INSTRUCTION MANUAL
WWW.NEOMOUNTS.COM
FPMA-HAC100HC
EN
NL
DE
FR
IT
ES
PT
DK
NO
SE
FI
PL
CS
SK
RO
Medical mount
Medische steun
Medizinische Halterung
Support médical
Supporto medico
Soporte médico
Suporte medico
Medicinsk beslag
Medisinsk feste
Medicinskt fäste
Medical teline
Uchwyt medyczny
Držák pro lékařské účely
Držiak na lekárske vybavenie
Suport medical
FPMA-HAC100
2
INDEX
FPMA-HAC100HC
1-6 kg
6-12 kg
75x75 -
100x100 mm
75x75 -
100x100 mm
Before starting assembly p. 2
Parts p. 3
Arm operation p. 4
Positioning p. 5
Serviceable range p. 6
Ceiling assembly p. 7
Cable assembly p. 13
Monitor assembly p. 17
Placement of the arm covers p. 19
Adjustment for loading p. 20
Adjusting universal joint tension p. 21
Safety notes p. 22
0-170 cm
0-170 cm
0-189 cm
0-189 cm
BEFORE STARTING ASSEMBLY
Please read this manual thoroughly, before assembling the product.
Some drawings are enlarged to clearify the steps.
Do not discard any of the packaging until you have checked all the parts.
If you are missing any of the parts, please contact your supplier.
Note
Only if required, all fastening hardware can be replaced by the installer at their own risk, based on the requirements of the ceiling compo-
sition; Neomounts shall not be held liable if any fasterning hardware supplied by third parties fails to sufciently secure the ceiling mount to
the ceiling.
Cleaning recommendations
Please use non-abrasive or diluted products to clean the plastic components of this product, such as soap water or diluted alcohol.
Use a soft cloth with 91% isopropyl alcohol to remove pen or marker spots on the surface of the arm.
For any other stains like iodine spots, a soft cloth with above cleansers is suggested for cleaning.
The following chemicals are strictly forbidden to use cleaning the arm: abrasive cleansers, acetone, mineral spirits, paint thinner or any
other harsh or toxic chemicals.
THE INSTALLATION SHOULD BE PERFORMED BY A QUALIFIED TECHNICIAN AND SHOULD MEET THE
REQUIREMENTS OF LOCAL REGULATIONS
FPMA-HAC100 FPMA-
HAC100:
FPMA-
HAC100HC:
3
1. (x1)
2. (x1)
3. M4x12 (x4)
4. M6x30 (x4)
5. M4x25 (x4)
6. (x4)
7. 2,5 mm (x1)
8. 4 mm (x1)
9. (x2)
10. (x1)
11. (x1)
12. (x1)
13. (x4)
PARTS
14. (x1)
15. (x4)
16. (x2)
17. (x1)
18. 17 mm (x2)
19. 3 mm (x1)
20. (x1)
21. (x2)
22. (x4)
23. (x2)
24. (x1)
25. M5x10 mm (x2)
26. M5x8 mm (x2)
27. (x1)
