INSTRUCTION MANUAL

WWW.NEOMOUNTS.COM

FPMA-HAW200

Medical mount

Medische steun

Medizinische Halterung

Support médical

Supporto medico

Soporte médico

Suporte medico

Medicinsk beslag

Medisinsk feste

Medicinskt fäste

Medical teline

Uchwyt medyczny

Držák pro lékařské účely

Držiak na lekárske vybavenie

Suport medical

INDEX

Before starting assembly p. 2

Parts p. 3

Arm operation p. 5

Serviceable range p. 6

Wall assembly p. 7

Cable assembly p. 9

Monitor assembly p. 13

Adjustment for loading p. 15

Replacement of the arm covers p. 18

Adjusting universal joint tension p. 21

Safety notes p. 22

BEFORE STARTING ASSEMBLY

• Please read this manual thoroughly, before assembling the product.

• Some drawings are enlarged to clearify the steps.

• Do not discard any of the packaging until you have checked all the parts.

• If you are missing any of the parts, please contact your supplier.

Note

Only if required, the fastening hardware may be replaced by the installer at their own risk, based on the requirements of the wall compo-

sition; Neomounts shall not be held liable if any fasterning hardware supplied by third parties fails to sufciently secure the wall mount to

the wall.

Cleaning recommendations

• Please use non-abrasive or diluted products to clean the plastic components of this product, such as soap water or diluted alcohol.

• Use a soft cloth with 91% isopropyl alcohol to remove pen or marker spots on the surface of the arm.

• For any other stains like iodine spots, a soft cloth with above cleansers is suggested for cleaning.

• The following chemicals are strictly forbidden to use cleaning the arm: abrasive cleansers, acetone, mineral spirits, paint thinner or any

other harsh or toxic chemicals.

THE INSTALLATION SHOULD BE PERFORMED BY A QUALIFIED TECHNICIAN AND SHOULD MEET THE

REQUIREMENTS OF LOCAL REGULATIONS

FPMA-HAW200

1-7 kg75x75 -

100x100 mm

0-149 cm 0-149 cm

10. M4x25 (x4)

11. (x4)

12. 2,5 mm (x1)

13. 4 mm (x1)

14. (x2)

15. (x1)

16. (x1)

PARTS

1. (x1)

3. (x1)

4. (x1)

5. (x1)

6. 3 mm (x1)

7. (x8)

8. M4x12 (x4)

9. M6x30 (x4)

2. (x1)
