Sida 1/4

Speaker System

D-N10BX

D-N9BX

D-N7BX

Instruction Manual

Thank you for purchasing an Onkyo Speaker

System.

Please read this manual thoroughly before using

it. Following the instructions in this manual will

enable you to obtain optimum performance and

listening enjoyment from your new Speaker Sys-

tem.

Please retain this manual for future reference.

Before Using Your New Speakers

• The speaker cabinets are made out of

wood and are therefore sensitive to

extreme temperatures and humidity.

Do not use them in locations subject to

direct sunlight or in humid places,

such as near an air conditioner, humid-

iﬁer, bathroom, or kitchen.

• Place the speakers on sturdy, ﬂat sur-

faces. Putting them on uneven or

unstable surfaces where they may fall

and cause damage will affect the

sound quality.

• Do not keep water or other liquids

close to the speakers. If a liquid is

spilled over them, the woofer and

tweeter inside may be damaged.

• Do not handle the speakers with wet or

damp hands.

D-N10BX,N9BX,N7BX_En.fm Page 1 Thursday, May 25, 2006 5:42 PM

In catalogs and on packaging, the letter at the end of the

product name indicates the color. Speciﬁcations and

operation are the same regardless of the color.

The speakers can handle the speciﬁed input power when

used for normal music reproduction. If they’re fed any

of the following signals, even if the input power is

within the speciﬁed rating, excessive current may ﬂow

in the speaker coils, causing burning or wire breakage:

1. Interstation noise from an untuned FM radio.

2. Audio from a cassette that’s being fast-forwarded.

3. High-pitched sounds generated by an oscillator, elec-

tronic musical instrument, and so on.

4. Ampliﬁer oscillation.

5. Special test tones from audio test CDs and so on.

6. Thumps and clicks caused by connecting or discon-

necting audio cables (always turn off your ampliﬁer

before connecting or disconnecting cables).

7. Microphone feedback.

The speakers contain powerful magnets. Do not put

metal items, such as screwdrivers, close to the speakers,

as they may be attracted toward the magnet, causing

injury, or damage to the tweeter diaphragm.

• D-N10BX/D-N9BX

• D-N7BX

The two speakers are identical, so it doesn’t matter

which one you use on the left or right.

TVs and computer monitors are magnetically sensitive

devices and as such are likely to suffer from discolora-

tion or picture distortion when conventional speakers

are placed nearby. To prevent this, the speakers feature

internal magnetic shielding. In some situations, how-

ever, discoloration may still be an issue. In this case,

turn off your TV or monitor, wait 15 to 30 minutes, and

then turn it back on again. This normally activates the

degaussing function, which neutralizes the magnetic

ﬁeld, thereby removing any discoloration effects. If dis-

coloration problems persist, try moving the speakers

away from your TV or monitor. Note that discoloration

can also be caused by a magnet or demagnetizing tool

that’s too close to your TV or monitor.

Note:

If the speakers are placed close to a TV or monitor, due

to the electromagnetic waves radiated by the TV or

monitor, you may hear noise from the speakers even

after your ampliﬁer has been turned off. To prevent this,

position the speakers away from your TV or monitor.

You can use the speakers either with or without their

grilles, which can be removed as follows.

1. Use both hands to gently pull the bottom of the grille

away from the speaker.

2. Use both hands to gently pull the top of the grille

away from the speaker.

3. To replace the grille, align the four fasteners and gen-

tly push the grille toward the speaker.

* D-N10BX/D-N9BX shown here. Grille removal is

the same for the D-N7BX.

You can improve the sound quality by attaching the

included cork spacers to raise the speakers off the surface

and reduce the contact area. The cork spacers also make

the speakers stable and prevent them from slipping.

* D-N10BX shown here.

Precautions

Getting to Know the Speakers

Tweeter

Grille

attachment pin Grille

Woofer Cabinet

Tweeter

Grille

attachment pin Grille

Woofer Cabinet

Using Close to a TV or Computer

Removing the Speaker Grilles

Using the Included Cork Spacers

ReplaceRemove

D-N10BX/D-N9BX D-N7BX

Cork spacer

Bottom

D-N10BX,N9BX,N7BX_En.fm Page 2 Thursday, May 25, 2006 5:42 PM

• Before connecting the speakers, disconnect your

ampliﬁer’s power cord from the wall outlet and set its

volume control to minimum.

• The speaker’s rated impedance is 4

Ω

. Make sure you con-

nect an ampliﬁer that is compatible with a 4

Ω

impedance.

• Use the supplied speaker cables to connect the speak-

ers to your ampliﬁer as shown.

The type of speaker terminals used on the receiver and

their position depends on the model. Refer to the

receiver’s instruction manual for details on connecting

speakers to the receiver.

Before Turning on Your Receiver:

• Make sure the speaker’s positive (+) terminals are

connected to the ampliﬁer’s positive (+) terminals,

and the speaker’s negative (–) terminals are con-

nected to the ampliﬁer’s negative (–) terminals. If you

get the polarity reversed, the sound will be unnatural,

with a limited bass range and poor stereo image.

• Make sure that the positive (+) and negative (–) wires

are not touching each other. If they are, a short circuit

may occur, damaging your ampliﬁer.

The sound quality of the speakers is directly affected by

the size and shape of the room they’re used in and its

furnishings. When considering where to place your

speakers, read the following:

• Where possible, mount the speakers on speaker

stands, concrete blocks, bricks, or a sturdy bookshelf.

Putting them directly on the ﬂoor will emphasize bass

sounds, creating a boomy sound.

• If a speaker is placed on an uneven surface where it

can wobble or vibrate, bass performance will be

adversely affected. You can eliminate speaker wobble

by putting a shim made out of cork or metal, such as a

coin, underneath the speaker or stand, as shown.

• If you mount the speakers on a ﬂat surface, such as a

bookshelf, you can improve the sound quality by

inserting cork spacers or coins in between the speaker

and the shelf. Raising them off the surface like this

will reduce the contact area and improve the sound.

• If you like lots of bass, mount the speakers on low

speaker stands and place them in front of a solid wall.

• Walls and furnishings affect sound quality. To achieve

a good stereo sound, put the left and right speakers in

similar locations at the same distance away from your

listening position and at the same height. If you put

them in totally different locations, for example, one

on the ﬂoor and the other on a bookshelf, the stereo

imaging will be adversely affected.

• To determine the best positions for your speakers,

imagine an equilateral triangle and put the left and

right speakers at the ends of the base. The ideal listen-

ing position is at or slightly behind the triangle’s

apex. Angle the speakers toward your listening posi-

tion.

• Glass doors and smooth walls behind the listening

position can reﬂect the sound from the speakers and

can make sounds at certain frequencies louder. You

can prevent this by hanging sound-absorbing mate-

rial, such as thick curtain, on the door or wall.

D-N10BX

• Please note that the speakers’ surface features a spe-

cial ﬁnish. An object placed on the speakers for a

long period of time may leave a trace or mark. Adhe-

sive tape may also leave a mark.

Connecting the Speakers

Right speaker Left speaker

Speaker cable

Positive (+) side is

indicated by a

red line

D-N10BX

shown

1.Peel the

insulation off

the ends of

the speaker

cable and

twist the

core wires.

2.Loosen the

terminal screw

and insert the

speaker cable

into the hole

(until the core

wires are

inserted fully).

3.Fasten the

terminal

screw.

Speaker Placement

Shim

D-N10BX,N9BX,N7BX_En.fm Page 3 Thursday, May 25, 2006 5:42 PM
