Metra. The World’s Best Kits.®MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 11/25/19 INST99-8731
I N S TA L L AT I O N I N S T R U C T I O N S
99-8731
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DIN radio provision with pocket
• Polished gloss black to match the factory finish
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) #8 x 3/8” Phillips pan-head screws (4) • E) #8 x 3/8” Phillips flat-head screws (4)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Torx T-20 screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly ..........................................................3
A B C D E
Mercedes Sprinter† 2019-Up
Visit for more detailed information about the product and up-to-date vehicle MetraOnline.com
specific applications
† Excluding models with a touchscreen radio
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wire Harness: See metraonline for harness and
interfacing solutions
Antenna Adapter: 40-EU10
1.800.221.0932
|
MetraOnline.com
2
1. Unclip and remove the radio trim panel.
(Figure A)
2. Remove (4) Torx T-20 screws securing
the radio and pocket assembly. Slide the
assembly out, then unplug and remove.
(Figure B)
Continue to Kit Assembly
(Figure A) (Figure B)
DASH DISASSEMBLY
REV. 11/25/2019 INST99-8731 3
(Figure B) (Figure C)(Figure A)
KIT ASSEMBLY
1. Secure the radio brackets to the radio
trim panel using (4) #8 x 3/8” Phillips
pan-head screws provided. (Figure A)
2. Slide the into the bracket/panel pocket
assembly, then secure using (4) #8 x
3/8” Phillips flat-head screws provided.
(Figure B)
3. Remove the metal DIN sleeve and trim
ring from the aftermarket radio.
4. Slide the radio into the bracket/panel
assembly, then secure using screws
supplied with the radio. (Figure C)
5. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
6. Slide the radio assembly into the dash,
then secure using the factory screws.
7. Attach the factory radio trim panel to
complete the installation.
