LITHIUM - Coin Type

Coin type lithium batteries are high energy, high reliability batteries for a variety of

applications. The full 3 volts in these high energy density batteries is about twice that of

conventional dry batteries.

Panasonic coin type lithium batteries are available in

two types: poly-carbonmonouoride lithium batteries

(BR series) for uses that require extended reliability

and safety, and manganese dioxide lithium batteries

(CR series) for uses that require high voltage and

strong load pulse characteristics.

The CR Lithium primary coin cells contain

Perchlorate over the limit specied by the state

legislature of California and are therefore subject to

requirements in the California Code of Regulations,

title 22, division 4.5: Chapter 33 – Best Management

Practices for Perchlorate Materials.

Features:

High voltage of 3 volts - twice that of conventional dry batteries

Extremely small self-discharge for long service and shelf life

A wide operational temperature range

Compact and lightweight; extremely high energy density per unit weight

Very safe (poly-carbonmonouoride lithium)

Extremely strong load pulse characteristics (manganese dioxide lithium)

Operating temperature range:

BR Coin Cells: -30ºC ~ +80ºC

CR Coin Cells: -30ºC ~ +60ºC

Calculators

Cameras

Compact, low power consuming cordless applications

Electronic translators

Electronic watches (digital and analog)

Memory back-up in all types of devices (with tab terminals)

Technical Data - Table 1 - (CF)n/LI: Poly-Carbon Monouoride (BR)

Model

No.

Electrical

Characteristics

(20ºC)

Standard Load Dimensions

Tab Congurations

Nominal

Voltage

(V)

*Nominal

Capacity

(mAh)

Continuous

Drain

(mA)

Diameter

(mm)

Height

(mm)

Weight

(g)

BR1220 3 35 0.03 12.5 2.00 0.7

BR1225 3 48 0.03 12.5 2.50 0.8

BR1632 3 120 0.03 16.0 3.20 1.5

BR2032 3 190 0.03 20.0 3.20 2.5

BR2325 3 165 0.03 23.0 2.50 3.2

BR2330 3 255 0.03 23.0 3.00 3.2

BR3032 3 500 0.03 30.0 3.20 5.5

* Nominal capacity shown is based on standard drain and cut o voltage down to 2.0V at 20ºC.

Technical Data - Table 2 - Mn0 /LI:Manganese Dioxide (CR)2

Model

No.

Electrical

Characteristics

(20°C)

Standard Load Dimensions

Tab Congurations

Nominal

Voltage

(V)

*Nominal

Capacity

(mAh)

Continuous Drain

(mA)

Diameter

(mm)

Height

(mm)

Weight

(g)

CR1025 3 30 0.10 10.0 2.50 0.7

CR1216 3 25 0.10 12.5 1.60 0.7

Applications:

AUGUST 2005

LITHIUM HANDBOOK
