MF280 & MF400

CABINETS

M O D E F O U R

M O D E F O U RM O D E F O U R

ENGLISH

MODE FOUR Cabinet Options

MF280 & MF400 4x12" Cabinets

Countless hours of Research and Development went in to the development of the MF350 and it became clear

at an early stage that special cabinets would be needed to get the most from it.The MF280 (280W) and MF400

(400W) cabinets are the result of this parallel design process.Designed specifically to reproduce the balanced

mid range and huge bottom end that are a pre-requisite for extreme hard rock and nu-metal sounds, these

cabinets feature:

■

Sonically optimised Celestion loudspeaker designs

■

Pro-gauge internal wiring

■

Increased internal volume

The ultra-rugged construction has been underpinned with literally hundreds of hours of extreme endurance

(soak) testing using real life signals in real life conditions.This has assured us that these cabinets are not only

ready for the sonic demands of a high performance head like the MF350, but also the extreme physical abuse

they may receive on the road.

We recommend the MF280A (angled) and B (base) for full stack operation and the MF400A or B for half stack

operation.

Full Stack versus Half Stack

The MODE FOUR cabinets can be used either as a full stack (two cabinets) or half stack (one cabinet)

configuration.The rig you choose is a matter of personal taste and as always when it comes to sound we

recommend you try both to see which suits your style best. Below is a guide to the major attributes of each:

Full Stack:

Enhanced on stage spread.

More ‘cut through’due to accentuated treble and high mids.

Iconic stage presence.

Half Stack:

More controllable spread of sound on stage (especially base type)

Convenient and portable.

Half Stack Options

The MF400A and MF400B are 8 Ohm/400W cabinets specifically voiced for use in half stack configurations with

the Mode Four.

Whether you choose an angled or base half stack configuration is a personal choice between the different tonal

qualities of each set up.

The MF400A (angled) is, in keeping with other angled 4x12" cabinets, tonally more aggressive than the base

option.The angled cabinet is the usual choice for those who want a more prominent upper mid and treble

response that really cuts through in a live situation.

Alternatively, the MF400B (base) delivers a more even mid range with less spread of the aggressive treble

response.Marshall 4x12" base cabinets are more often used by professionals as they have a more focused

bottom end and a smoother mid range and treble response. They are often easier to deal with in terms of sound

reinforcement and monitoring in a live situation.

Cabinet Impedance & Power Handling

When connecting your loudspeaker cabinet(s) to your amplifier always ensure:

■

The total impedance of the cabinets is equal to, or greater than, the minimum rated impedance of the amplifier.

■

The total power rating of the cabinets is equal to, or greater than, the rated output power of the amplifier.

If you are unsure please contact your nearest Marshall dealer or log onto our website, www.marshallamps.com.

WARNING! - Importa
