24DS16

HD CCTV 16CH Digital Splitter Built-In

ORION IMAGES CORPORATION

7300 Bolsa Avenue, Westminster, CA 92683 Tel. 714.766.6300 Fax. 714.766.6310 www.orionimages.com

Cam2

Cam3

Cam16

24” LCD with integrated 16 channel splitter

Can used to enhance display image of existing cameras

Deinterlacing & Scaling built-in

60% gain in video quality per channel in 1920 x 1200p Full HD mode

Minimizes the number of system components required

Digital Image

Up to 16 Analog Cameras + RG59/U Coaxial Cable + 24DS16

Cam1

RG59/U Coaxial Cable

View up to 16 analog cameras as 1 digital image

SPECIAL FEATURES

24DS16 INTERFACE

Composite Video 16ch

Composite 16ch

RS422 / 485

N/A

RS232C

N/A

Network (RJ45)

Dip Switch

Power Switch

USB

PS2 Port

VGA Out

Composit Loop Switch

AC In

KLMN

B C D E F G H I J

HDMI Input

DVI Input

VGA Input

PC Audio

Component

Audio Input

Audio Output

Video Input

Video Output

Trigger

S-Video In / Out

Bottom

Top

P Q S T U V W X Y

SERIES 24DS16

DISPLAY

INTERFACE (MONITOR)

TRANSMITTER

FEATURES

SPILITTER

Screen Size

RoHs, TUV NRTL, CB, FCC(A), CE-Emc(LVD)

Native Resolution

Pixel Pitch

Brightness

Contrast Ratio

Aspect Ratio

Viewing Angle (H/V)

Display Color

Response Time

Video System

Video In / Out (BNC Type)

S-Video In / Out

VGA In (15Pin D-Sub)

Component

HDMI In

DVI In

PC Stereo In

Audio In (RCA type)

Built in Speakers

Video In

Video Loop Out

VGA Output

Serial Interface

USB Port

Network

Dip-pin switch

PS2 port

Remote Control

Screen Division format

Video process

System Restore

OUTLINE DIMENSION

CABINET

WARRANTY

REGULATIONS

POWER

CIRCUMSTANCE

MOUNTS

Dimension W x H x D (w/ stand)

Net. Weight

Finish / Tilt Stand

Part & Labor

Consumption : < On

Electrical Ratings

Electronic

Operating Temperature

VESATM Mount Size

1, 4, 9, 11A, 11B, 12, 13, 14, 16A, 16B

Deinterlacing & Scaling

Watchdog (Auto Restart), Blackout : Auto Power On

Virtual key board on screen

Multi Language

Yes

Korean, English, Spanish, Japanese

2 (one for Display / one for monitor)

RS232 x 1 (For firmware upgrade)

RS485 / RS422 x 1

Resolution change (1920x1080p / 1280x1024 / 1024x768)

For upgrading the Firmware

BNC In / loop Out (selectable)

Connect to PS-2 Mouse

RJ45 (TCP / IP) x 1 (Controller Program is supported )

3 (For firmware upgrade)

Composite (DVI pin adaptor) x 16ch

Composite (BNC) x 16ch

Composite (DVI pin adaptor) x 16ch

Composite (BNC) x 16ch

0 ~ 50 C / 32 ~ 122 F

22.05”W x 15.55”H x 5.5”D

19 lbs

100 x 100mm

Black / Yes

2year / 2year

MTBF (Approx.) 50,000 Hours

< 60W

AC100 ~ 240V(50/60Hz)

DC 12V / 5A

24 Inch

1920 x 1200 @ 60Hz

0.270 x 0.270mm

1000 : 1

16 : 10

16.7 Million

< 5ms (Gray to Gray)

NTSC / PAL

2 / 2

1 / 1

3 (L+R)

Yes (4W X 2)

300cd/m2

160 / 160

* Design and Specifications are subject to ch ange without notice

MONITOR

Multi Display Function

Filter Type

Trigger Sensor

PIP / PBP

3D Comb filter / DeInterlace

Yes (NO / NC)

Multi Language English, Spanish, French, German, Italian
