INSTRUCTION MANUAL
Battery Sense Monitor Model: BSM888X
INTRODUCTION
This product is used to monitor the health of your vehicle’s battery, check vehicle cranking
system automatically while engine is starting and check battery charging system (alternator).
Your driving log can be viewed which includes driving time and duration.
Connect Battery Monitor to the battery and download the App.
Using Bluetooth communication, you can now monitor your battery via your smartphone.
The Battery Monitor will send you a notification when you approach your vehicle.
It will help to prevent vehicle breakdowns and maximise the performance of your battery by
giving you valuable information about the state of your battery.
This product is designed to be used on standard flooded type lead acid batteries. It may
give incorrect information on other types of battery. Voltage measurement will always be
correct on any battery.
FEATURES
• Free Battery Sense App for iOS and Android
• Monitor up to 4 batteries
• Connects to smartphone via Bluetooth®
• Compatible with all 12/24 volt batteries*
• IP65 Ingress protection
• Monitors engine compartment temperature
• Tests cranking automatically on engine startup
• Manually test charging system (alternator)
• Automatically record the time / duration of each trip
• Smartphone notifications (within Bluetooth® range)
• Short-circuit and reverse polarity protection
• Review historical data (up to 30 days)
SPECIFICATIONS
• Working Voltage: 6-30V
• Working Current: 12V 4mA, 24V 5mA
• Cable Length: 230mm x 2
• Working Temperature: -30°C ~ 85°C
• Product Size: 56x36x10mm
• Weight: 24g
INSTALLATION
1. Connect the Battery Monitor to a battery
Connect positive terminal to positive
pole, negative terminal to negative pole
or to a suitable vehicle earth point.
Attach the product to the battery with
the tape provided. Clean the area first
and make sure it in a position that the
signal is not blocked.
Warning: Make sure that if using a
metal tool, not to short the battery
terminals or touch the vehicle chassis
while fixing the terminals.
* For full functionality, this product should be used on standard flooded type lead acid batteries.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Oricom International Pty Ltd is under license.
2. Download the App
APP OPERATION
1. Turn on bluetooth, click app icon. Add device.
This app supports up to 4 devices.
You can monitor 4 batteries simultaneously.
The App with automatically detect the correct battery
voltage, or this can be manually selected between 12 or
24V in the settings.
Scan the QR code on the left to download
the Battery Sense Monitor App.
Battery Monitor
Battery Monitor App is available in App Store or Google Play.
Please allow app to access location even when app not in use.
If access is not given, the product will not automatically notify you
when monitoring the battery (within bluetooth range).
Turn notifications on to receive information on the vehicle’s battery,
cranking system, and fault alerts. Notifications are received when
mobile phone is within bluetooth range. If notifications are turned off
you will not receive this information.
WARNING
Be careful not to disconnect the battery
from the vehicle while installing this
product, as you may lose some or all of
your vehicle security settings.
2. Operation
1) Real-Time Voltage
Click once to enter detailed interface
1 Battery Real-time Voltage
2 Cranking Voltage
3 Battery Level
4 Battery Voltage
5 Cranking Test
11 System Setting
10 Battery Age
9 Find More
8 Voltage Curve
7 Trip Record
6 Charging Test
All specifications and figures are subject to change without notice. Printed in China 2021.07 Version: 1.0 7504-1157-01
4) Trip Time Recorder
App automatically determines travel time, start
and end times. (Please Note: the trip log is for
reference only, many factors can affect the
accuracy of the trip recorder.)
3) Charging Test (Alternator)
Alternator is used to recharge your car battery used to run your car’s electrical system.
You should test your alternator to ensure it is in perfect working condition.
The easiest way to test the alternator is by using this device. Follow the instructions on
the App to do the test.
6 Charging Test:
This tests the charging system manually.
7 Trip Record:
Records each start time, stop time and
driving time of the vehicle.
8 Voltage Curve:
Shows the voltage curve of battery.
9 Find More:
Detailed voltage curve.
10 Battery Age:
Shows the age of the battery.
11 System Setting:
Select to enter system setting.
1 Battery Real-time Voltage
Shows Battery Real-time Voltage
2 Cranking Voltage:
The voltage the battery drops to
during starting or cranking the engine.
For a 12 Volt system you may see a
drop from 7.5 to 11 Volts.
For a 24 Volt system it often drops to
15 to 22 Volts.
3 Battery Level:
Shows battery status of capacity
4 Battery Voltage:
Displays current battery voltage.
5 Cranking Test:
This is done automatically on start up.
2) Cranking Test
Everytime you start the engine, the device
will test the cranking system automatically
and store the test result. If the cranking
voltage is below 7.5V, it means abnormality
has been detected. For a 24 Volt system,
voltage under 15V will be abnormal. It might
be time to replace the battery. Have your
vehicle’s battery checked.
Note: If using the battery monitor on a 24V
battery you will need extension cables to
connect the meter.
