Sida 1/2
301 Fulling Mill Road, Suite G
Middletown, PA 17057
Phone (800) 321-2343 / Fax (717) 702-2546
www.onqlegrand.com
Page 1 of 2
INSTRUCTION/INSTALLATION SHEET
lyriQ™ Local Source Input
IS-0321 REV. A
©Copyright 2007 by On-Q/Legrand All Rights Reserved.
1. Introduction
The On-Q /Legrand lyriQ™ Local Source Input, PN F7417-xx (see Figure 1), is
an integral part of the On-Q/Legrand lyriQ™ Audio System. It is a component
which, when combined with other essential components and your source
equipment (receiver, CD player, etc.), creates a versatile whole-house audio
system that will fill your rooms with high-quality sound for years to come.
Category 5 technology is a new, innovative method of providing high quality
audio to remote locations with a single 8-conductor cable such as Cat 5e. This
technology provides many advantages over other conventional methods of
audio distribution such as simple, single Cat 5e wiring scheme, infrared control
of system components, and system power status.
NOTE: The lyriQ™ Local Source Input, like other On-Q/Legrand lyriQ™
Audio system components, is powered by the On-Q/Legrand lyriQ™ Audio
Distribution Module.
IMPORTANT: Read the manuals that are included with all associated
lyriQ™ Audio products before installation of any single component! If you
are unsure of any of the following installation procedures contact On-
Q/Legrand Technical Support @ 1-800-321-2343 option 1 or contact an On-
Q/Legrand installer.
2. Description
The lyriQ™ Local Source Input allows the system to use a “local” input in any Audio zone. It is connected in
series with the volume control by simply terminating the run of Cat 5 cable from the lyriQ™ Distribution Module
to the input of the lyriQ™ Local Source Input, and connecting the output of the lyriQ™ Local Source Input to the
volume control. The lyriQ™ Local Source Input uses the same 110 style punchdown connection as the volume
controls. The lyriQ™ Local Source Input senses the audio signal from a line level audio source such as a CD
player, and if it is active, the local source has priority over the main source and will be heard within the zone.
When the local source is no longer active or plugged in, the main source will be heard in the zone within 30
seconds.
3. Installation
Installation of the On-Q lyriQ™ Local Source Input is best accomplished in two steps during new construction,
at “Rough-in” before the drywall is installed, and at “Trim-out” after the drywall is installed and painted.
NOTE: The On-Q/Legrand lyriQ™ Local Source Input is typically mounted at electrical outlet height.
Measure the nearest box on the same wall that the lyriQ™ Local Source Input will be installed and place
the J-Box at the same height. Position and cabling must maintain separation of class 2 cable from power
wiring. Special applications, such as audio from a TV, entertainment center, or a computer, may require
dierent heights.
A. “Rough-in” steps:
Figure 1
F7417-WH (White)
F7417-LA (Lt. Almond)
F7417-IV (Ivory)
F7417-BK (Black)
301 Fulling Mill Road, Suite G
Middletown, PA 17057
Phone (800) 321-2343 / Fax (717) 702-2546
www.onqlegrand.com
Page 2 of 2
INSTRUCTION/INSTALLATION SHEET
lyriQ™ Local Source Input
IS-0321 REV. A
©Copyright 2007 by On-Q/Legrand All Rights Reserved.
1. Run Cat 5 cable from the lyriQ™ Single Source 4 Zone Distribution Module located in the Enclosure to
the single gang box at the location that will contain the lyriQ™ Local Source Input. Also run Cat 5 cable
from the single gang box that will contain the lyriQ™ Local Source Input to the volume control location.
B. “Trim-out” steps:
NOTE: Use a standard punch down tool with a 110 style blade, maintain less than ½” of untwisting of
pairs, and make sure the 110 blade cuts any excess conductor completely.
1. Punch down the prewired Cat 5e cable from the lyriQ™
Single Source 4 Zone Distribution Module onto the 110 strip
labeled “INPUT” at the bottom of the unit (see Figure 2).
2. Punch down the prewired Cat 5e cable to the lyriQ™
Volume Control onto the 110 style block labeled “OUTPUT”
at the top of the unit (see Figure 2).
3. The JP1 header next to the “OUTPUT” 110 strip is set to
the “KNOB” (pins 2 and 3 jumpered) position by default and
this position is suitable for knob only or mixed knob and
keypad systems. If the system uses keypad volume
controls only, move JP1 to the “KEYPAD” (pins 1 and 2
jumpered) position.
4. Mounting: Use the included screws to install the lyriQ™
Local Source Input into a standard single gang box and use
a standard Decorator style cover.
4. Important Safety Precautions:
READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING THE lyriQ™ AUDIO SYSTEM.
• Do not attempt to service, move or change any component of this system unless you are qualified to do so.
• This system should be installed by a qualified installer and must conform to all local building and electrical codes.
• Do not apply power to the lyriQ™ Audio System until all components have been installed and all wiring has been properly
terminated.
• Do not attempt to terminate, change or un-install any wiring without first turning off power to the
lyriQ™ Audio System which
is located in the enclosure. Unplug the power transformer that is powering the
lyriQ™ Audio System from the power outlet
before proceeding with wiring terminations or changes.
• Install each component of this system away or any other heat from heat sources such as HVAC ducts/registers, stoves
source.
• Do not expose any component that was designed for indoor use to moisture. Doing so can create electrical hazards or
render the component unusable. Exposure to moisture will also void the warranty on the system.
• Only use a damp cloth to clean the cover plates of the system components. Do not use vacuum cleaners, liquid or aerosol
cleaners.
Blue/White - - - - - - - - - -
Blue
Orange/White - - - - - - - - - -
Orange
Green/White - - - - - - - - - -
Green
Brown/White - - - - - - - - - -
Brown
Blue/White - - - - - - - - - -
Blue
Orange/White - - - - - - - - - -
Orange
Green/White - - - - - - - - - -
Green
Brown/White - - - - - - - - - -
Brown
Figure 2
