Sida 1/6
MI5
OWNER’S MANUAL
Powered Amplifier
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT, FULLY INSERT.
Warning: To reduce the risk of
Electric shock, do not remove
Cover (or back) no user
Servicing to qualified service
Personnel.
The exclamation point within the
Equilateral triangle is intended to
Alert the user to the presence of
Important operating and
Maintenance (servicing)
Instructions in the literature
Accompanying suppliance.
1. Read these instructions.
2. Keep these instructions.
3 Read all warnings.
4 Follow all Instruction.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturers instructions.
8. Do not install near heat sources such as radiators, heat registers, stoves, or other apparatus
( Including amplifiers) that Produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
Blades with one wider than the other. A grounding type plug has two blades and a third grounding
Prong. If the provided plugs does not fit Into your outlet, consult an electrician for replacement of
The obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience
Receptacles, and at the point where they exit form the appliance.
11. Only use attachments or accessories specified by the manufacturer.
12. Unplug the apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been
Damaged in anyway, such as power supply cord or plug is damaged, liquid has been spilled or
Objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
Not operate normally, or has been dropped.
This appliance shall not be exposed to dripping or splashing water and no object filled with liquids
Such as vases shall be placed on apparatus.
This Lighting flash with arrowhead
Symbol, within an equilateral triangle,
Is intended to alert the use to the
Presence of un-insulated dangerous
Voltage within the products enclosure
That may be of sufficient magnitude
To constitute a risk of electric shock
To persons.
2
The MI5 Powered Amplifier can be turned on and off independently
via a switch on the front panel, by signal sensing, or remotely by a
triggered DC input. There is a switch located on the lower edge of
the rear panel of the amplifier to select how you would like to turn
on the MI5 power Amplifier. If you would like to control the unit’s
power On/Power off status manually from the front, place the
switch in the unit’s power On/Power off status by means of signal
sensing, place the switch in the “Auto On” position. If you would
like to control the unit’s power On/Power off status by a DC
Remote trigger, place the switch in the ”TRIGGER” position, and
connect the remote triggering device to the terminal labeled “
TRIGGER IN” next to the switch.
MI5Powered
Ampl ifier
Congratulations on your purchase of OSD Powered Amplifier.
Note: If any part of this product is damaged or missing,
Please call OSD Audio Return Department
At (714) 447-9880
Using the controls/ Front Panel
Power
MI6 Powered Amplifier. Please take a few moments to read this
entire manual, and be sure to retain this document for future
reference please read and observe all safety instructions detailed
on page.
The front panel switch will manually switch the MI5 Powered
Amplifier on or off. A blue led behind the faceplate lens indicates its
power status. Whenever the amplifier’s power switch is in the “ON”
position and the amplifier is in ”active” status the lens is illuminate
blue. If the amplifier is “ON” but in the “standby” status the lens is
illuminated RED.
You should use a 3.5mm phone plug in the “IN” connector to make
this connection. The tip of the connector is positive, and the sleeve
of the connector is negative. A second terminal in the same block is
labeled “OUT”. This allows for remote turn-on of other devices
when the MI5 powered Amplifier is powered on. Use the same
polarity for the terminals of this plug. Please read the owner ’s
manual for any devices you are attempting to connect in this
manner to ensure compatibility.
Note: The front panel power switch must be in the “ON”
Position for the triggers or “Auto ON” features to operate.
MODEL MI5
Using The Controls/ Back Panel
Power
3
