Sida 1/30
artica deluxe
USER’S MANUAL
www.ngs.eu
English Français Español Deutsch Italiano Português Polskii i i i i i
2
USER’S MANUAL
Welcome to use this Bluetooth stereo headset. Please read this user’s manual
carefully before using it.
BRIEF INTRODUCTION
NGS ARTICA DELUXE is a stereo Bluetooth headset. It supports the following
Bluetooth profiles:
HSP: Headset Profile
HFP: Hands-free Profile
A2DP: Advanced Audio Distribution Profile
AVRCP: Audio/Video Remote Control Profile
CHARGING THE HEADSET
First time charging
Before you use this Bluetooth headset, please charge the battery of
NGS ARTICA DELUXE fully.
Next time
When you hear three warning tones of “DONG” every 30 seconds, at the same
time, the red light blinks two times. It means the battery is low power and need
to be charged. The battery can be charged as below:
CHARGING THE BATTERY WITH USB CABLE
Step1: Insert USB charging cable into USB port of PC or into wall charger with
USB port.
Step2: Connect charging cable with the charging port of headset.
When the red light is on, the headset is charging.
When the red light is off, the headset is charged fully.
It takes about 3 hours to charge the headset fully.
Warning:
The battery is recycled.
Do not dispose of the battery in fire, as it may cause explosion.
BEFORE USING
OVERVIEW
Built-in Microphone
Multi-function button (MFB)
Next song
Pause/play
Previous song
Line-in jack
LED indicator
Charging jack
Volume down
Volume up
Right speaker
Left speaker
1
2
3
4
5
6
7
8
9
10
11
12
1112 10
9
8
7
6
5
4
3
2
1
3
USER’S MANUAL
GETTING STARTED
1 Switching on / off headset
2 Pairing the headset with Bluetooth devices
How to enter pairing mode
Note: In order to save power, the headset will automatically switch off if no devices can be
connected within 5 minutes after switching on.
Note: The pairing mode will last 2 minutes, If the headset still can’t pair with any Bluetooth
devices after 2 minutes, it will switch into standby mode automatically.
Please make sure your mobile phone has Bluetooth function that can be used.
Specific pairing procedures may vary with different mobile phone. Please refer
to your mobile phone manual for further information. Steps as follows:
Pairing the headset with Bluetooth mobile phone
1. Please keep the headset and mobile phone in the range of 1 meter when
pairing.
2. Make the headset enter into pairing mode (Please refer to “how to enter into
pairing mode”).
3. Start the Bluetooth function of mobile phone and search the Bluetooth
devices. After searched, select “NGS ARTICA DELUXE”in the Bluetooth device
list.
4. According to indication, enter password or PIN No:”0000”,and press the key of”
Yes” or “confirm.
5. After successful pairing, select “NGS ARTICA DELUXE” in the Bluetooth device
list, and press “connect”.
6. After successful connecting, the blue LED of the headset quickly blinks twice
or three times every 4 seconds.
Function Operation LED indicator
Switch on Press the MFB button for 3-5 seconds, and
release it till the blue LED is on
Blue LED is on for 1 second
Switch off Press the MFB button for 3-5 seconds, and
release it till the red LED is on
Red LED is on for 1 second
Function Operation LED indicator
Enter
pairing
mode
Make sure the headset is off. Press and hold
MFB button for 7-9 seconds, and release it till
the red and blue LEDS blink alternately
Red and blue LEDs blink
alternately.
Función Estado de los auriculares Funcionamiento
Cancel calling Short press MFB onceCalling
Answer a call Incoming ringing Short press MFB once
Reject a call Incoming ringing Long press MFB for 2 seconds and
release it until listen a tone
End a call During a call Short press MFB once
Volume up During a call Short press button
Volume down During a call Short pres button
Transfer conversation to
mobile phone
During a call Long press MFB for 2 seconds
Transfer conversation to
headset
During a call Long press MFB for 2 seconds
Microphone mute During a call Double click MFB
Cancel mute During a call(micro mute) Double click MFB
Voice dial Standby mode(have already
connected device)
Long press button for 2 seconds
Redial the last number Standby mode(have already
connected device)
Double click MFB
Remove paired list Turned off Press MFB and pause button for 8
seconds simultaneously, and release
it until the red and blue(or purple) LED
on at the same time
3 Making calls with the headset
Basic operation
Remarks:
• If pairing is failed, please turn o the headset rst and then re-pair according to steps 1-6
mentioned above.
• After pairing is successful, the headset and the cell phone will remember each other, they
will no need to re-pair next time. The headset can remember 8 paired devices, when the
number of paired devices exceeds 8, the first one will be replaced.
• Every time the headset is turned on, it will connect to last connected device automatically.
If you want to pair it with other devices, please turn off the Bluetooth function of last
connected devices first and pair the headset with the new device according to steps 1-6
mentioned above.
