Oricom TPS10-10E Bruksanvisning
Läs nedan 📖 manual på svenska för Oricom TPS10-10E (3 sidor) i kategorin Radio. Denna guide var användbar för 9 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/3
>25km / h
Installation is complete when all tyre
data has been received and is showing
on the display.
Psi
Psi
Psi
Psi Psi
Display ON/OFF
Display installation
Installation position
Place the anti-slip mat under the
display
Press any button for 3 seconds to turn on the display.
Press “ “ button for 3 seconds to turn off the display.
USB charging connection
Micro USB Plug USB charger
(Not included)
Product Overview
Select button
Solar panel
Micro USB input
SET button
Ventilation holes
Warning indicator
Display battery indicator
Charging status
Pressure data
Pressure unit
Temperature unit
Axles of trailer
Temperature data
Pack Includes
Sensor battery replacement
1.Unscrew the valve cap 2.Insert the dustproof cover into the valve stem
3.Screw in the nut
1.Unscrew the nut 3.Take out the washer
5.Replace the battery 6.Repeat steps in “Sensor installation”4.Unscrew the sensor cover by using
the sensor tool
2.Unscrew the sensor
4.Screw on the sensor
TPS10-4E - With 4 Sensors
TPS10-6E - With 6 Sensors
interface Trailer interface Spare interface
5. Tighten up the nut to the sensor by using the
spanner
6. Check air leakage by spraying soapy water
Sensor position
Sensor installation
Psi Psi Psi
F.L. F.R.
R.L. A3R.R.
A1 A2 S1 S2
A4
Solar Powered Tyre Pressure
Monitoring System
Note: Typical sensor position as per
diagram to the left.
F.R. R.R.
R.L.F.L.
A2 A4
A3
S2
S1
A1
TPMS
User Guide
LCD Display
Washers
X4 or X6
X4 or X6
x5 or x7
Nuts x5 or x7
Ensure that these parts are stored safely.
tyre
Button/coin cell batteries are hazardous and must be kept out of reach of children at all times, whether the battery is new
or used. These batteries can cause severe or fatal injuries in 2 hours or less if swallowed or placed inside any part of the
body. If it is suspected a button/coin cell battery has been swallowed or placed inside any part of the body, seek medical
attention immediately or contact the Australian Poisons Information Centre on 131126 for 24/7 fast, expert advice.
WARNING THIS PRODUCT CONTAINS BUTTON/COIN CELL BATTERIES
Alerts
High temperature
Troubleshooting
Additional Warnings
Express Warranty (Australia)Sensor programming(All sensors in package are preprogrammed)
2. To select the tyre position:
a. Press and hold “ ” button and press “ ”
button briefly to select the interface. (Interface
sequence: Tow vehicle → Axle A of Trailer →
Axle B of Trailer→ Spare tyre)
b. Then press “ ” button to select the desired tyre.
6. After the sensors are programmed, press “ “
button for 4 seconds to exit the programming mode.
5. Press “ ” button to select the next sensor
position.
Specifications Disclaimer
Driver distraction warning
2.3~3.3V
7.9 115
2.5mA
–20℃~ + 80℃/ -4℉~ + 176℉
–20℃~ + 70℃/ -4℉~ + 158℉
temperature:
High pressure value: 2.6~7.9Bar/37~115PSI
High temperature value:
80℃
/
176℉
Low pressure value: 0.9~3.9Bar/13~55PSI
High temperature value:
70 90~
℃
/ 158
℉
~ 194
℉
Adjustable Alarm Value:
High pressure value: 3.3Bar/47PSI
Low pressure value: 1.7Bar/24PSI
Default Value:
Temperature: ±
3℃
/±
5℉
Pressure: ±
0.1Bar
/±
0.2PSI
Precison:
Note: It is recommended that the tyre pressure
alarm values are set to ±25% of the recommended
manufacturer tyre pressure values.
1. (TPMS) is designed for vehicles with tyre pressure up to 6.0
Bar/ 86PSI.
2. All sensors in this unit have been pre-set individually for each
tyre in the factory.
3. Whenever the location of tyre changed, the sensors must be
changed to the corresponding tyre.
4. The display will turn off after the vehicle stops.
5. The sensor battery life depends on the driving mileage.
6. Approval marks and numbers should not be removed from the
product.
7. If the solar energy display is placed in temperature of higher
than 80ºC(or 176ºF), the capacity of the built-in battery might
be damaged.
8. If the display no longer holds a charge then it is time to replace
the battery.
9. Discharge and charge fully every 6 months to preserve battery life.
10. Store between -40ºC to +80ºC (-40ºF to +176ºF). Charge
between -10ºC to +65ºC (+14ºF to +149ºF).
