Owners Manual

Contents

Spikes and Feet 2

For Wooden/Hard Floors 2

For Carpeted Floors 2

Setting Up 2

2 Channel Positioning 2

AV Positioning 3

Setting up the Silver FX 3

Silver AMS Dolby Atmos® Enabled Speakers 4

Fixing Silver FX & Silver AMS to a Wall 4

Wiring 5

Single Wiring 5

Bi-Wiring 5

Bi-Amping 5

The Effects of Bi-Wiring and Bi-Amping 6

Port bungs 6

Running-In Your Speakers 6

Retention Bolt Adjustment 7

Warranty 7

Owner Information 7

Specications 8

monitoraudio.com 1

English

Silver Series 7G2

Spikes and Feet

Select nishes are supplied with a foam gasket on the out-rigger, please ensure this side is placed on the

cabinet.

For Wooden/Hard Floors

(Silver 200, 300 and 500 only)

The feet and ‘out-riggers’ are supplied assembled for use on non-

carpeted, wooden/ hard oors or where spikes are inappropriate. All

that is required is to x them to the speaker base using the supplied

bolts and hex keys.

You can check that the speaker is level on all sides by using a spirit level

(not supplied). If it’s slightly off-level, unscrew the foot at the lowest

point and check again. Continue this process until the cabinet is fully

level. Use the locking nuts on each foot to x the feet in place and to

stop any unwanted vibrations.

For Carpeted Floors

(Silver 200, 300 and 500 only)

If the speaker is being installed on a carpeted oor, screw the spike into

the foot and ‘out-rigger’ assembly. Fix them to the speaker base using

the supplied bolts and hex keys.

You can check that the speaker is level on all sides by using the spirit

level. If it’s slightly off-level, unscrew the foot at the lowest point and

check again. Continue this process until the cabinet is fully level. Use

the locking nuts on each foot to x the feet in place and to stop any

unwanted vibrations.

Please ensure there are no hidden wires under the carpet that

could be damaged by the spikes.

Setting Up

2 Channel Positioning

When arranging a 2 channel system, the listening position and the

loudspeakers should form an equilateral triangle. Ideally the speakers

should be positioned approximately 6 - 10 feet (1.8 - 3m) apart and a

minimum of 3 feet (91cm) from the side walls. The ideal distance from

the rear wall varies depending on the speaker (see list below).

• Silver 50 6 - 12 inches (15 - 30cm)

• Silver 100 & 200 8 - 14 inches (20 - 36cm)

• Silver 300 & Silver 500 12 - 24 inches (30 - 61cm)

NOTE: These are recommended distances for optimal performance.

Actual results will vary dependant on room size and construction.

Experimentation is strongly advised when setting up the speakers, as

environment and personal preference will differ with every installation.

If there is insufcient bass for example, try moving your speakers closer

to the rear wall. The opposite approach is recommended if there is excess bass. Also see the information on

page 6 referring to Port Bungs. If stereo imaging is being lost, try ‘toeing’ them in slightly. The sound should

appear to originate from the centre point between the speakers, not the actual speakers themselves.

xm xm

M10

X 1.25 mm M4

M10

X 1.25 mm M4
