Quick Start Guide

Please use this quick start guide in conjunction with the operating

manual following the recommended safety precautions.

Your FTA receiver is pre-programmed with channels from several different satellites.

The majority of UK channels are broadcast from the Astra 2 satellite. This guide will show you:

How to display only ASTRA 2 channels

Use your receiver to help position your satellite antenna

Scan for new TV and Radio channels

Change the menu language

Important

If your FTA Receiver is reset to the factory default setting the OSD

language reverts to German and channel list is modified.

If this occurs please follow the simple steps in this guide to revert back to UK Specifications

If your receiver has been reset to the factory default setting

and this screen is shown when the receiver is tuned on

you will need to change the language setting from

German to English

Press the button on the remote.MENU

Press the key until this screen is VOLUME UP/DOWN

shown.

Press the key until the Sprache CHANNEL UP/DOWN

box is highlighted.

Press the button to select.OK

Press the keys until the CHANNEL UP/DOWN

Sprache box is highlighted.

Use the keys to scroll through the languages.VOLUME

When English has been highlighted press .EXIT

MXL014

FOR USE IN THE UK

& CENTRAL EUROPE

1 YEAR

GUARANTEE

For more information on our

vast range of leisure products,

please request a copy of our

leisure catalogue.

Maxview Limited (UK head office) ■Common Lane ■Setchey ■King’s Lynn ■Norfolk ■PE33 0AT ■England

Customer Helpline +44 (0)1553 811000■e-mail cust_serv@maxview.co.uk ■website www.maxview.co.uk

Maxview reserve the right to change specifications without prior notice. MXL014L Iss 1

‘FREE TO AIR’ DIGITAL

SATELLITE RECEIVER

Change language

Set up diagram

This is a simple set-up example, please refer to the

user manual for more set-up examples and detailed

information about using this product in a safe manner.

Note: Ensure TV is set to the AV channel. Please refer

to your TV instruction manual for more information.

Install your satellite antenna referring to the operating

manual supplied with it and install your FTA receiver as

shown previously. Follow these simple steps to find the

Astra 2 satellite.

When you first turn your FTA receiver on this screen

will be shown.

Press the blue button on the remote control to edit LIST

the .TV Channel List

The default channel list includes channels from a wide

range of satellites. The majority of UK channels are

broadcast from the Astra 2 satellite.

This menu allows you to edit the so that TV Channel List

it displays channels from the Astra 2 satellite only.

Press the key to scroll through the VOLUME UP/DOWN

various satellites and groups until ASTRA 28 EAST is

displayed below the TV Channel List title.

Press the button.EXIT

Note: You will only have to do this once. The receiver will

memorise the menu change even when the power has

been disconnected.

To select a channel, press the button on the remote OK

control to display the .TV Channel List

Scroll through the pages of channels using the

VOLUME UP/DOWN keys.

Use the button to select your CHANNEL UP/DOWN

channel and press .OK

To help with the alignment of your satellite dish press

the button on the remote control.INFO

Press on the remote to turn on the built-in sat-finder. 1

The tone from the Sat-finder will rise in pitch when a

satellite signal is received.

Follow the operating instructions supplied with your dish

antenna when finding a satellite.

When you have found the Astra 2 satellite press .EXIT

When the antenna has been successfully positioned to

receive Astra 2 follow these steps to add the latest channels.

Press the button on the remote control.MENU

Select the menu using the Installation VOLUME UP/

DOWN key.

Highlight using the key Auto Scan CHANNEL UP/DOWN

and press .OK

Scroll down the menu using the Auto Scan

CHANNEL DOWN key.

Use keys to ensure: VOLUME UP/DOWN

Satellite is set on ASTRA 28 EAST

Scan mode is set on Free

Scan channel is set to TV + Radio

Then highlight and press Search OK

Searching for channels may take several minutes.

When complete press EXIT.

Your receiver now contains the latest Free to View

channels from the Astra 2 satellite.

Note: We advise you scan for new channels periodically.

Scan for new TV and Radio channels

Display only Astra 2 channels

Aligning your satellite antenna