11. Do not expose the battery to high temperature.
12. Do not allow the battery to get wet, store or use in high humidity
conditions as this will discharge the battery.
13. Do not disassemble or tamper with battery.
This Express Warranty is provided by Oricom
International Pty Ltd ABN 46 086 116 369, Unit 1, 4
Sovereign Place, South Windsor NSW 2756, herein after
referred to as “Oricom”.
Oricom warrants that the product is free from defects in
materials or workmanship during the Express Warranty
Period. This Express Warranty does not extend to any
product from which the serial number has been removed
or was purchased outside of Australia.
The benefits of this Express Warranty are in addition to
other rights and remedies you may have under the
Australian Consumer Law. Our goods come with
guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does
not amount to a major failure. In the event of a minor
failure, Oricom reserves the right to choose to repair or
replace the product.
The Express Warranty Period will be a period of 12
months beginning on the date of purchase of the product
evidenced by your dated sales receipt. You are required
to provide proof of purchase as a condition of receiving
Express Warranty services.
You are entitled to a replacement product or repair of
the product at our discretion according to the terms and
conditions of this document if your product is found to
be faulty within the Express Warranty Period. This
Express Warranty extends to the original purchaser only
and is not transferable.
Products distributed by Oricom are manufactured using
new materials or new and used materials equivalent to
new in performance and reliability. Spare parts may be
new or equivalent to new. Spare parts are warranted to
be free from defects in material or workmanship for thirty
(30) days or for the remainder of the Express Warranty
Period of the Oricom branded product in which they are
installed, whichever is longer. During the Express
Warranty Period, Oricom will where possible repair and
if not replace the faulty product or part thereof. All
component parts removed under this Express Warranty
become the property of Oricom. In the unlikely event that
your Oricom product has a recurring failure, Oricom may
always, subject to the Competition and Consumer Act
2010, at its discretion, elect to provide you with a
replacement product of its choosing that is at least
equivalent to your product in performance.
No change to the conditions of this Express Warranty is
valid unless it is made in writing and signed by an
authorised representative of Oricom.
Oricom will not be liable under this Express Warranty,
and to the extent permitted by law will not be liable for
any defect, loss, damage or injury arising out of or in
connection with a:
1. Failure by you to adhere to the warnings and follow
the instructions set out in this user guide for the proper
installation and use of the product;
2. Willful misconduct or deliberate misuse by you of the
product;
3. Any external cause beyond our control, including but
not limited to power failure, lightning or over voltage; or
4. Modification to the product or services carried out on
the product by anyone other than Oricom or Oricom’s
authorised service provider.
How to make a claim under your Express Warranty
in Australia
Oricom has a simple warranty process for you to follow:
• Please call or email our Customer Support Team, 02
4574 8888 or support@oricom.com.au.
• A Customer Support Team member will verify after
troubleshooting with you if your product qualifies under
warranty. If so, they will give you a Product Return
Authorisation number.
• We will then email a Return Authorisation form and a
Repair Notice (if necessary), together with instructions
on how to return the product for warranty service.
Please note that if a Customer Support Team member
advises that your product does not qualify for return, this
warranty does not apply to your product. Products that
are authorised to be returned to Oricom in Australia must
include all of the following:
• A completed Return Authorisation form
• A copy of your Proof of Purchase (please keep your
original copy)
• The faulty product, including all accessories.
Send the approved returns to:
Oricom International Pty Ltd
Locked Bag 658
South Windsor NSW 2756 Australia
Please note that this Express Warranty excludes
expenses incurred by you in returning any faulty product
to us. You must arrange and pay any expenses incurred
(including postage, delivery, freight, transportation or
insurance of the product) to return the faulty product to
us, however, we will arrange delivery of the repaired or
replaced faulty product to you.
Important Information - Repair Notice
Please be aware that the repair of your products may
result in the loss of any user-generated data (such as
stored telephone numbers, text messages and contact
information). Please ensure that you have made a copy
of any data saved on your product before sending for
repair. Please also be aware that products presented for
repair may be replaced by refurbished products or parts
of the same type rather than being repaired.
ORICOM CUSTOMER SUPPORT
Oricom have a trained and dedicated team of Customer
Support Representatives, each with the knowledge and
resources to assist in answering your questions quickly
and efficiently.
Oricom Support - Australia
For all product enquiries, troubleshooting or to discuss
the range of Oricom products, feel free to contact Oricom
or visit our website for answers to frequently asked
questions.
02 4574 8888
Monday - Friday 8am – 6pm AEST
Email: support@oricom.com.au
www.oricom.com.au
When programming a new sensor or a missing sensor to the display.
Temperature unit setting:
In high temperature value setting page. press
button to select the high temperature value,
once you have reached the desired value.
press button once to enter the next setting.
