove all the batteries to turn off the
display. Then turn the power back on.
H GENERAL
COPYRIGHT
Please check the copyright laws relating to recordings from disc, radio or external
tape for the country in which the machine is being used.
Tuner section
Frequency range, FM: 88-108 MHz
AM: 530-1600 KHz
Deck section
Track format- 2 track, 4 channels / Frequency range-
Normal tape / Recording system- DC bias /
Erasing system-Magnet erase / Heads- Recording /
playback head , Erasure head
CD player section
Disc- Compact disc / Scanning method - Non-contact
optical scanner (semiconductor laser)
I SPECIFICATIONS
General
Speaker- 77 mm cone type (2) / Output- Headphones jack
(stereo jack) / Power output - 0.8 W +0.8 W / Power
requirements- DC 9 V using six size C batteries,
AC 230V, 50Hz / Weight - 2.1Kg (excluding batteries) /
Dimensions - 295(W)x153(H)x213(D) mm
Specifications and external appearance are
subject to change without notice.
insert six (size C) batteries, not supplied, with the and
marks correctly aligned. then close the lid.
Disconnect the AC cord from the AC inlet.
GB-3 GB-4
