Sida 1/25
ACPA005
MANUAL (p. 2)
12 -24 V 40 W UNIVERSAL ADAPTER
MODE D’EMPLOI (p. 5)
ADAPTATEUR UNIVERSEL DE HAUTE
QUALITé 12-24 V 40 W
MANUALE (p. 8)
ALIMENTATORE UNIVERSALE
12 - 24 V 40 W
BRUKSANVISNING (s. 15)
12-24 V 40 W UNIVERSALADAPTER
MANUAL DE UTILIZARE (p. 18)
ADAPTOR UNIVERSAL 12-24 V 40 W
BRUGERVEJLEDNING (p. 22)
12-24 V 40 W UNIVERSEL ADAPTER
HASZNÁLATI ÚTMUTATÓ (o. 12.)
12 -24 V 40 W UNIVERZÁLIS
ADAPTER
KÄYTTÖOHJE (s. 13)
12-24 V 40 W YLEISKÄYTTÖINEN
VIRTALÄHDE
ANLEITUNG (s. 3)
12-24 V 40-W- UNIVERSALNETZTEIL
GEBRUIKSAANWIJZING (p. 7)
12-24 V 40 W UNIVERSELE ADAPTER
MANUAL DE USO (p. 10)
ADAPTADOR UNIVERSAL
12-24 V 40 W
NÁVOD K POUŽITÍ (s. 17)
12-24 V, 40 W UNIVERZÁLNÍ NAPÁJECÍ
ADAPTéR
ΕΓΧΕΙΡΙΔΙΟ XPHΣHΣ (σελ. 20)
12-24 V 40 W UNIVERSAL
ΤΡΟΦΟΔΟΤΙΚΟ
VEILEDNING (σελ. 24)
12 -24 V 40 W UNIVERSALADAPTER
2
ENGLISH
Specications Power Adapter
• Input voltage: 100-240 V AC, 50/60 Hz
• Output voltage: 12/13/14/15/16/17/18/18.5/19/19.5/20/21/22/23/24 V (DC)
• Output power: Max. 40 W
• Protection: short circuit protection, overload protection
• Efciency: > 87%
• Dimensions: 45x28x95 mm
Power Up Your Notebook
1. Connect your notebook (or any other appliance that works within the offered output
voltage and output power range) with this power supply by connecting the supplied
detachable adaptor plug.
2. Determine the proper connector size. Check the polarity of your device and plug the power
tip into the socket of the power supply.
Center is negative
Center is positive
cen
3. Set the DC voltage selector to the desired voltage position. Before you connect your
notebook computer nd the required voltage setting on your original AC adaptor or in the
computer’s user manual (PLEASE NOTE THAT AN INCORRECT VOLTAGE SETTING
MAY DAMAGE YOUR NOTEBOOK. IF YOU ARE UNSURE, DO NOT TRY TO CONNECT
IT TO YOUR COMPUTER BUT CONSULT YOUR LOCAL DEALER!!!).
Voltage selector
4. Make sure that the total connected load does not exceed the rated output current of the
power supply.
3
Voltage output (V) 12 13 14 15 16 17 18 18.5
Max. output current (A) 2.5 2.4 2.3 2.2 2.1 2.0 1.95 1.93
Voltage output (V) 19 19.5 20 21 23 2422
Max. output current (A) 1.9 1.88 1.85 1.8 1.75 1.7 1.65
5. Connect the power cord to the power supply rst and then insert the AC plug into your wall
socket. The LED indicator will light up.
6. Switch on your computer.
Safety precautions:
RIS K OF ELECT RIC S KHOC
DO NO T O PEN
CAUTION
To reduce risk of electric shock, this product should ONLY be
opened by an authorized technician when service is required.
Disconnect the product from mains and other equipment if a
problem should occur. Do not expose the product to water or moisture.
Maintenance:
Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty:
No guarantee or liability can be accepted for any changes and modications of the product or
damage caused due to incorrect use of this product.
General:
Designs and specications are subject to change without notice.
All logos brands and product names are trademarks or registered trademarks of their
respective holders and are hereby recognized as such.
Keep this manual for future reference.
Attention:
This product is marked with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste. There is a separate
collections system for these products.
DEUTSCH
Spezikationen Netzteil
• Eingangsspannung: 100-240 V AC, 50/60 Hz
• Ausgangsspannung: 12/13/14/15/16/17/18/18,5/19/19,5/20/21/22/23/24 V (DC)
• Ausgangsleistung: Max. 40 W
• Schutz: Kurzschluss, Überlastung
• Efzienz: > 87%
• Abmessungen: 45x28x95 mm
Spannungsversorgung für Notebook
1. Schließen Sie Ihr Notebook (oder jedes andere Gerät, welches mit der verfügbaren
Ausgangsspannung und Leistung arbeitet) über das mitgelieferte Netzteil an.
2. Bestimmen Sie den korrekten DC Anschlussstecker. Überprüfen Sie die Polarität Ihres Geräts
und schließen Sie den DC Anschlussstecker an der Ausgangsbuchse des Netzteils an.
