Sida 1/20

English

Index 1

INDEX

Introduction 2

Coverage 2

Batteries 2

Care of optional Ni-Cd rechargeable batteries 2

To enjoy your radio for a long time 3

Accessories 3

Controls and indicators 4

How to use your ALAN 456 8

Voice-controlled transmit mode (VOX) 9

Manual transmit mode (PTT) 10

Main features 10

Roger Beep: end-transmission note 10

Keypad /switching on beep 11

Use of ALAN 456 as Babyphone 11

INTERCOM function 12

SCAN function 12

CTCSS (Continuous Tone Coded Signalling System) 13

DCS (Digital Code Squelch) 14

DW function (Dual Watch) 15

Channels memorisation 15

Power Save 16

Battery level 16

Reset 16

Summary table 17

Technical speciﬁcations 18

Restrictions to the use 20

2Introduction

INTRODUCTION

ALAN 456 is a new generation handheld transceiver PMR 446

type. It can be used without license in all countries where

PMR 446 frequencies are authorised.

Coverage

The operating band (446Mhz) allows clear communication,

virtually free from atmospheric interferences and -despite the

low power - will allow you to communicate up to a distance

of 5 km (under optimum conditions).

The only limit to maximum possible range are environmental

factors such as blockage caused by trees, buildings, hills, or

other obstructions. If you find communication is not possible,

many times this can be solved by moving a few meters to a

new location. Range is also reduced while operating in a

vehicle or metal building.

Batteries

The radio uses 3 AA type alkaline (dry) or 3 AA Ni-Cd

rechargeable batteries.

• Do not leave batteries installed over a long period of time

as leakage may occur and this can destroy the radio.

This operation, besides, preserves battery life.

• Never use different batteries from the ones suggested.

Attention: to obtain proper operation, batteries must be in

good condition and fully charged.

Care of optional rechargeable Ni-Cd batteries

The following is meant as general information regarding Ni-

Cd batteries.

• Allow the batteries to fully discharge before recharging.

Full discharge will be indicated by flashing on the

display.

• Always allow the battery to fully charge before using to

prevent the batteries from developing “memory”, which

eﬀectively reduces their capacity.

• It is better to store Ni-Cd batteries that are discharged

rather than charged.

• Never use batteries which differ from the ones

recommended. Do not mix old and new batteries or

rechargeable batteries of different capacities.

English

Accessories

ALAN 456 is equipped with jack for external speaker

microphone, intercom system and charge jack for Ni-Cd

batteries.

To enjoy your radio for a long time

• While ALAN 456 has been designed for many years of

reliable, trouble-free performance, it is a precision piece

of electronic equipment that should not be exposed to

moisture, dust or extreme temperatures.

• Do not connect the unit to a power higher than the working

one.

• To power the radio by the car, do not use a cigarette

lighter adapter: use “AL25” charger only.

• Clean the unit with a damp cloth only; do not use harsh

chemicals.

Introduction 3
