Sida 1/2

Marshall Amplification plc

Denbigh Road, Bletchley, Milton Keynes, MK1 1DQ, England

Tel : [01908] 375411 Fax : [01908] 376118

Web Site - http://www.marshallamps.com

Whilst the information contained herein is correct at the time of publication, due to our policy of constant improvement and

development, Marshall Amplification plc reserve the right to alter specifications without prior notice.

Suggested Settings

Here follows four sample settings to act as starting points from which to develop your own sounds.

N.B. Volume and Reverb should be adjusted to taste.

Pre

amp

Master

POWER

Equalisation

Power

INPUT HEAD

PHONES

LINE

OUT

INPUT

0 10

GAIN 1

0 10

GAIN 2

0 10

TREBLE

0 10

CONTOUR

0 10

BASS

0 10

MASTER

VOLUME

0 10

REVERB

G15RCD

Pre

amp

Master

POWER

Equalisation

Power

INPUT HEAD

PHONES

LINE

OUT

INPUT

0 10

GAIN 1

0 10

GAIN 2

0 10

TREBLE

0 10

CONTOUR

0 10

BASS

0 10

MASTER

VOLUME

0 10

REVERB

G15RCD

Pre

amp

Master

POWER

Equalisation

Power

INPUT HEAD

PHONES

LINE

OUT

INPUT

0 10

GAIN 1

0 10

GAIN 2

0 10

TREBLE

0 10

CONTOUR

0 10

BASS

0 10

MASTER

VOLUME

0 10

REVERB

G15RCD

Pre

amp

Master

POWER

Equalisation

Power

INPUT HEAD

PHONES

LINE

OUT

INPUT

0 10

GAIN 1

0 10

GAIN 2

0 10

TREBLE

0 10

CONTOUR

0 10

BASS

0 10

MASTER

VOLUME

0 10

REVERB

G15RCD

CleanBluesRockMetal/Thrash

ENGLISH

1. Input Jack

Plug your guitar in here.

2. Gain 1

Providing that Gain 2 Control is kept at zero, turning

this up to around half way, i.e. around five can result

in some great clean sounds. Turning this up past

half way will result in your guitar crunching up, ideal

for vintage blues or classic rock.

3. Gain 2

This takes off where Gain 1 finishes. Having both

Gains off will result in no sound. Turning Gain 2 will

result in a distorted tone straight away. Turning up

this control even further will result in high gain

sounds, ideal for contemporary styles. Cranking up

both Gain 1 and Gain 2 will result in monster

distortion.

4. Treble

The Treble control will add or take away the higher

frequencies in your guitar tone.

5. Contour

The Contour control shifts the mid-range frequencies

in your guitar tone. By turning the Contour control

fully clockwise you will scoop most of the middle

frequencies out of your sound, ideal for thrash tones

if combined with high gain settings. By turning the

control fully anti-clockwise you can get some great

fusion type tones.

6. Bass

Turning the Bass control will effect the amount of

low frequencies or bottom end in your tone.

7. Master Volume

Controls the overall volume of the amp.

8. Reverb Control

Adding Reverb to your guitar tone will add ambience

and size, giving the effect of playing in a large empty

room or hall.

9. Headphones Jack

Plug your headphones in here. This will disconnect

the internal speaker.

10. Line Out Jack

The Line Out jack is for use for direct connection to

recording equipment or for connection to a P.A.

system.

11. CD Input

This is an input for connection to a CD player, tape

player or other auxiliary device, to allow you to play

along. This is a fixed level input, so volume of your

backing music should be adjusted on the auxiliary

unit itself.

12. Power On LED

Indicates the operating status of your combo. Red

indicates that the amp is switched on.

13. Power Switch

Switches the mains power to the combo.

From Jim Marshall

I would like to thank you personally for selecting

one of our Marshall MG Series guitar combos.

Your new amplifier has been designed by the same

team of British designers who created all of the

great Marshall amps. It is built to the customary

exacting Marshall standards and will give you an

incredible spectrum of sounds to complement a

wide range of playing styles, as well as being

designed to stand the test of time.

The Marshall name has adorned many of Britain’s

finest amps, from the early 1960’s through to the

present day. Some of the original vintage amps

have become highly sought after by both amp

collectors and working guitarists alike.

This new line of transistor guitar and bass guitar

combos have been released to unanimous acclaim.

Your combo is part of a new breed of Marshall

amplifier, which has benefited from years of

experience and continual investment in research and

development.

Not only is the sound quality of your Marshall MG

Series amp of a standard that you would only expect

to come from Marshall’s own design team. The

Marshall G15RCD also has a CD input to allow you

to play along to CD’s. The ultimate home practice

facility.

I would like to wish you every success with your

new Marshall MG Series amplifier, which I am sure

you will find a pleasure to play for years to come.

Yours Sincerely,

ENGLISH

WARNING! - Important safety instructions

PLEASE READ THE FOLLOWING LIST CAREFULLY

A. THE PLUG attached to the mains lead provided is wired in accordance with the following colour code:

Blue Brown -Neutral. -Earth. Green/Yellow -Live (UK Only).

B. ALWAYS ensure that the value of the fuse corresponds to the rating marked on the plug.

C. DO NOT use your Marshall MG amp in damp or wet conditions.

D. ALWAYS have this equipment serviced or repaired by competent, qualiﬁed personnel.

E. PLEASE READ this instruction manual carefully before switching on.

F. WARNING This apparatus must be earthed.

G15RCD Front Panel Features

Pre

amp

Master

POWER

Equalisation

Power

INPUT HEAD

PHONES

LINE

OUT

INPUT

0 10

GAIN 1

0 10

GAIN 2

0 10

TREBLE

0 10

CONTOUR

0 10

BASS

0 10

MASTER

VOLUME

0 10

REVERB

G15R CD

12 3 4 5 6 7 8 9 10 12 1311
