Sida 1/13

S E R

A N U A L

From Jim Marshall

Warning List and Introduction

Section 1 - Connection Diagrams

A. With a Home / Recording Mixer

B. Stereo Rack System

C. With a Stereo or Mono Combo / Amp

Section 2 - Quick Reference Guide

2.1 - Selecting a Stored Pre-Set

2.2 - Editing Pre-Set Programs

2.3 - Storing Altered Parameter Values

2.4 - Naming a Program

Section 3 - Front Panel

3.1 - The Rear Panel

Section 4 - The Mixer Section

4.1 - Setting the Output Levels

Section 5 - Chorus / Flange Mode

5.1 - Chorus / Flange Types

5.2 - Chorus Parameters

5.3 - Creating a Chorus / Flange Program

Section 6 - Multi-Tap Mode

6.1 - Multi Tap Parameters

6.2 - Creating a Multi-Tap Program

Section 7 - Delay Mode

7.1 - Delay Types

7.2 - Delay Parameters

7.3 - Creating a Delay Program

Section 8 - Reverb Mode

8.1 - Reverb Mode

8.2 - Reverb Characters

8.3 - Reverb Parameters

8.4 - Creating a Reverb Program

Section 9 - Multi Effect Mode

9.1 - Multi-Effect Individual Features

9.2 - Multi-Effect Parameters

9.3 - Creating a Multi-Effect Program

Section 10 - Naming a Program

Section 11 - Storing a Program

Section 12 - The System Menu

12.1 - The Remote Jack

12.2 - MIDI Operations and Functions

12.3 - MIDI Channel

12.4 - Input and Output Mapping

12.5 - MIDI Controllers

12.6 - MIDI Controller Parameters for each Mode

12.7 - System Exclusive Back-up

12.8 - Battery Level

Section 13 - Re-Initialising the JFX-1

Section 14 - Specifications

Section 15 - JFX-1 Factory Pre-Sets

Section 16 - MIDI Implementation Chart

Section 17 - Program Information Sheets

JFX-1 Handbook Contents :

FRENCH GERMAN SPANISH JAPANESE

ENGLISH

WARNING!

PLEASE READ THE FOLLOWING LIST CAREFULLY

A. DO NOT attempt to remove the JFX-1’s lid, There are no user serviceable parts inside.

B. ALWAYS have this equipment serviced or repaired by competent, qualified personnel.

C. NEVER use the JFX-1 in damp or wet conditions.

D. ALWAYS use only the Marshall power supply that is provided with the JFX-1.

E. PLEASE READ this instruction manual carefully before switching on.

Introduction

The Marshall JFX-1 is a totally programmable 24 bit digital effects processor which features the

highest quality effects algorithms and also allows complete control via MIDI.

By utilising a 64x over-sampling 16 bit Sigma/Delta Analogue to Digital converter in conjunction

with 16 bit linear dual Digital to Analogue conversion, the JFX-1 produces effects that have superb

resolution and depth, with an absolute minimum of distortion and maximum dynamic range.

Also by incorporating a high quality Voltage Control Amplifier the all important dry signal is kept free

from degradation - essential for maintaining the integrity of your direct sound.

Although suitable for all processing applications the JFX-1 has been designed primarily as a guitar

rack effects processor. The first 50 programs have been pre-set at the Marshall factory but may be edited

in full. They can also be restored without loss of data custom programmed into memories 50 to 127. The

individual algorithms for Chorus/Flange, Multi-Tap Delay, Delay, Reverb and Multi-Effect, give you the

ability to edit and store a superb library of effects, with no unnecessary or redundant features to confuse

the issue.

If you want to use the JFX-1 with an amp head or combo which has channel switching facilities the

special Remote Jack can be programmed to activate the Channel switch as part of the selected program.

Whether you are recording in a professional or home studio or playing live through a combo or full

stereo rack system, the JFX-1 puts a vast range of creative possibilities instantly at your fingertips.

It is advisable to keep this manual in a safe place for future reference after studying it carefully, as

gaining a full understanding of how the JFX-1 operates will ensure that you are getting the most from it’s

processing power- especially when designing your own personal sounds.

Section 1 - Connection Diagrams

Manufactured in Great Britain by:

Marshall Amplification plc, Bletchley,

Milton Keynes, England.

Model No. JFX-1

WARNING! No user servicable parts inside;

refer servicing to qualified personel only.

Power

9V AC

1.2A

MIDI

THRU Out Remote Right Left Input

Outputs

FX Send L&R Return

JFX-1

Mixer

Set-up A: With a Home / Recording Mixer.
