Nedis SPBB350BK Bruksanvisning

Nedis högtalare SPBB350BK

Läs nedan 📖 manual på svenska för Nedis SPBB350BK (29 sidor) i kategorin högtalare. Denna guide var användbar för 9 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/29
ned.is/spbb350bk
Bluetooth® Party Speaker
With a rich, 150 W peak sound output
SPBB350BK
1 2 3 4 5 6 7
9 q w e r
t
y
8
a
Quick start guide 3
c Kurzanleitung 4
b Guide de démarrage rapide 5
d Snelstartgids 7
j Guida rapida all’avvio 8
h Guía de inicio rápido 10
i Guia de iniciação rápida 11
e Snabbstartsguide 13
g Pika-aloitusopas 14
f
Hurtigguide 16
2 Vejledning til hurtig start 17
k Gyors beüzemelési útmutató 18
n Przewodnik Szybki start 20
x Οδηγός γρήγορης εκκίνησης 21
1 Rýchly návod 23
l Rychlý návod 24
y Ghid rapid de inițiere 26
A
3
a
Quick start guide
Bluetooth® Party Speaker SPBB350BK
For more information see the extended manual
online: ned.is/spbb350bk
Intended use
The Nedis SPBB350BK is intended to stream audio from your media
device via Bluetooth, audio cable or from a USB ash drive.
This product is intended for indoor and outdoor use.
The product is not intended for professional use.
Any modication of the product may have consequences for safety,
warranty and proper functioning.
Specications
Product Bluetooth® Party Speaker
Article number SPBB350BK
Dimensions 215 x 215 x 390 mm
Weight 4700 g
Features True Wireless Stereo (TWS) and
party lights
RMS audio output 4 x 4 W + 2 x 27 W
Peak audio output 150 W
Bluetooth® frequency range 2402 - 2480 MHz
Bluetooth® version v4.2 + BR
Transmission distance Up to 10 meters
Maximum transmission power 4 dBm
Maximum antenna gain 0 dBi
Battery type Lithium-ion
Battery capacity 4400 mAh
Charging input power 5.0 VDC / 2.0 A
Charging time Up to 5 hours
Maximum battery play time
(at 50% volume)
Up to 3.5 hours
Impedance 4 Ω
Frequency response 80 Hz - 15 KHz
Water resistance IPX5
Main parts (image A)
1 Previous song / Volume
down button
2 Next song / Volume up
button
3 Play / pause button
4 Power button
5 TWS button
6 Mode button
7 Light button
8 Battery indicator lights
9 Dust cover
10 USB port
11 AUX port
12 USB-C port
13 Microphone port
(6.35 mm)
14 AUX cable
15 USB-C cable
Safety instructions
To prevent possible hearing damage, do not listen
at high volume levels for long periods.
-
WARNING
• Ensure you have fully read and understood the instructions in
this document before you install or use the product. Keep this
document for future reference.
• Only use the product as described in this document.
• Do not use the product if a part is damaged or defective. Replace
a damaged or defective product immediately.
• Do not drop the product and avoid bumping.
• This product may only be serviced by a qualied technician for
maintenance to reduce the risk of electric shock.
• Do not expose the product to water or moisture.
• Disconnect the product from the electrical outlet and other
equipment if problems occur.
• Do not immerse the product in water for cleaning.
• Only use the provided USB charging cable.
• The product is delivered with a partially charged battery. For
optimal battery life, fully charge the battery before rst use.
• Do not charge when the product is wet.
• Do not leave a battery on prolonged charge when not in use.
• Do not dismantle, open or shred batteries.
• Do not expose the product to direct sunlight, naked ames or
heat.
Switching on the product
Press the power button to switch the product on or o.A4
4When inactive, the product automatically switches o after 10
minutes.
Charging the product
-
Only use the provided USB charging cable.
1. Remove the rubber cover A
9.
2. Plug the USB-C cable Ay into the USB-C port Ae.
3. Plug the other end of A
y into a 5.0V/2.0A USB adapter (not
provided).
4. Plug the USB adapter into a power outlet.
The battery indicator lights A8 burn to indicate the product is
charging.
4A8 gives an indication of how far the battery is charged.
When all four lights burn, the product is fully charged.
-
Close A9 to protect the connectors from dust and water.
Pair with Bluetooth
1. Press Mode button A6 to select Bluetooth.
A4 blinks blue to indicate pairing mode is active.
2. Enable Bluetooth on the device you want to pair.
3. Select "SPBB350BK" from the list of available Bluetooth devices
on your device.
If asked, enter the pairing code '0000'.
4If the product has already been paired with another device, make
sure that device is switched o or Bluetooth is disabled.
4When the product has lost connection to the Bluetooth source,
it will automatically reconnect when back in range and switched
on.
Controlling the music
1. Press play/pause button A3 to play or pause music.
2. Press previous song / volume down button A
1 or next song /
volume up button A2 to skip between tracks.
3. Press and hold A2 to turn the volume up.
4. Press and hold A1 to turn the volume down.
Connecting with audio cable
1. Plug the AUX cable A
t into the AUX port Aw.
2. Plug the other end of A
t into your audio source.
4Playing music without Bluetooth disconnects Bluetooth. Press
A6 until the product is in Bluetooth mode to connect to your
Bluetooth audio source again.
4The music can be controlled from the connected device.
