Quick Tips 2003 Mazda Mazda6 page 20
page 1
Revised October 30, 2002
M A I N T E N A N C E S C H E D U L E
©2002 Calcar, Quick Tips
®is a trademark
of Calcar, made in USA 9/02 74.01M GL
Mazda North American Operations reserves
the right to change product specifications at
any time without incurring obligations.
Normal maintenance notes
Rotate tires every 7,500 miles or
sooner if needed; replace cabin air
filter every 25,000 miles or 24
months
A. Change: Engine oil/replace filter
Lube: Locks and hinges
B. Inspect: Disc brakes
C. Inspect: Drive belts, fuel lines
and hoses, brake lines and
hoses, steering operation and
linkages, front suspension ball
joints, driveshaft dust boots,
chassis and body bolts, exhaust
system and heat shields
D. Inspect: Drive belts (2.3 liter)
Replace: Air filter
E. Inspect: Hoses and tubes for
emission system
F. Replace: Spark plugs
* See Owner’s Manual
Your Mazda comes with a 48
month/50,000-mile limited warranty
This Quick Tips®guide is provided
by Mazda North American
Operations to make your Mazda
ownership experience more
convenient. It is not intended to
replace your Owner’s Manual.
If you have any questions about
your vehicle, you are invited to
contact your local dealer.
Or if you need additional help,
feel free to call our
Customer Assistance Center
at 1-800-222-5500
Monday through Friday,
9 a.m.- 4 :45 p.m., Pacific
9 a.m.-5:45 p.m., Eastern/Central
Unique driving conditions*
Every 5,000 miles change oil/filter,
inspect coolant level, lights, brake/
clutch fluid, tire pressure/wear,
power steering fluid, locks/hinges
and washer fluid
7,500 miles
15,000 miles
22,500 miles
30,000 miles
37,500 miles
45,000 miles
52,500 miles
60,000 miles
67,500 miles
75,000 miles
82,500 miles
95,000 miles
A
A
A F
A
A B C E
A
A
A D
A B C
A
A B
A
2 0 0 3
Reference
Guide for
Controls and
Functions
Quick Tips®
®
MAZDA6
MAZDA6
D R I V E R ’ S V I E W
1. Power window switches,
see Switches
2. Power door locks, see Locks
3. Dual power mirrors,
see Switches
4. Traction Control
System*, see Under Hood
5. Air vents
6. Turn signal/lighting control
lever, see Driver Controls
7. Instrument panel
lighting
To brighten/dim turn
thumb-wheel up/down
8. Horn/Air bag
9. Wiper/washer control
lever, see Driver Controls
10. Storage
11. Information display,
see Owner’s Manual
Tip: Dimmer cancel function
increases display intensity
12. Hazard warning
switch, Press on/off
13. Audio system,
see Audio Systems
14. Rear window defogger
Press on/off; shuts off with
ignition; also operates heated
side mirrors*
15. Climate control panel,
see Climate Controls
16. Gearshift lever (A/T)*,
see Transmission
17. Cup holder
18. Heated seats*,
see Interior Lights/Console
19. Console, see Interior
Lights/Console
20. Accessory socket
21. Parking brake lever,
see Interior Lights/Console
22. Cruise control,
see Driver Controls
23. Tilt/telescopic steering-
wheel lever
Pull lever down to unlock column,
position tilt angle and length of
steering column position
Tip: Telescopic function
allows steering wheel to be
adjusted closer or farther
according to driver’s reach
24. Audio control switches*,
see Driver Controls
25. Remote trunk-lid
release
Push to open trunk;
main switch in glove box
must be ON, see Trunk
26. Hood release handle
27. Bottle holder
CAUTION: Use plastic bottles
with caps, cups may spill
when door is closed
28. Remote fuel-door
release
Driver’s
View
Quick Tips 2003 Mazda Mazda6 page 2
page 3
Revised October 30, 2002
Key
Operates ignition and
all locks
Tip: Use key number
plate to purchase new
key; store in safe place
Immobilizer system
Prevents engine from
running unless coded key
used; see Owner’s Manual
Remote keyless
entry system,
see Locks
H F
EC
20
x1000rpm/m
40
60
80 100
120
140
6010
1
2
345
6
7
8
P
R
N
DM
0
123
4
9
13
14
12
5
15
17
26
27
25 2224 23
86 752 431
16
10
28
19
20
21
10
11
18
LOCK
UN
LOCK
*Denotes optional equipment
Always check the Owner’s Manual for more operating information and safety features
I N S T R U M E N T C L U S T E R
Always check the Owner’s Manual for more operating information and safety features
Instrument
Cluster
Instrument
Cluster
Quick Tips 2003 Mazda Mazda6 page 4
page 5
Revised October 30, 2002
H F
E
C
20
mph
40
60 80 100
120
140
160
P
R
N
D
M
2
1 212 121413 1511
0
1
2
3
x1000rpm/m
45
6
7
8
TRIP
A
8
O.O
202123 222426 1925 5 64
10
8
7
9
16
3
18
17
21. Charging system
warning light
Dealer inspection required
22. Engine oil pressure
warning light
23. Air bag readiness
Front, side and curtain air bag
malfunction; warning light
constantly flashes or stays on
or never comes on with ignition
on, dealer inspection required
24. Door ajar
25. Immobilizer system on,
see Driver’s View
26. Always fasten
safety belts
7. Instrument cluster
dimmer select button
Press to increase display intensity
8. Engine coolant
temperature gauge
If above normal range, stop
vehicle and turn off engine,
check coolant level when safe
14. High beams on
15. Traction Control
System*,
Light flashes when in use;
dealer inspection required if
light remains on
16. Lights on
17. Traction Control
System* off,
System turned off manually
or malfunctioning; dealer
inspection required
18. Low fuel
19. Brake system
Parking brake on/low fluid level
20. Check engine
Dealer inspection required
6. Odometer/trip odometer
selector
Press to select among trip A,
trip B, and odometer
Press and hold to reset selected
trip meter
WARNING LIGHTS
9. Cruise control,
see Driver Controls
10. Cruise Control
Main Power On,
see Driver Controls
11. Anti-lock Brake
System (ABS)*
ABS malfunction, normal brakes
only, dealer inspection required
12. Turn signals/hazard
warning on
13. Automatic transaxle
indicator
Dealer inspection required
if light remains on
CRUISE
MAIN
GAUGES
1. Tachometer
2. Speedometer
3. Fuel gauge
4. Odometer/trip odometer
5. Manual mode gear
indicator*
Displays current gear of Sport
AT during manual shift mode
*Denotes optional equipment
