KNOT LR8/LR9 kit
An out-of-the-box IoT Gateway solution for LoRa® technology.
For ultimate versatility and cost-eectiveness.
CAT-M/NB
technology
2.4 GHz
wireless
Bluetooth 2x 100 Mbps
Ethernet ports
PoE-in &
PoE-out
MicroUSB GNSS GPIO RS485/Modbus
LoRa ® 868MHz or
915MHz
The first gateway with a CAT-M interface for LoR!
4
KNOT LR8/LR9 kit
Product code RB924i-2nD-BT5&BG77&R11e-LR8/LR9
CPU QCA9531 650 MHz
Number of 100 Mbps Ethernet ports 2
Number of 100 Mbps Ethernet ports with PoE-out 1
Size of RAM 64 MB
Storage 128 MB flash SPI NAND
Concentrator Gateway card for LoRa® R11e-LR8/R11e-LR9
Wireless 2.4 GHz 802.11 b/g/n dual-chain
Antenna gain 1.5 dBi
Bluetooth antenna gain 2 dBi
Antenna beam width 360°
Bluetooth Version 5.2
Dimensions 122 x 87 x 26 mm
Operating system RouterOS, License level 4
USB port 1 microUSB port type AB
SIM slots 1 Nano SIM
Built-in GPS Yes (GPS, GLONASS, BeiDou, Galileo)
Operating temperature -40°C to +70°C
Specifications
Narrow Band and CAT-M technology is supported by many operators around the world!
* According to the 3GPP deployment map, Feb 2021 https://www.gsma.com/iot/deployment-map/
6
KNOT LR8/LR9 kit
Included parts
24 V 1.2 A
power adapter
Wall mount
set
DIN rail
mount set
USB A Female to
Micro B cable
R11e-LR8/R11e-LR9 specifications
Product code R11e-LR8 R11e-LR9
Interface Mini-PCIe
Supported class A and C
Frequency 863-870 MHz (EU863-870, RU864-870,
IN865-867)
902-928 MHz (AU915-928, US902-
928, AS923, KR920-923)
RF Output power 863-870 MHz 14 dBm 902-928 MHz 23 dBm
Receive max sensitivity -137 dB @ SF12
Range Up to 15 km in rural environment and up to 2 km in urban environment when using
MikroTik LoRa® 6.5 dBi antenna kit
Operating ambient
temperature -40°C .. +70°C
Max power consumption 2 W
