Endless power for endless possibilities

All information provided in this document is subject to change without prior notice

15932

Picture shown may not represent model quoted

3707-3707/10 has a three phase side chanel blower that guarantees quiet

and continuous running. The suction unit is controlled by utilising soft start

technology which reduces power consumption during start up.

The 3707 and 3707/10 have the ability to collect high quantities of heavy

materials.

With power ratings of 5.5kW & 7.5kW, the 3707- 3707/10 offers high

performance whilst being extremely manouverable and versatile. Large

waste container designed for heavy duty use and constant service. With a

large 175 litre capacity waste bin, it is fitted with the drop down release

mechanism to ensure ease of removal and emptying. The large primary ' L'

class star filter provides effective and efficient filtration.The units can be

fitted with M and H class HEPA filtration if required for hazardous dusts.

Filter cleaning is done via the manual filter shaker or by an optional

electrical version. The machine body is manufactured to ensure stability,

robustness and a long service life.

• Low maintenance

• Continuous use

• Very high performance levels

• Large Primary "L" Class Star Filter

• Efficient filter cleaning system

• Filter blockage level monitoring

• Vacuum gauge

• Watertight control panel with soft start

• Electrical filter shaker option

• Highly manoeuvrable

• Stainless steel option

• L, M, H and ATEX versions

● Standard equipment

Included accessories Ref. no. Min.

required 3707 3707 AD 3707/10

FilterFilterFilterFilter

STAR FILTER 560 M Z8 17246 1

● Standard equipment

Included accessories Ref. no. Min.

required 3707/10 C 3707/10 SE 3707/10 C SC

Filter

FilterFilter

Filter

STAR FILTER 560 M Z8 17246 1

Model 3707 3707 AD 3707/10

Ref. no. 4030700000 4030700008 4030700034

PRODUCT FEATURES

Electrical filter shaker

Cartridge filter incl. jet clean system with timer

Manual filter shaker ● ● ●

Star triangle starting ● ● ●

Industrial vacuum cleaners 3707-3707/10

Endless power for endless possibilities

All information provided in this document is subject to change without prior notice

15932

Model 3707 3707 AD 3707/10

Ref. no. 4030700000 4030700008 4030700034

PRODUCT FEATURES

Inversor switch ● ● ●

Relief valve ● ● ●

L class filter ● ● ●

M class filter

Cyclone plate

5 pin plug

Purge jet system

Hepa Downstream Filtration ●

Vacuum Gauge (Filter Surveillance) ● ● ●

Automatic stopping for liquids

Solid control

Model 3707/10 C 3707/10 SE 3707/10 C SC MS

Ref. no. 4030700061 4030700072 4030700695

PRODUCT FEATURES

Electrical filter shaker ●

Cartridge filter incl. jet clean system with timer ● ●

Manual filter shaker ●

Star triangle starting ● ● ●

Inversor switch ● ● ●

Relief valve ● ● ●

L class filter ●

M class filter ● ●

Cyclone plate

5 pin plug

Purge jet system ● ●

Hepa Downstream Filtration

Vacuum Gauge (Filter Surveillance) ● ● ●

Automatic stopping for liquids

Solid control ●

Industrial vacuum cleaners 3707-3707/10

Endless power for endless possibilities

All information provided in this document is subject to change without prior notice

15932

Technical specifications 3707 3707 AD 3707/10

Voltage (V) 230/400 230/400 230/400

Frequency (Hz) 50 50 50

IP protection class 55 55 55

Insulation class F F F

Rated power (kW) 5.5 5.5 7.5

Airflow without hose (m³/h - l/m) 486 - 8100 486 - 8100 810 - 13500

Max. vacuum (kPa - mbar) 36 - 360 36 - 360 25 - 250

Sound pressure level (dB(A)) 78 78 78

Container capacity (l) 175 175 175

Main filter type L CLASS

POLYESTER

L CLASS

POLYESTER

L CLASS

POLYESTER

Main filter area (cm²) 35000 35000 35000

Inlet (mm) 100 100 100

Length x width x height (mm) 1600x800x1810 1600x800x1810 1600x800x1810

Weight (kg) 291 291 305

Technical specifications 3707/10 C 3707/10 SE 3707/10 C SC MS

Voltage (V) 230/400 230/400 230/400

Frequency (Hz) 50 50 50

IP protection class 55 55 55

Insulation class F F F

Rated power (kW) 7.5 7.5 7.5

Airflow without hose (m³/h - l/m) 810 - 13500 810 - 13500 810 - 13500

Max. vacuum (kPa - mbar) 25 - 250 25 - 250 25 - 250

Sound pressure level (dB(A)) 78 78 78

Container capacity (l) 175 175 175

Main filter type L CLASS

POLYESTER

L CLASS

POLYESTER

L CLASS

POLYESTER

Main filter area (cm²) 70000 35000 70000

Inlet (mm) 100 100 100

Length x width x height (mm) 1600x800x1810 1600x800x1810 1600x800x1810

Weight (kg) 305 305 305

Industrial vacuum cleaners 3707-3707/10
