o w n e r s m a n u a l

Silver Series2

Contents

Introduction 2

Spikes and Feet 3

For Wooden/Hard Floors 3

Setting Up 3

2 Channel Positioning 3

AV Positioning 4

Setting up the Silver FX 4

Atmos 5

Fixing the Silver FX to a wall 5

Wiring 6

Single Wiring 6

Bi-Wiring 6

Bi-Amping 6

The Effects of Bi-Wiring and Bi-Amping 7

Port bungs 7

Running-In Your Speakers 8

Retention Bolt Adjustment 8

Guarantee 8

Owner Information 8

Speciﬁcations 9

Introduction

The revered Silver Series is now entering its sixth generation, introducing groundbreaking design

throughout the entire range. Each model has been developed to provide a wider appeal to audiophiles

and home cinema enthusiasts alike, whilst elevating performance to a new level. Two new centre speakers

now make it possible to assemble stylish, discrete or large, powerful home theatre systems. Silver 50 and

Silver 200 models are more compact, providing a more attractive proposition for modern living spaces, yet

delivering the same kind of performance expected from much larger speakers. Silver 50 and Silver 200 can

be combined with the compact Silver C150 centre speaker, tonally matched and visually discrete to form a

compact high-performance multi-channel system. The Silver C350 centre now provides the ability to create

a no-compromise home theatre system, based around the Silver 100, Silver 300 or Silver 500 models.

ENGLISH

monitoraudio.com 3

Spikes and Feet

Select ﬁnishes are supplied with a foam gasket on the out-rigger, please ensure this side

is placed on the cabinet.

For Wooden/Hard Floors

(Silver 200, 300 and 500 only)

The feet and ‘out-riggers’ are supplied assembled for use on non-

carpeted, wooden or hard ﬂoors or where spikes are inappropriate.

All that is required is to ﬁx them to the speaker base using the

supplied bolts (A & B).

You can check that the speaker is level on all sides by using a spirit

level. If it’s slightly off-level, unscrew the foot at the lowest point and

check again. Continue this process until the cabinet is fully level.

Use the locking nuts on each foot to ﬁx the feet in place and to stop

any unwanted vibrations.

For Carpeted Floors

(Silver 200, 300 and 500 only)

If the speaker is being installed on a carpeted ﬂoor, screw the spike

into the foot and ‘out-rigger’ assembly. Fix them to the speaker

base using the supplied bolts (A & B).

You can check that the speaker is level on all sides by using the

spirit level. If it’s slightly off-level, unscrew the foot at the lowest

point and check again. Continue this process until the cabinet is

fully level. Use the locking nuts on each foot to ﬁx the feet in place

and to stop any unwanted vibrations.

Please ensure there are no hidden wires under the

carpet that could be damaged by the spikes.

Setting Up

2 Channel Positioning

When arranging a 2 channel system, the listening position and the loudspeakers should form an equilateral

triangle. The speakers should be positioned approximately 6 - 10 feet (1.8 - 3m) apart. The ideal distance

from the rear wall varies depending on the speaker (see list below), however, they need to be a minimum of

3 feet (91cm) from the side walls.

• Silver 50 6 - 12 inches (15 - 30cm)

• Silver 100 & 200 8 - 14 inches (20 - 36cm)

• Silver 300 & Silver 500 12 - 24 inches (30 - 61cm)

NOTE: These are recommended distances for optimal performance. Actual results will vary dependant on

room size and construction.

Experimentation is strongly advised when initially setting up the speakers, as environment and personal

preference differ with every installation. If there is insufﬁcient bass for example, try moving your speakers

closer to a wall. The opposite approach is recommended if there is excess bass. Also see the information

on page 7 referring to Port Bungs. If stereo imaging is being lost, try ‘toeing’ them in slightly. The

sound should appear to originate from the centre point between the speakers, not the actual speakers

themselves.

Spike

(A) (B)

Polymer Pad

Main

Threaded

Assembly

Bottom

Locking

Nut

Out-Rigger

Foam Gasket

Top Locking Nut
