Sida 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• Dynamic Cooling Technology™ air fl ow system ensures even circulation
and optimal cooling environment for longer lasting food preservation
• Digital controls offer precise temperature stability within one degree
• Energy-effi cient variable speed compressor chills food quickly while
saving energy
• One of the quietest, technologically advanced compressors available
• Integrated ion air purifi er eliminates airborne bacteria and mold spores,
removes odors and enhances food preservation – and it never degrades
or needs replacing
• Moisture-control evaporator removes excess humidity
• Maintenance-free anti-clog condenser coil prevents dust and other
airborne particles from clogging the condenser
Storage Capabilities
• 20.4 total cubic feet storage capacity
REFRIGERATOR
• 15.3 cubic feet refrigerator capacity
• Seamless glass shelves feature spill-proof Nano technology that
contains spills and makes clean up easy
• 3/8” thick tempered glass shelves provide industry-leading durability
• 2 moisture-adjustable drawers feature soft-close slides and high/low
settings for the freshest leafy vegetables and fruits
• 2 deli drawers with soft-close slides store meats and cheeses
• 4 metal door bins provide enduring performance to securely store heavy
items – and 3 are adjustable
• 2 dairy compartments in the door with easy-view covers
• Also features additional space for extra-large 18” pizza box storage
FREEZER
• 5.1 cubic feet freezer capacity
• Full-extension bottom freezer drawer glides out quietly and easily on ball-
bearing rollers to access bulky frozen foods
• Positive self-closing drawer ensures a good seal
• Factory installed automatic crescent ice maker with large-capacity ice bin
Touchscreen Controls
• Fast Cool: cools the refrigerator at high speed for 2 hours
to rapidly chill contents
• Max Refrigerator Mode: adjusts refrigerator temp to the coldest setting
for 4 hours
• Max Freezer Mode: adjusts freezer temp to the coldest setting
for 6 hours to freeze contents faster
• Door Open Alarm: alerts when door is left open for more than 3 minutes
• Power Loss Alarm: POWER indicator light fl ashes, in the case of a
power loss
• High Temperature Alarm: alerts when freezer temp is too high
for 2 hours
• Temperature Sensor Alarm: alerts of temperature sensor problems
• Sabbath Mode: disables interior lights and alarms for observance
of the Sabbath
Marvel Professional Built-in
36” Bottom Freezer
Model # MP36BF2
Solid Overlay
(Panel Ready)*
Stainless Steel
Finish Options
Optional
Professional Handle
Aesthetics
• Graduated theater lighting with bright,
energy-effi cient LED illumination from top
and sidewalls for better visibility
• Robust hinge allows optimal door rotation
and maximum durability
• Adjustable door stops at 90, 110 and 120
degrees
Additional Convenience
• 2-year full product warranty, 6-year full sealed
refrigeration system warranty, 90-day full
cosmetic parts and 12-year limited sealed
refrigeration system warranty
Ordering Options
Solid Stainless Steel Door, Right
Hinge, Slim Designer Handle MP36BF2RS
Solid Stainless Steel Door,
Left Hinge, Slim Designer Handle MP36BF2LS
Panel-Ready Solid Overlay Door,
Right Hinge,
(Handle Not Included)*
MP36BF2RP
Panel-Ready Solid Overlay Door,
Left Hinge,
(Handle Not Included)*
MP36BF2LP
Optional Accessories
Professional Handle - Vertical
Door Installation (qty 1)
42249470
Professional Handle - Horizontal
Freezer Door Installation (qty 1)
42249471
Flush Mount Trim Kit PBIRFTKSS
*Consult your cabinet maker for overlay panel and
handle options
Slim Designer
Handle Shown
(MP36BF2RS)
marvelrefrigeration.com | 800.223.3900
9”
(22.9 cm)
73-3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board &
opening height
84–1/16”
(213.5 cm) max.
anti-tip board &
opening height
35–5/8”
(90.5 cm) min.
to
35–3/4”
(90.8 cm) max.
36”
(91.5 cm)
PFlush Mount only
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.6 cm)
5/8”
(1.6 cm)
10–1/2”
(26.7 cm)
5/8”
(1.6 cm)
10–3/4”
(27.3 cm)
1”
(2.5 cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
35–5/8”
(90.5 cm)
36”
(91.5 cm)
Flush Mount only
See Anti-Tip board installation
6”
(15.2 cm)
9”
(22.9 cm)
15.3 cu. ft. (434 liters)
5.1 cu. ft. (145 liters)
Width 36” (91.5 cm)
Overall Height
(from bottom)
82-3/4” (210.2 cm) min to
84-1/16” (213.5 cm) max
Depth to front edge
of side trim 22-3/16” (56.4 cm)
Depth to front of
top grille 24” (61.0 cm)
Depth to front of
handle endcap 26-1/2” (67.3 cm)
Cutout Width 35-5/8” (90.5 cm) min to
35-3/4” (90.8 cm) max
Cutout Height 82-7/8” (210.5 cm) min to
84-1/16” (213.5 cm) max
Cutout Depth 24” (61.0 cm) min
Electrical
Requirements
115 volt, 60 Hz, 15 amp
dedicated circuit; 3-wire
cord with grounded
3-prong plug attached to
product
Maximum Amp Usage 9.9 amps
Water Requirements
1/4” copper tubing inlet
waterline; minimum 20
psi; maximum 120 psi
Length of Power Cord 4 1/2 ft. (137 cm)
Total Capacity 20.4 cu. ft. (578 liters)
Refrigerator Capacity 15.3 cu. ft. (434 liters)
Freezer Capacity 5.1 cu. ft. (145 liters)
Approximate Shipping
Weight 565 lb. (256.3 kg)
Interior Finish Arctic White
Shelving System Spill-proof sealed 3/8”
thick glass shelves
Shelf Fronts Arctic White
Other Storage Bottom Storage for Extra-
Large Pizza Box
Interior Lighting White LED Lighting
(Top, Sidewalls)
Toe Grill Finish Stainless Steel
Hinge Zero Clearance
Handle
Designer
(Handle not included on
Overlay Models)
Control Type Digital Controls
Temperature Range
REFRIGERATOR:
33°F to 43°F
(0.6°C to 6°C)
FREEZER: -5°F to 5°F
(-20.6 °C to -15°C)
Lock No
Finishes Stainless Steel, Overlay
Agency Approvals UL
Marvel Professional Built-in
36” Bottom Freezer
Model # MP36BF2
*Specifi cations subject to change without notice.
This spec sheet is intended only for quick reference.
For complete installation details, consult the owner’s
guide on marvelrefrigeration.com.
