METRA. The World’s best kits.®metraonline.com © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
REV. 11/14/2017 INST99-3310B
Installation instructions for part 99-3310B
®
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
U.S. PATENT # D755,779
• ISO DIN radio provision with pocket
• Painted black
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • See www.metraonline.com for harness information
Antenna Adapter: • 40-CR10
• Panel removal tool • Phillips screwdriver • 9/32” socket wrench
TOOLS REQUIRED
Dash Disassembly ................................................. 2
Kit Assembly
– ISO DIN radio provision with pocket 3 ......................
Table of Contents
AB C D
99-3310B
®
Dash Disassembly
(Figure A) (Figure B)
(Figure C)
1. Unclip and remove the radio
trim panel including the climate
controls, then unplug the climate
controls and remove the panel.
(Figure A)
2. Remove (2) 9/32” Screws securing
the hazard switch assembly.
(Figure B)
3. Remove (4) 9/32” Screws securing
the radio then unplug and remove
the radio. (Figure C)
Continue to kit assembly
99-3310B
®
Kit Assembly
ISO DIN radio provision with pocket
1. Slide the into the radio brackets
radio trim panel aligning the holes
in the trim panel to the clips on the
brackets. (Figure A)
2. Mount the to the radio pocket
brackets/trim panel assembly with
the (4) #8 x 3/8” Phillips screws
supplied. (Figure B)
3. Slide the radio into radio brackets/
trim panel assembly and secure
with the screws supplied with the
aftermarket radio. (Figure C)
4. Locate the factory wiring harness
and antenna plug in the dash.
Metra recommends using the
proper mating adapters from Metra
and/or AXXESS.
5. Mount the new radio assembly into
the dash and reassemble dash in
reverse order of disassembly.
(Figure A) (Figure B) (Figure C)