Psi
High pressure value setting:
In high pressure value setting page.press
button to select the high pressure value,
once you have reached the desired value
press button once to enter the next setting.
Psi
In temperature unit setting , press “ ”
button to select the temperature unit, then
press “ ” button once to save and move
to the next setting;
In low pressure value setting page. press
button to select the low pressure value, once
you have reached the desired value
Low pressure value setting:
High temperature value setting:
Psi
Time interval setting of each interface:
In time interval setting page, press “ ” button
to set the time interval of each interface, then
press “ ” button once to enter the next setting.
Time intervals: 5 / 10 / 20 / 30 / 60 / OFF
Default: 5 seconds
Tyre data deletion:
Psi
In tyre data deletion page, press button
to programmed select the tyre data to be deleted.
Then hold button until the display shows
"--", the tyre data has been deleted.
Psi
Press button to select the programmed
Axles of the Trailer or Spare Tyre, then
press button for 3 seconds to disable or
to enable, press button to save and
continue.
Disable/enable trailer and spare tyres:
Press button once to enter the next setting.
press button once to enter the next setting.
Trailer axles setting:
Spare Tyre settings (individual):
Enabled status(default)
Enabled status(default)
Disabled status
Disabled status
Driver should always operate a vehicle in a safe manner.
Minimising the amount of time spent viewing the display will
prevent distraction.
When installing on the dash, ensure the device is placed securely
to ensure that it does not obstruct the driver’s view of the road.
Do not place in any way that may hinder the vehicles operating
controls.
Do not place in a location that will obstruct airbags.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception,
which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio / TV technician for help.
1. After the installation, there is no tyre data on the display
* The sensors were not programmed to the display, please
reprogram the sensors
* The display should show the real time tyre data automatically when
the speed is over 25km/h
2. There is no tyre data on the display
* The sensors are not programmed to the display, please reprogram
it
* There is a problem with the sensor
3. The system has a problem when there is "--" appears
intermittently
* The signal that is transmitted is a RF signal and is much like a
cellphone signal. The FCC requires to allow all other RF signals to
interfere with the system signals and this can cause the monitor to
occasionally miss a transmission from the sensors. If this persists
then you could have a damaged sensor or the batteries could be
weak.
Press " " button 5 times, the display will beep
once and enters programming mode.
Psi
Psi
Function settings
Press “ “ button for 4 seconds to exit the setting mode
two beeps will sound.
The setting sequence as below:
Press “ “ button for 4 seconds to enter the setting mode,
a beep will sound.
Enter/Exit the setting mode
3. Screw the new sensor to the corresponding
tyre position.
Psi
4. The tyre data will be shown on the display,
then press “ ” button once to save the data.
Psi
Display low battery
Psi
Psi
Psi
Psi
Psi
Psi
Psi
Sensor failure
Psi
Pressure unit
Temperature unit Time interval of
each interface
High pressure
value
Tyre data
deletion
Low pressure
value
High temperature
value
Disable/enable trailer
and spare tyres
after
to save and move to the next setting.
PPI0540R/A
Produktspecifikationer
| Varumärke: | Oricom |
| Kategori: | Radio |
| Modell: | TPS10-10E |
Behöver du hjälp?
Om du behöver hjälp med Oricom TPS10-10E ställ en fråga nedan och andra användare kommer att svara dig
Radio Oricom Manualer
2 September 2024
1 September 2024
1 September 2024
1 September 2024
31 Augusti 2024
31 Augusti 2024
31 Augusti 2024
30 Augusti 2024
28 Augusti 2024
27 Augusti 2024
Radio Manualer
- Radio Sony
