METRA. THE WORLD’S BEST KITS.™
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
APPLICATIONS
1-800-221-0932 metraonline.com
INSTALLATION INSTRUCTIONS FOR PART 95-7881G
REV. 12/01/11
WIRING & ANTENNA CONNECTIONS (Sold Separately)
Wiring Harness: • 70-1729 - Honda harness 2008-up
Antenna Adapter: • 40-HD11 - Honda antenna adapter 2009-up
Panel Removal Tool • Phillips Screwdriver • Socket Wrench
TOOLS REQUIRED
• A) Radio Trim Panel • B) Radio Brackets • C) (6) Panel Clips • D) (6) #8 x 3/8” Truss-head Phillips screws
• E) (2) #8 x 1/2” Pan-head Phillips screws
KIT FEATURES
KIT COMPONENTS
• DDIN Head unit provisions
• Painted to match factory finish
B C D
E
A
Table of Contents
Dash Disassembly
– Honda Civic 2012-up 3
Kit Assembly
– DDIN head unit provisions 4
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most cognized and spected re re
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
Metra recommends MECP
certified technicians
95-7881G
Caution
Metra recommends disconnecting the negative battery terminal before beginning any
installation. All accessories, switches, and especially air bag indicator lights must be
plugged in before reconnecting the battery or cycling the ignition.
*NOTE: Refer also to the instructions included with the aftermarket radio.
1. Remove instrument cluster surround
panel. (Figure A)
2. Remove (2) Phillips screws securing
accessory power socket panel.
(Figure B)
3. Remove (2) 8mm/Phillips screws from
under radio chassis. (Figure C)
4. Remove radio from dash and
disconnect harnesses.
Continue to kit assembly
Dash Disassembly
95-7881G
(Figure A)
(Figure B)
(Figure C)