- Radio Xiaomi
- Radio Bosch
- Radio AEG
- Radio Philips
- Radio Panasonic
- Radio Daewoo
- Radio DeWalt
- Radio Garmin
- Radio Grundig
- Radio JVC
- Radio JBL
- Radio Kenwood
- Radio Karcher
- Radio Motorola
- Radio Medion
- Radio Quigg
- Radio Topcom
- Radio Yamaha
- Radio Adler
- Radio Aiwa
- Radio Albrecht
- Radio Akai
- Radio Acoustic Energy
- Radio Argon
- Radio OneConcept
- Radio Lexibook
- Radio Sharp
- Radio Telefunken
- Radio Silvercrest
- Radio Makita
- Radio Hitachi
- Radio Nedis
- Radio Thomson
- Radio Tristar
- Radio Lenco
- Radio Pyle
- Radio Vonroc
- Radio Audizio
- Radio Stanley
- Radio Manta
- Radio GPO
- Radio Caliber
- Radio Timex
- Radio OK
- Radio Hyundai
- Radio Sonoro
- Radio Renkforce
- Radio ECG
- Radio Moulinex
- Radio Ryobi
- Radio Bush
- Radio Clatronic
- Radio Lowrance
- Radio Sencor
- Radio GPX
- Radio Festool
- Radio Blaupunkt
- Radio Metabo
- Radio Logik
- Radio Milwaukee
- Radio Telestar
- Radio Salora
- Radio Denver
- Radio Imperial
- Radio Schneider
- Radio Sanyo
- Radio Vitek
- Radio Einhell
- Radio Hama
- Radio Soundmaster
- Radio Brigmton
- Radio Denon
- Radio Sunstech
- Radio Sennheiser
- Radio Maginon
- Radio Midland
- Radio GlobalTronics
- Radio Technisat
- Radio GoGEN
- Radio Rockford Fosgate
- Radio Marquant
- Radio Nordmende
- Radio AudioAffairs
- Radio Krüger And Matz
- Radio Binatone
- Radio Steren
- Radio Kicker
- Radio Bose
- Radio Audiosonic
- Radio Clarion
- Radio Proline
- Radio Coby
- Radio Crosley
- Radio Envivo
- Radio Muse
- Radio Teufel
- Radio Bigben Interactive
- Radio Kathrein
- Radio Olympia
- Radio Pure
- Radio Powerplus
- Radio Porter-Cable
- Radio Uniden
- Radio Audiovox
- Radio Ion
- Radio Roberts
- Radio Yaesu
- Radio Tesco
- Radio Artsound
- Radio Dual
- Radio Boss
- Radio Terris
- Radio Camry
- Radio Cobra
- Radio MB Quart
- Radio Switel
- Radio Bigben
- Radio Auna
- Radio Alba
- Radio Clas Ohlson
- Radio Naxa
- Radio Lexon
- Radio Sven
- Radio Ricatech
- Radio Konig
- Radio Boston Acoustics
- Radio Icom
- Radio Mpman
- Radio Trevi
- Radio Sogo
- Radio JL Audio
- Radio Zebra
- Radio Technaxx
- Radio Nikkei
- Radio PerfectPro
- Radio Peaq
- Radio Freecom
- Radio Jensen
- Radio Roadstar
- Radio Gira
- Radio Scott
- Radio Jung
- Radio Sangean
- Radio Basetech
- Radio Dnt
- Radio Balance
- Radio Audio Pro
- Radio HQ
- Radio Be Cool
- Radio Noveen
- Radio Karcher Audio
- Radio CRUX
- Radio Fusion
- Radio IHome
- Radio August
- Radio Infinity
- Radio AIC
- Radio Ruarkaudio
- Radio Tivoli Audio
- Radio Go Green
- Radio Victrola
- Radio Linn
- Radio Numan
- Radio Elta
- Radio Iluv
- Radio Monitor Audio
- Radio TELEX
- Radio Multiplex
- Radio Tangent
- Radio SPC
- Radio Stabo
- Radio Clint
- Radio Soundstream
- Radio Xoro
- Radio Sagemcom
- Radio Woxter
- Radio Xhdata
- Radio Monacor
- Radio Noxon
- Radio Orava
- Radio Geneva
- Radio Ferguson
- Radio Wet Sounds
- Radio DAP Audio
- Radio Reflexion
- Radio Duronic
- Radio Scansonic
- Radio TFA Dostmann
- Radio Audisse
- Radio ETON
- Radio Lenoxx
- Radio H-Tronic
- Radio Equity
- Radio Intertechno
- Radio Schwaiger
- Radio EKO
- Radio Pinell
- Radio Aquatic AV
- Radio Digitalbox
- Radio Ruark Audio
- Radio NUVO
- Radio Narex
- Radio Tiny Audio
- Radio Klein Tools
- Radio E-bench
- Radio Peha
- Radio Sanwa
- Radio Sailor
- Radio SSV Works
- Radio Microlab
- Radio QFX
- Radio Voxx
- Radio SACK It
- Radio BasicXL
- Radio Roth
- Radio Majestic
- Radio Ices Electronics
- Radio AmpliVox
- Radio Memphis Audio
- Radio AMX
- Radio Elbe
- Radio GBS Elettronica
- Radio Sang
- Radio Gewiss
- Radio Lutron
- Radio Axxess
- Radio Majority
- Radio Retekess
- Radio Wintal
- Radio Acoustic Solutions
- Radio Atlantis Land
- Radio Ranger
- Radio BLUEPALM
- Radio Weather X
- Radio Data-Tronix
- Radio Aconatic
- Radio Mebby
- Radio Yamazen
Nyaste Radio Manualer
27 Oktober 2024
26 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
23 Oktober 2024
22 Oktober 2024
20 Oktober 2024
19 Oktober 2024
18 Oktober 2024
